Panasonic SA-PT860GC Service Manual
Panasonic SA-PT860GC Service Manual

Panasonic SA-PT860GC Service Manual

Dvd home theater sound system
Table of Contents

Advertisement

Quick Links

Specifications
Main unit SA-PT860GC/GCS/GCT/GS
GENERAL
Power supply:
Power consumption:
Power consumption in standby mode:
Dimensions (W×H×D):
Mass:
Operating temperature range:
Operating humidity range:
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch:
250 W per channel (6 Ω), 1 kHz, 10% THD
Surround Ch:
125 W per channel (3 Ω), 1 kHz, 10% THD
Center Ch:
250 W per channel (6 Ω), 1 kHz, 10% THD
Subwoofer Ch:
250 W per channel (6 Ω), 100 Hz, 10 % THD
DVD Home Theater Sound System
AC 110V to 127V/220V to
240V, 50/60 Hz
This unit 135 W
approx. 0.4 W
430 mm×68 mm×327 mm
This unit 3.4 kg
+0 °C to +40 °C
35 % to 80 % RH
(no condensation)
SA-PT860GC
SA-PT860GCS
SA-PT860GCT
SA-PT860GS
Colour
(K).......................Black Type
Total RMS Dolby Digital mode power:
PMPO Output Power:
DIN Output Power: Dolby Digital Mode
Front Ch:
150 W per channel (6 Ω), 1 kHz, 1% THD
Surround Ch:
70 W per channel (3 Ω), 1 kHz, 1% THD
Center Ch:
150 W per channel (6 Ω), 1 kHz, 1% THD
Subwoofer Ch:
150 W per channel (6 Ω), 100 Hz, 1 % THD
Total DIN Dolby Digital mode power:
FM TUNER, TERMINALS SECTION
Preset Memory:
Frequency Modulation (FM)
Frequency range:
Antenna terminals:
© 2008 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0803019CE
250 W
9300 W
740 W
FM 30 stations
87.50-108.00 MHz (50-kHz step)
75 Ω (unbalanced)
Unauthorized
copying
and
