Panasonic SA-PT170PH Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Home Theater System
  5. SA-PT170PH
  6. Service manual

Panasonic SA-PT170PH Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's DVD mechanism unit is DLS6. Please refer to the original service manual
(Order No. MD0801003CE) for this mechanism

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. GENERAL GUIDELINES -------------------------------- 3
1.2. Before Use -------------------------------------------------- 3
1.3. Before Repair and Adjustment ------------------------- 3
1.4. Protection Circuitry ---------------------------------------- 4
1.5. Safety Parts Information --------------------------------- 4
2 Warning -------------------------------------------------------------- 6
DVD Home Theater Sound System
Model No.
Product Color: (K)...Black Type
PAGE
2.2. Precaution of Laser Diode -------------------------------7
3 Service Navigation --------------------------------------------- 11
3.1. Service Information -------------------------------------- 11
4 Specifications ---------------------------------------------------- 12
© Panasonic Corporation 2009. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
SA-PT170PH
SA-PT170PR
PSG0904028CE
PAGE
