4000 Series 18V
Power Awning
Installation and Owner's Manual
(For Aftermarket Applications)
4000 Series 18V
Power Awning
Installation and
Owner's Manual
(For Aftermarket Applications)
Solera Power Awning 18V Kits
Solera Power Awning 18V Kits
Part #
Part #
Description
434729
Power 18V 69" kit, Black
434730
Power 18V 69" kt, White
2
Charging the Battery
2
Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Extending the Awning and Setting Pitch
Retracting the Awning
2
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
Manual Override
4
Adjusting Pitch Arm Fasteners
Troubleshooting Table
4
Maintenance - Solera Awnings
5
Fabric Care
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
Notes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
7
1
CCD-0001260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
8
9
9
11
11
11
12
12
13
13
14
Rev. 09.20.24
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lippert Solera 4000 Series
Summary of Contents for Lippert Solera 4000 Series
- Page 1 ..........lippert.com 432-LIPPERT (432-547-7378) CCD-0001260...
- Page 2 POSSIBLY A FULL FACE SHIELD, DEPENDING ON Drive Head Assy w/Gear Pack w/Override - Regal - Awning Black THE NATURE OF THE INSTALLATION PROCEDURE. 672052 Idler Head Assy w/Gear Pack w/Override - Regal - Awning Black lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 3 INJURY, DAMAGE TO THE RECREATIONAL VEHICLE BE USED TO CONTAIN THE TENSION WHEN THE UNIT OR THE AWNING ASSEMBLY AS WELL AS SYSTEM IS BEING SERVICED. VOIDING THE LIPPERT COMPONENTS LIMITED WARRANTY. THE AWNING MUST BE RETRACTED COMPLETELY DURING INCIDENTS OF HIGH WIND, HEAVY RAIN...
- Page 4 4. Align the awning rail on the wall and secure with #10 x the top of the entry door. " screws, using all fastener holes. Letter Letter Description Description Awning Rail Support Arm Assembly Roll Tube Assembly front facing view floor line Fig.1 lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 5 NOTE: Keep the head of the wax screw ” from fastened to avoid compromising the structural integrity of the wax screw. Fig.3 awning rail awning width is from centerline to centerline of support arm assemblies. floor line Fig.2 lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 6 #14 x 1 ” screws at the top (Fig.5) and two #14 x 1 ” screws at the bottom (Fig.6). lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 7 OEM supplied #6 x 1/2” hex head screw (Fig.8E). Install the screw (Fig.8E) down through the awning rail (Fig.8B) and polycord (Fig.8D). possible fastener 1/4” locations 1” Outer Edge of Fabric Fig.7 Fig.8 lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 8 ANY CONNECTOR OTHER THAN THE ONE SPECIFIED MAY RESULT IN PERSONAL INJURY, DAMAGE TO THE RECREATIONAL VEHICLE UNIT OR THE AWNING ASSEMBLY AS WELL AS VOIDING THE LIPPERT COMPONENTS LIMITED WARRANTY. connector NOTE: The battery for the Solera 18V Power Pack is Fig.10...
- Page 9 1. Locate the locking latch on the side of the support arm, (Fig.12A). Scan the QR Code below to watch if equipped, and unlock the latch. the video on How to Correctly Pitch a Lippert Awning. NOTE: This latch is optional and may or may not be installed on one or both support arms.
- Page 10 (Fig.15). The 2-position arm can be set in the pitch position or snapped into a straight position by pushing the release button (Fig.15A) and sliding the sleeve (Fig.15B). Pitch Slide Fig.15 Fig.12 Fig.13 lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 11 (Fig.18) before the motor. manual override nut is released. Fig.16 Fig.18 lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 12 Make sure there are no obstructions in the support arm assemblies preventing Awning doesn’t close all the way. the awning from closing. Verify the fabric is square from unit to roll tube and is rolling up straight on the roll tube. lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 13 3. Repeat if necessary. accumulated dust, dirt and grime. 4. Allow to dry before retracting. Periodically clean vinyl or woven acrylic fabric using a mixture of cup of dish soap and five gallons of warm water. lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 14 4000 Series 18V Power Awning Installation and Owner’s Manual (For Aftermarket Applications) Notes lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 15 4000 Series 18V Power Awning Installation and Owner’s Manual (For Aftermarket Applications) Notes lippert.com 432-LIPPERT (432-547-7378) CCD-0001260 Rev. 09.20.24...
- Page 16 Installation and Owner’s Manual (For Aftermarket Applications) Manual information may be distributed as a complete document only, unless Lippert provides explicit consent to distribute individual parts. All manual information is subject to change without notice. Revised editions will be available for free download at lippert.com.
