TOOLS REQUIRED
•
Scissors or utility knife
•
Isopropyl alcohol
•
1/2" Wrench or socket
•
Phillips screwdriver
•
5/8" Drill bit & drill
PARTS INCLUDED IN THE BOX
1x Hard fold cover
A
1x Driver side rail
B
1x Passenger side rail
C
1x Bulkhead seal
D
4x Cover retainer clamps
E
6x Clamps
F
2x Drain tubes
G
1
Installing Seal: Install bulkhead seal (D) included with
cover (A) by cleaning the top of the bulkhead with soap and
water to remove dirt and debris. Clean the area with isopropyl
alcohol to remove wax or grease and to evaporate any remaining
water. Allow the surface to dry. Peel the backing and adhere the
seal from one bulkhead edge to the other. Remove any excess with
scissors or a utility knife. Apply pressure evenly to the entire seal to
ensure proper adhesion. If the truck has a drop-in bedliner, no seal
will be needed.
RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024
NOTE: It is important that all areas
where the bed cover mounts are clean
and free of debris prior to installing.
A
B
2005-2021 NISSAN FRONTIER
With or Without Utili-Track System
SELECT
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 866-900-8800 Mon - Fri 8:00 am - 5:00 pm CST
or email info@undercoverinfo.com
C
G
D
F
E
D
E
G
F
Part# SL-U8_Install Rev. 7-22-24
Advertisement
Table of Contents
Related Manuals for UnderCover REALTRUCK UNDSL54011
Summary of Contents for UnderCover REALTRUCK UNDSL54011
- Page 1 Apply pressure evenly to the entire seal to ensure proper adhesion. If the truck has a drop-in bedliner, no seal will be needed. RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024 Part# SL-U8_Install Rev. 7-22-24...
- Page 2 If the clamps are tightened too quickly or overtightened, it will cause the rails to lean down. Part# SL-U8_Install Rev. 7-22-24 RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024...
- Page 3 You are ready to drive with towards the cab. your cover in the closed position. RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024 Part# SL-U8_Install Rev. 7-22-24...
- Page 4 Slide assembly. the latch housing back on. Part# SL-U8_Install Rev. 7-22-24 RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024...
-
Page 5: Limited Warranty
Other than postage or shipping charges, no charge will be made for repair or replacement under this warranty. This warranty gives you specific legal rights. As an owner, you may also have additional rights and remedies under the laws of your state. WARRANTY REGISTRATION Warranty registration must be on file and/or proof of original purchase (detailed and dated receipt) required for warranty to be effective. https://realtruck.com/undercover-warranty REGISTER Serial Number_______________________________________________________ YOUR WARRANTY Date of Purchase ___________________________________________________ ONLINE Part# SL-U8_Install Rev. 7-22-24 RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024... -
Page 6: Care And Maintenance
Wavy Side Seal: The seal may be wavy when removed from the box. Allow 3-5 days in warm sunlight to lay down and relax. RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024 Part# SL-U8_Install Rev. 7-22-24...
