- Page 1 SP 1.900 SP 4.500 SP 4.900 USER’S Il Manuale Utente è disponibile anche sul nostro sito www.hertz-audio.com MANUAL The User’s Manual is also available on our web site www.hertz-audio.com rev 1.0 hertz-audio.com...
-
Page 2: Packaging Contents
User’s Manual PACKAGING CONTENTS Speakers out Power supply harness harness SP 4.900 Installation screws 3,5 x 25 mm Wire to RCA adapter SP 4.500 Speakers out harness Power supply harness Speakers out Power supply harness harness SP 1.900 Installation screws 3,5 x 25 mm Wire to RCA adapter... - Page 3 User’s Manual Index 1. PRECAUTIONS ..............................08 2. INSTALLATION AND SIZES........................... 42 3. CABLE SIZE CALCULATION TABLES. 1: POWER SUPPLY / 2: SPEAKERS ............42 4. POWER SUPPLY and REMOTE IN CONNECTION ....................43 5. INPUT/OUTPUT CONNECTION ..........................44 6. PRE IN / SPEAKER IN / DC REM ......................... 46 7.
- Page 4 User’s Manual SLOVENŠČINA ESPAÑOL KAZALO ÍNDICE 1. PREVIDNOSTNI UKREPI. 1. PRECAUCIONES. 2. VELIKOSTI. 2. TAMAÑOS. 3. RAZPREDELNICE ZA IZRAČUN DIMENZIJ KABLOV 3. TABLAS DE CÁLCULO DE TAMAÑO DEL CABLE 1: NAPAJANJE 2: ZVOČNIKI. 1: ALIMENTACIÓN 2: ALTAVOCES. 4. NAPAJANJE IN PRIKLJUČEK ZA DALJINSKI VHOD (REMOTE IN). 4.
- Page 5 15. Always wear protective eyewear when using tools, as splints or product residue may become airborne. TYPICAL INSTALLATION SEQUENCE If you have any questions please refer to the User’s Manual you can find available on www.hertz-audio.com or contact your HERTZ dealer or Hertz authorized service for assistance.
- Page 6 15. Utilisez toujours des protections pour les yeux lorsque vous utilisez les outils, car des bouts de bois ou des résidus du produit peuvent être dans l’air. SÉQUENCE D’INSTALLATION TYPIQUE Si vous avez des questions, veuillez vous référer au Manuel de l’Utilisateur disponible sur www.hertz-audio.com ou contacter votre revendeur HERTZ ou le service d’assistance HERTZ.
- Page 7 15. Lleve siempre gafas protectoras cuando use herramientas, ya que los fragmentos de metal o residuos del producto pueden saltar al aire. SECUENCIA HABITUAL DE INSTALACIÓN En caso de duda, consulte el Manual del usuario disponible en www.hertz-audio.com o comuníquese con su distribuidor HERTZ o con un centro de servicio autorizado HERTZ para obtener ayuda.
-
Page 8: Installation And Sizes
User’s Manual INSTALLATION AND SIZES 205 211,6 107 SP 1.900 8.07 8.33 4.212 5.118 1.929 185.7 192.7 107 SP 4.500 7.31 7.58 4.212 5.118 1.929 205 211,6 107 SP 4.900 8.07 8.33 4.212 5.118 1.929 CABLE SIZE CALCULATION TABLES: 1: Power supply cable / 2: Speakers cable. 1: Power supply cable 2: Speakers cable Connection length... - Page 9 User’s Manual POWER SUPPLY and REMOTE IN CONNECTION SOURCE FUSE SP 1.900 60 A SP 4.500 30 A SP 4.900 60 A APPLY A FUSE CLOSE TO BATTERY POSITIVE POLE TO PROTECT BATTERY CABLE MAX 20 cm / 7.9 in. FUSE 12 V BATTERY...
-
Page 10: Input/Output Connections
User’s Manual INPUT / OUTPUT CONNECTIONS SP 1.900 Optional REMOTE VOLUME CONTROL HRC BM IN R IN L [USS] SPEAKER OUT use RCA adapter Provided WHITE IN L Select “HI [USS]” if you connect speaker output signals. Select “LO” if you connect pre-out signals. - Page 11 User’s Manual PRE IN / SPEAKER IN / DC REM SP 1.900 CONTROLS SIDE Red LED DC REM INPUT LEVEL INPUT SEL MONO L [USS] HI LEVEL PRE INPUT CHECK Mono Input Stereo input AUTO TURN ON LEVEL input with on IN L on IN L - IN R by SPEAKER DC...
- Page 12 User’s Manual SP 1.900 DC REM: Auto Turn On by Speaker DC (without using the “REM IN” wire) CONTROLS SIDE [USS] PROT. DC REM INPUT LEVEL INPUT SEL CH1-2 CH3-4 FREQ GAIN B.BOOST GAIN FREQ FULL LP HP FULL LP HP CABLES SIDE REM IN [USS]...
-
Page 13: Installation Examples
User’s Manual INSTALLATION EXAMPLES SP 1.900 1 Ch OUT (2Ch IN L+R): One Subwoofer CONTROLS SIDE SUBWOOFER LO-PASS GAIN CABLES SIDE REM IN [USS] use RCA adapter SPEAKER OUT Provided OUT + WHITE IN L Select “HI [USS]” if you connect speaker output signals. - Page 14 User’s Manual 2 Ch OUT (2Ch IN L+R): Two Subwoofer CONTROLS SIDE SUBWOOFER LO-PASS GAIN CABLES SIDE REM IN [USS] use RCA adapter SPEAKER OUT Provided OUT + OUT - WHITE IN L Select “HI [USS]” if you connect speaker output signals.
- Page 15 User’s Manual 1 Ch OUT (1Ch IN): One Subwoofer CONTROLS SIDE SUBWOOFER LO-PASS GAIN CABLES SIDE REM IN OUT + WHITE IN L PRE OUTS use RCA cable adapter Not provided OUT - IN R SUBWOOFER min 1Ω Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
- Page 16 User’s Manual 2 Ch OUT (1Ch IN): Two Subwoofer CONTROLS SIDE SUBWOOFER LO-PASS GAIN CABLES SIDE REM IN OUT + OUT - WHITE IN L PRE OUTS use RCA cable adapter Not provided SUBWOOFER IN R min 2Ω OUT + OUT - SUBWOOFER min 2Ω...
-
Page 17: Block Diagrams
User’s Manual BLOCK DIAGRAMS SP 1.900... -
Page 18: Technical Specifications
User’s Manual TECHNICAL SPECIFICATIONS SP 1.900 POWER SUPPLY Nominal power supply voltage 11 ÷ 15 VDC Pulse Operating voltage 6 ÷ 16 VDC Idling current 0.9 A Idling current when off 0.03 mA Consumption @ 14.4 VDC, MIN load impedance 50 A (Max Musical Power) Remote IN... - Page 19 PART OF ELETTROMEDIA Strada Regina Km 3,500 - Marignano 62018 Potenza Picena (MC) Italy T +39 0733 870 870 - F +39 0733 870 880 www.elettromedia.it...
- Page 20 SP 1.900 D-CLASS MONO AMPLIFIER 1000 W Up to 87% efficiency thanks to ADC (Advanced D-Class) output stage, ensuring POWER SUPPLY high audio performance in a compact size. Nominal power supply voltage 11 ÷ 15 VDC USS (Universal Speakers Simulators) allows SP 1.900 to work with head units Pulse Operating voltage 6 ÷...
