- Page 1 EMU Hardware 70681 User Manual ENTTEC’s touring-grade USB to DMX/Art-Net interface delivers real-time lighting control for EMU software.
-
Page 2: Table Of Contents
EMU HARDWARE (70681) Visit the ENTTEC website for the latest version. Content Safety............................................. 2 Electrical safety ............................................. 2 System Planning and Specification .................................... 2 Protection from Injury During Installation ................................3 Installation Safety Guidelines ....................................... 3 Hardware Feature ......................................4 Physical Dimensions .......................................... -
Page 3: Safety
ENTTEC device. If you are in any doubt about system safety, or you plan to install ENTTEC device in a configuration that is not covered within this guide, contact ENTTEC or your ENTTEC supplier for assistance. -
Page 4: Protection From Injury During Installation
Always work with a plan of the installation that respects all system limitations as defined within this guide and product datasheet. Note the serial number of each EMU HARDWARE and add it to your layout plan for future reference when servicing. -
Page 5: Hardware Feature
◼ TS35 DIN mount (using provided DIN Clip accessory) Physical Dimensions Mounting Method The EMU Hardware supports DIN rail mounting. To install, attach the DIN rail clip using the screws provided in the product packaging. Once secured, mount the product onto a suitable TS35 rail for installation. -
Page 6: Dmx Connector
EMU HARDWARE (70681) Visit the ENTTEC website for the latest version. DMX Connector The EMU Hardware features both 3-Pin and a 5-Pin Female XLR DMX ports for a combined 512 channels of DMX512 output. ◼ PIN1: GND (V-) ◼ Pin 4: NC (5-Pin XLR only) ◼... -
Page 7: Wiring Diagram
2. Connect the EMU Hardware to your computer with the data-grade USB Type-C cable provided. 3. Connect the DMX output (either 3 pin or 5 pin) of the EMU Hardware to the “DMX IN” XLR socket on your first light fixture. -
Page 8: Functional Feature
To configure the EMU Hardware, you need the ENTTEC EMU Software. Visit the ENTTEC website to download a free version of the EMU Software, which includes basic functionalities to help users explore the platform. The software provides a comprehensive setup and management suite for the EMU Hardware, featuring: ◼... -
Page 9: Device Discovery
In the Output tab, click the Scan for devices button to search for any EMU Hardware connected to your computer. Once the device is detected, click the gear icon next to the device to access configuration options. -
Page 10: Connecting Enttec Lighting Controller
5. Footswitch or MIDI configuration: see EMU Software User Manual for detailed instructions. Connecting ENTTEC Lighting Controller EMU Hardware featuring RJ45 ethernet port supporting connection to other Art-Net controllers. The EMU Software will discover connected devices and allow integration of compatible ENTTEC lighting controllers. -
Page 11: Firmware Update
The firmware update procedure can be used to: Update to the latest feature set. Reset EMU HARDWARE if it ever gets stuck or stops responding. (Eg., Error mode). The following steps will explain the firmware update procedure: 1. Launch the EMU Software on your computer and select of the discovered EMU Hardware from the device list. -
Page 12: Cleaning
◼ Do not spray the device or accessories. The device is an IP20 product. To clean an ENTTEC device, use low-pressure compressed air to remove dust, dirt, and loose particles. If deemed necessary, wipe the device with a damp microfiber cloth.
