Jet J-349V Operating Instructions Manual

Portable bandsaw
Hide thumbs

Advertisement

Quick Links

Download this manual
J-349V
Original:
GB
Operating Instructions
Portable Bandsaw
JPW Tool Group Hong Kong Limited
98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC
www.jettools.com
Импортёр в РФ: ООО «ИТА Технолоджи»
105082, Москва, Переведеновский пер., д. 17
www.jettools.ru
Made in Taiwan / Сделано на Тайване
M-50000333M
2022-12

Advertisement

loading
Need help?

Need help?

Do you have a question about the J-349V and is the answer not in the manual?

Questions and answers

Related Manuals for Jet J-349V

Summary of Contents for Jet J-349V

  • Page 1 J-349V Portable Bandsaw Original: Operating Instructions JPW Tool Group Hong Kong Limited 98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC www.jettools.com Импортёр в РФ: ООО «ИТА Технолоджи» 105082, Москва, Переведеновский пер., д. 17 www.jettools.ru Made in Taiwan / Сделано на Тайване...

  • Page 2: Table Of Contents

    Many thanks for the confidence you have shown in us with the purchase of your new machine. This manual has been prepared for the owner and operators of a J-349V metal band saw to promote safety during installation, operation and maintenance procedures.

  • Page 3: Declaration Of Conformity

    Contents 1. Declaration of conformity On our own responsibility we hereby declare that this product complies with the regulations* listed on page 2. Designed in consideration with the standards**. 2. Warranty JPW (Tool) AG guarantees that the supplied product is free from material defects and manufacturing faults.

  • Page 4: Remaining Hazards

    The machine is designed to operate in closed rooms and must be placed stable on firm and levelled ground. Make sure that the power cord does not impede work and cause people to trip. Keep the floor around the machine clean and free of scrap material, oil and grease. Never reach into the machine while it is operating or running down.

  • Page 5: Transport And Installation

    4.2 Noise emission Acoustic pressure level (EN ISO 11202): Idling LpA 60,0 dB(A) The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks involved only.

  • Page 6: Machine Operation

    6. Machine operation NOTE: Before using the saw, pull the transport lock pin (A, Fig 3).For transport lock it again. Fig 3 The machine is designed to cut in dry condition only. The use of any coolant or oil will damage the machine. Don’t cut magnesium-high danger to fire! Support long workpieces with helping roller stands.
  • Page 7 7.2 Blade guides adjustment Loosen the indexable knob (B, Fig 5) and slide blade guide assembly (C) as close as possible without interfering the material being cut. Tighten knob. Fig 5 7.3 Machine vice adjustment The machine is equipped with a vise. Fig 6 To clamp the workpiece, rotate the lever in clockwise direction.
  • Page 8 7.5. Choosing the saw blade Choose a toothing that is appropriate to the workpiece being processed. Ideally, at least 3 teeth should be in action at the same time. The toothing should not be smaller than necessary, as the cutting speed is reduced if there are too many small teeth working on the workpiece simultaneously, which causes the saw blade to wear more quickly, and makes the cuts crooked and distorts them.
  • Page 9 7.6 Cutting speed selection The general rule is the harder the material being cut, the slower the blade speed. 25 - 30 m/min (Position 1) for stainless steel, alloy steel and bearing bronzes. 40 - 50 m/min (Position 2-3) for mild steel, hard brass or bronze. 60 - 80 m/min (Position 4-6) for soft brass, aluminum or other light materials.

  • Page 10: Maintenance And Inspection

    8. Maintenance and inspection General notes: Maintenance, cleaning and repair work may only be carried out after the machine is protected against accidental starting by pulling the mains plug. The maintenance schedule has been divided into daily, weekly, monthly and six-monthly intervals. Neglecting the machine maintenance will result in premature wear and poor performance.

  • Page 11: Environmental Protection

    Cut is not square *Saw arm setting is bad *Blade guide setting is bad. *Saw blade is dull. Cutting surface is bad *Wrong saw blade chosen *Saw blade is dull *Blade guide setting is bad *Blade tension too low *Feed pressure too high *Feed speed too high 10.Environmental protection Protect the environment.
