- Page 1 UA-24 v2.0 BEEPER Headset with Bluetooth wireless technology...
-
Page 2: Table Of Contents
Contents Product Specifications ..1 Components ..1 UA-24 v2.0 Overview ..2 Retractable Mechanism ..3 Ringer and Anti-Lost Function ..4 How to Wear ..5-7 Charging the Headset ..8 Getting Started ..9 Pairing with a mobile phone ..9-11 Using the Headset ..12-15 Trobleshooting ..16-17 Safety Precautions ..18... -
Page 3: Product Specifications
55(L) x 25.5(W) x 15(H) mm Weight: *May be varied by mobile phone setting and operator Components Thanks for choosing the iXchange UA-24 v2.0 BEEPER Headset, we hope you enjoy it! Inside the package, you should find: 1 UA-24 v2.0 Headset 1 USB Cable... -
Page 4: V2.0 Overview
UA-24 v2.0 Overview 1.Rewind Button 2. Status Indicator (LED) 3. Multi-function Button (MFB) 4. Volume Button 5. Microphone 6. Earpiece 7. Clip 8. Micro USB Charging Socket 9. Neck Strap Hole... -
Page 5: Retractable Mechanism
Retractable Mechanism The earpiece cord can be extended by gently pulling the cord. It can be retracted (shortened) by pressing the Rewind Button. -
Page 6: Ringer And Anti-Lost Function
Ringer and Anti-Lost Function UA-24 v2.0 has a built-in buzzer, which supports A. Ringer B. Anti-Lost Function UA-24 v2.0 will make a "Beep" UA-24 v2.0 has an out of range alert sound when you have an that reminds you that your incoming call to prevent phone is out of range or left missing any important call. -
Page 7: How To Wear
How to Wear UA-24 v2.0 is designed, A. to clip onto your clothing, or... - Page 8 How to Wear B. fasten by a neck strap to wear comfortably and securely around your neck Step 1. Loop the thin end of the neck strap through the slot on the headset. Step 2. Loop the thicker side of the neck strap through the loop created by the thin wire and pull until snug.
- Page 9 How to Wear To release the strap, hold the strap and pull outwardly. (Ref to the picture) 1. Use the provided neck strap only. 2. It may be necessary to bring the microphone closer to your mouth for lowering the blackground noise...
-
Page 10: Charging The Headset
Charging the Headset Before using your UA-24 v2.0 ("Headset"), please plug the charger into the power source and connect the other end to Micro USB charging socket of Headset to charging the battery fully. Status Status Indicator Audio (Earpiece) 1. Charging Red light ON No sound 2. -
Page 11: Getting Started
Getting Started Turning ON: Press and hold the MFB until the status indicator (LED) flashes blue and "beep" once . For the first time (or after reset), the headset will go to the Pairing Mode directly (LED flashes blue and red). Turning OFF: Press and hold the MFB until the LED flashes red and "beep"... -
Page 12: Pairing With A Mobile Phone
To pair the headset with a second phone (Multi-point operation) 1. Pair the headset with the first phone, follow the step in "Pairing with a mobile phone". 2. Turn off the headset and the Bluetooth on the first phone. 3. Pair the headset with the second phone, follow the step in "Pairing with a mobile phone"... -
Page 13: Reconnecting The Headset
Reconnecting the headset 1. If the headset has been powered off, it will reconnect the phone automatically after turning on the headset, it not, press connect on the phone. 2. If the phone has been powered off, the headset is then disconnected, reconnect the headset by pressing on the phone or turns on the headset again after turning of the phone. -
Page 14: Using The Headset
Using the Headset Function Button Vibration Audio Status (Headset) (Speaker) Indicator Incoming call Beep Ringtone Blue light flashes sound (Music will stop) Answer a call Press the MFB once “Do Do” tone During the call, once blue light flashes (Standby mode or music playing mode) Answer a “Do Do”... - Page 15 Using the Headset Function Button Audio Audio Status (Headset) (Speaker) Indicator(LED) Voice dial Press and hold the MFB “Do” tone once once 1. After your hear a short beep, say the voice tag, and you must have the voice tag record on your phone.
- Page 16 Using the Headset Function Button Vibration Audio Status (Headset) (Speaker) Indicator(LED) Adjust Volume Press the Vol +/- once to increase of decrease by 1 level Standby mode Blue light flashes without mobile in every 10s, connection then blue and (No network red light flashing covered) Standby mode...
- Page 17 Using the Headset UA-24 v2.0 is designed to work with the mobile phone with Bluetooth Headsfree profiles, the compatibility of some featues are not guaranteed for some mobile phone with different operating system. In order to have a better and clear reception, there should have no obstade to the headset while talking.
-
Page 18: Troubleshooting
Troubleshooting I cannot pair with my mobile phone - Ensure your headset is power on and fully charged - Ensure the Bluetooth setting is activated on your phone - Ensure the headset is at pairing mode (flash blue and red LED) - Ensure the headset is not out of range of your phone If the above steps do not solved the problem, please turn off the headset and recharge the headset, and then try again. - Page 19 Troubleshooting My phone cannot be auto-reconnect with the headset - Manually connect the headset from your phone - Turn off the phone and then turn on again - Turn off the headset and then turn on again If the above steps do not solve the problem, turn off the headset and reset it, then pair the headset again Can I switch off the "Beep"...
-
Page 20: Safety Precautions
Safety Precautions 1. Unintentional depression of the retractable button could result in an injury from the force of the earpiece cord retraction. 2. Be careful when retracting the length of the earphone. Keep a safe distance between your face and the headset. 3. -
Page 21: Maintenance
Maintenance 1. Do not yank or forcibly pull the earphone cord. 2. Consider turning your headset off before placing it into your pocket or bag. If the MFB is accidentally pushed, your phone may place an unintended call. 3. Do not expose the headset to liquid or humidity, as it is not waterproof. 4. -
Page 22: Declaration Of Conformity
Declaration of Conformity We, iXchange, declare that the following product: Model No.: UA-24 v2.0 is in conformity with the following essential requirements of Council Directive 1999/5/EC (referred to as R&TTE Directive): Article 3.1a, 3.1b and 3.2 and the product is manufactured in accordance with Article 11 of the directive. - Page 23 FCC Compliance Statement 15.105 (b) This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
