Summary of Contents for iXchange Mini Clip
- Page 1 Mini Clip Retractable Headset User Manual...
-
Page 3: Table Of Contents
Contents .... 3 Components .... 3 UA-26 Overview .... 4 Retractable Mechanism .... 5 How to Wear Your Headset .... 6-8 Charging Your Headset .... 9 Getting Started .... 10 Pairing Your Headset with a Bluetooth ® wireless technology enabled phone .... -
Page 4: Components
Bluetooth v5.3 ® Bluetooth HFP, HSP, A2DP, AVRCP ® Operating Distance: 10 meters Operating Temperature: 0-50 degree celsius Charging Time: Around 1.5-2 hours Talk Time*: Up to 7.5 hours Music Time*: Up to 10 hours Standby Time*: Up to 120 hours Battery Type and Capacity: Rechargeable Li-Polymer 65mAh Dimension:... -
Page 5: Ua-26 Overview
UA-26 Overview 1. Rewind Button 2. Multi-function Button (MFB) 3. Status Indicator 4. Microphone 5. Speaker 6. Clip 7. Micro USB Charging Socket 8. Neck Strap Hole... -
Page 6: Retractable Mechanism
Retractable Mechanism The earpiece cord can be extended by gently pulling on the cord. The cord can be retracted (shortened) by pressing the Rewind Button. PULL PRESS... -
Page 7: How To Wear Your Headset
How to Wear Your Headset UA-26 is designed, A. to clip onto your clothing... - Page 8 How to Wear Your Headset (cont’d) B. fasten by a neck strap to wear comfortably and securely around your neck Step 1. Loop the thin end of the neck strap through the slot on the Headset. Step 2. Loop the thicker side of the neck strap through the loop created by the thin wire and pull until snug.
- Page 9 How to Wear Your Headset (cont’d) To release the strap, hold the strap and pull outwardly. (See the picture on left) • Use the provided neck strap only. • It may be necessort to bring the microphone closer to your mouth for lowering background noise.
-
Page 10: Charging Your Headset
Charging Your Headset Before using your UA-26 (”Headset”) for the first time, please insert the charger into the power source and connect the other end to micro USB charging socket of headset to charge the battery fully. Status Status Indicator 1. -
Page 11: Getting Started
Getting Started Turning Your Headset On and Off: A. Turning on Press and hold the MFB until the status indicator flashes blue. B. Turning off Press and hold the MFB until the status indicator flashes red. Pairing Your Headset with a Bluetooth ®... -
Page 12: Pairing Your Headset With Two Bluetooth ® Wireless Technology Enabled Phones
® Pairing Your Headset with two Bluetooth wireless technology enabled phones (Multi-point) Headset supports a Multi-point function to allow simultaneous its pairing with two mobile phones. with a Bluetooth mobile phone”). 2. Turn off the headset and the bluetooth function of the first paired phone. 3. -
Page 13: Reconnecting Your Headset
Reconnecting Your Headset 1. If the headset has powered off, it will be reconnected to the phone auto- matically after switching on the headset. 2. If the phone has powered off and headset is then disconnected you need to reconnect the headset from the bluetooth’s menu when phone turns on again. -
Page 14: Using Your Headset
Using Your Headset Function Button Audio Status (Earpiece) Indicator Blue light flashes Incoming Call Ringtone Answer a Call Press MFB once to During the call, blue accept. light flashes Call Reject Press the MFB twice • Reject a second call directly on the other connected phone during the call. End a Call Press the MFB once ‘Do’... - Page 15 Using Your Headset (cont’d) Function Button Audio Status (Earpiece) Indicator Out of range Blue light flashing 2 alert times • The headset will automatically reconnect within 5 minutes, otherwise it will off. If auto-connect is not supported, please reconnect from the Bluetooth’s menu. Call Transfer During a conversation, Call by headset: Blue light...
- Page 16 Using Your Headset (cont’d) Function Button Audio Status (Speaker) Indicator Blue light flashing Standby mode 2 times without mobile connection UA-26 is designed to work with the mobile phones with Bluetooth • Hands-free not guaranteed for some phones in different operating system. In order to have a better and clear reception, there should have no obstacle to the headset while talking.
-
Page 17: Troubleshooting
Troubleshooting I cannot adjust volume in my headset - Please adjust the volume by your phone I cannot pair with my mobile phone - Ensure your headset is power on and fully charged - Ensure the Bluetooth setting is activated on your phone - Ensure the headset is at pairing mode (blue light on) - Ensure the headset is not out of range of your phone - Ensure your phone is visible to all nearby Bluetooth devices (when the headset... - Page 18 Troubleshooting (cont’d) I cannot turn on the headset Ensure your headset is power on and fully charged, otherwise, please charge the headset for 1-1.5 hours, and then turn on again. My phone cannot be auto-reconnected with the headset - Manually connect the headset from your mobile phone - Turn off the mobile then turn on again - Turn off the headset then turn on again There is a “Beep”...
-
Page 19: Safety Precautions
Safety Precautions 1. Unintentional depression of the retractable button could result in an injury from the force of the earpiece cord retraction. 2. Be careful when retracting the length of the earphone. Keep a safe distance between your face and the headset. 3. -
Page 20: Maintenance
Maintenance 1. Do not yank or forcibly pull the earphone cord. 2. Consider turning your headset off before placing it in your pocket or bag. If the MFB is accidentally pushed, your mobile phone may place an unin- tended call. 3. -
Page 21: Declaration Of Conformity
Declaration of Conformity We, iXchange, declare that the following product: Product Name: Mini Clip Model Number: UA-26 is in conformity with the following essential requirements of Council Directive 1999/5/EC (referred to as R&TTE Directive): Article 3.1a, 3.1b and 3.2 and the product is manufactured in accordance with Annea II of the directive. -
Page 22: Fcc Compliance Statement
FCC Compliance Statement (cont’d) 15.105(b) This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 24 Made in China...
- Page 25 Product Name Bluetooth Headset ： Product Model (S) UA-25B1, UA-26B1, UA-25 v2.0, UA-26 ： Trade Mark iXchange ： Related Directive 2014/53/EU Article 3.1a) : EN IEC 62368-1:2020 + A11:2020 EN 62479:2010 EN 50663:2017 Article 3.1b) : ETSI EN 301 489-1 V2.2.3 (2019-11) ：...
