Kramer VS-611DT Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
VS-611DT UHD 6x1:2 Auto Switcher
1 Power supply (12V DC)
Step 2: Get to know your VS-611DT
# Feature
1 ON LED
2 LAST LED
3 AUTO LED
4 AUTO/MAN. Button
5 LAST/PRIO. Button
6 INPUT Buttons (1-6)
7 OFF Button
8 EDID Button
9 LOCK Button
VS-611DT Quick Start (P/N: 2900-300841QS REV 4)
VS-611DT Quick Start Guide
This guide helps you install and use your VS-611DT for the first time.
www.kramerav.com/downloads/VS-611DT
Go to
firmware upgrades are available.
Function
Lights when the unit is powered on
Lights when last connect is active
Lights when auto switching is active
Press to select between auto-switching or manual switching mode
Press to select between last connected mode or priority switching mode
Press to select an HDMI source to route to the output
Press to mute the output
Press to capture the EDID
Press and hold to toggle locking and unlocking the front panel buttons
to download the latest user manual and check if
4 Rubber feet
1 Quick start guide
P/N:
2900- 300841QS
Rev:
4
