Quick Links
Scan for full manual
Step 1: Check what's in the box
RK-10MT
Rack Mount
1 Quick start guide
Step 2: Get to know your RK-10MT
Step 3: Mount RK-10MT
• Ensure that the environment (e.g., maximum ambient temperature & air flow) is compatible for the device.
• Avoid uneven mechanical loading.
RK-10MT Quick Start
RK-10MT Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/RK-10MT
upgrades are available.
RK-10MT
for the first time.
to download the latest user manual and check if firmware
2 Blank panels
#
Feature
1
Rack Adapter Screw
Holes
2
Blank Panel
3
Open Panel
4
Inside Screw Holes
Knob
5
P/N: 2 9 0 0 - 3 0 1 5 0 7 QS
50 Screws
Function
Connect to a Rack adapter shelf.
Blank panel to cover open slot.
Rack-mount panel with opening for
inserting the device.
Insert screws (supplied) to attach the
device to the open panel.
Turn to attach a panel to the rack.
Rev: 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kramer RK-10MT
Summary of Contents for Kramer RK-10MT
- Page 1 Step 1: Check what’s in the box RK-10MT Rack Mount 2 Blank panels 50 Screws 1 Quick start guide Step 2: Get to know your RK-10MT Feature Function Rack Adapter Screw Connect to a Rack adapter shelf. Holes Blank Panel Blank panel to cover open slot.
- Page 2 To mount a device onto the rack: 1. Unfasten the knobs to remove the open panel. 2. Slide the device into the panel opening. 3. Attach the device to the panel using 4 screws (2 on each side to secure the device to the panel. 4.
