0010-0004 SunSpot 46 HX-LX Installation Rev_I.docx
Installation Instructions
Sunspot 46 LX/HX
AeroLEDs, LLC
8475 W. Elisa St.
Boise, ID, 83709
208-850-3294
Name
Jennifer Blanchfield
Nate Calvin
Mark McCormack
04 December 2024
Intent
Installation and Operation Instructions
for the Sunspot 46 LX/HX series lights
Document Number
0010-0004
1 of 7
Revision
I
Advertisement
Table of Contents
Related Manuals for Whelen Engineering Company AEROLEDS Sunspot 46 LX
Summary of Contents for Whelen Engineering Company AEROLEDS Sunspot 46 LX
- Page 1 Installation Instructions Sunspot 46 LX/HX AeroLEDs, LLC 8475 W. Elisa St. Boise, ID, 83709 208-850-3294 NOTE: A printed copy of this document may not be the latest revision. It is the responsibility of the user to ensure that the latest revision is used. The latest revision of this document may be printed from the AeroLEDs electronic document repository.
-
Page 2: Revision Record
REVISION RECORD Rev Description Date Author Update Logo; added P65 warning 12/04/2024 J. Blanchfield Format, Instruction, and Image updates. Remove 10/26/2021 M. McCormack references to taxi lights All Pages Revised, Correct PN from 01-2030 to 01-2130, Add updated top-level drawing to include taxi light with 05/16/2018 M. - Page 3 TABLE OF CONTENTS 0010-0004 SunSpot 46 HX-LX Installation Rev_I.docx 3 of 7...
-
Page 4: Model Numbers
Model Numbers Voltage Current Power Weight Model Part Number Description (Vdc) (Amps) (oz) SunSpot 46 HX 01-2130-LX Landing 6.5 @ 14V 9-30.3 SunSpot 46 LX 3.0 @ 28V 01-2130-HX Landing w/Pulse Modes of operation (H-Lights only) Mode Switch Position Mode Switch Position Function Open... - Page 5 Installation Procedures Reference airframe manufacturer’s maintenance manual and remove light covers to gain access to lamp assembly(s) and bracket(s) This installation procedure is for single or multiple light installations. Wiring diagrams are provided for single and dual light installations. For lights without pulse, existing aircraft wiring, switches and breakers may be utilized.
-
Page 6: Wiring Diagrams
Wiring Diagrams Wiring Diagram for Single SunSpot 46 LX (without Pulse) Photo 4-1 Note: Fuse/breaker should be rated for wire size per AC43.13-1B Wiring Diagram for Single SunSpot 46 HX (with Pulse) Photo 4-2 Note: Fuse/breaker should be rated for wire size per AC43.13-1B 0010-0004 SunSpot 46 HX-LX Installation Rev_I.docx 6 of 7... - Page 7 Wiring Diagram for Dual SunSpots with Pulse Photo 4-3 Note: Fuse/breaker should be rated for wire size per AC43.13-1B If lights are installed in close proximity (within ~2’ of each other), use sync circuit, AeroLEDs PN 00-8120. 0010-0004 SunSpot 46 HX-LX Installation Rev_I.docx 7 of 7...
