SMC Networks SMCGS50C-SMART - FICHE TECHNIQUE Product Overview page 2

Features
PHYSICAL PORTS
48 10/100/1000BASE-T RJ-45 ports
2 Gigabit Ethernet SFP slots
(SFP ports support dual speed 100/1000BASE-X)
PERFORMANCE
Switching Capability: 100Gbps
Packet Buffer Size: 512KB
MAC Address Table: 8K
Flash: 16MB
L2 FEATURES
Auto-negotiation for port speed and duplex mode
Flow Control:
 IEEE 802.3x for full-duplex mode
 Back-Pressure for half-duplex mode
Spanning Tree Protocol:
 IEEE 802.1D Spanning Tree Protocol (STP)
 IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
 STP Auto Edge
VLANs:
 Supports 4K IEEE 802.1Q VLANs
 Port-based VLANs
 Voice VLAN
 Private VLAN
Link Aggregation:
 Static Trunk
 IEEE 802.3ad Link Aggregation Control Protocol
 Trunk groups: 25 trunk links: Up to 8 ports
IGMP Snooping:
IGMP snooping v1/v2/v3
 IGMP immediate leave
 Supports jumbo frames up to 10 KB
QoS FEATURES
Priority Queues: 8 hardware queues per port
Traffic classification based on IEEE 802.1p CoS, DSCP,
Supports WRR, Strict scheduling, or hybrid mode
Rate Limiting
 Ingress: Resolution 16 Kbps
 Egress: Resolution 16 Kbps
SECURITY
Port security: static and dynamic
Supports IEEE 802.1X port based and MAC-based
EAPOL transparent
MAC authentication
Web authentication
HTTPS/SSL
SSH v1.5/v2.0
MAC Filter/IP Filter
DHCP Snooping
MANAGEMENT
Switch Management:
 Web management
 SNMP v1/v2/v3
Firmware and Configuration:
upgrade/downgrade via TFTP/HTTP
Supports DHCP Client
Supports LLDP (802.1ab) and LLDP-MED
RMON (groups 1, 2, 3, and 9)
MANAGEMENT
Port mirroring: one to one and many to one
Event log: local flash, syslog, remote server (RFC3164) and SMTP
(RFC821)
SNTP (IPv4/IPv6)
Loop detection and prevention
UPnP
Cable diagnostics
IPv6 management:
 IPv4/IPv6 dual protocol stack
 IPv6 address types: unicast/multicast
 IPv6 Ping/tracert
 ICMPv6 and ICMPv6 redirect
 IPv6 neighbor discovery
 IPv6 stateless auto config/manual config
 IPv6 Telnet/SNMP/HTTP/DHCP
MECHANICAL
Dimensions (W x D x H)
43 x 25 x 4.4 cm
Weight: TBD
LED Indicators: Port, Uplink, System, Diagnostic
POWER SUPPLY
AC Power
 100 to 240 V, 50-60 Hz, 0.5A
Power Supply
 Internal, auto-ranging transformer: 100 to 240 VAC, 47 to 63 Hz
Power Consumption
 20 Watts for System Power
ELECTROMAGNETIC COMPATIBILITY
CE Mark
FCC Class A
EN 55022 (CISRP 22) Class A
EN 61000-3-2/3
ENVIRONMENTAL SPECIFICATIONS
Temperature:
 -0°C to 50°C (standard operating)
 -40°C to 70°C (non-operating)
Humidity: 10% to 90% (non-condensing)
Vibration: IEC 68-2-36, IEC 68-2-6
Shock: IEC 68-2-29
Drop: IEC 68-2-32
SAFETY
CSA (CSA 22.2 NO 60950-1 & UL 60950-1)
CB (IEC/EN60950-1)
WARRANTY
Please check www.smc.com for the warranty terms in your country.
