- Page 1 USER MANUAL AND PRODUCT SPECIFICATIONS SM-130F U N D E R - C O U N T E R BEVERAGE COOLER...
-
Page 3: Table Of Contents
CONTENTS WARRANTY, SERVICE AND SUPPORT Warranty Registration Service and Support IMPORTANT SAFETY INFORMATION Before Using Your Appliance Critical Safety Information For Your Safety INSTALLATION INSTRUCTIONS Accessories Included Control Panel MAINTENANCE Cleaning the Interior Cleaning the Exterior ENERGY SAVING TIPS TROUBLESHOOTING... -
Page 4: Warranty, Service And Support
Register your SnoMaster 100L Should an instance arrive where Sub-Zero Under-Counter Beverage you require assistance, contact Cooler (SM-130F) now for warranty, our service team: and allow us to provide you with the best possible after sales service: • Please log onto our website at www.snomaster.co.za... -
Page 5: Important Safety Information
SnoMaster – 100L Sub-Zero Under-Counter Beverage Cooler (SM-130F). Please read this manual carefully before use and follow all safety information and instructions. It is recommended to keep this manual for easy reference so that you are familiar with the... - Page 6 • Unless specifically recommended in this manual, do not attempt to repair or replace any part of the appliance. All other servicing should be referred to a qualified technician. • The appliance needs to be levelled for optimal operation. You can adjust the appliance feet to level it +- 10mm.
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Before installing your new appliance, please read all safety instructions in this manual and follow the installation instructions below: ACCESSORIES INCLUDED Please check if all the accessories shown below are included: Please remove the appliance from the box, ensure all packaging materials, stickers, and films are removed from the product and any additional cords. -
Page 8: Control Panel
CONTROL PANEL SETTING THE DIGITAL THERMOSTAT (FIRST TIME USE) 1 LED Light On/Off Switch Set Temperature Indicator 2 LED Display Lock Switch Current Set Temperature Indicator 3 Set Temperature Switch Thermal Cycling Indicator Open 4 Turbo Mode Switch (1 Hour) Door Open Indicator 5 Party Mode Switch (6 Hours) 10 Locked LED Display Indicator... -
Page 9: Turbo Function
DIGITAL THERMOSTAT SETTINGS On the digital display, located on the front of the door; THERMOSTAT SETTINGS: -5°C is the lowest temperature setting (Sub Zero) 22°C is the highest temperature setting TURBO FUNCTION The Turbo function is designed for use when restocking the appliance. It rapidly lowers the temperature to -5°C for one hour, ensuring a swift cool-down of beverages by bringing the interior temperature down. -
Page 10: External Cleaning
DOOR INDICATOR A beeping sound will be heard if the door has been open for longer than 1 minute. SURGE PROTECTOR PLUG To avoid electrical surges, it is advised to use a surge protector plug. (Please note that this must be purchased separately and does not come with the unit.) MAINTAINENCE To ensure safety, remember to always disconnect the appliance... -
Page 11: Food Storage
FOOD STORAGE • The appliance is suitable for short-term storage of fresh food. The temperature inside varies depending on the amount of food stored. • To maintain good cooling efficiency and save energy, we recommend less frequent opening and closing of the appliance door. •... - Page 12 • Not enough ventilation around the unit. • Check if Thermostat probe is not faulty, if so please contact SnoMaster support to replace. Moisture forms on the • Hot and humid weather usually in the coastal inside/ outside walls locations increases the internal rate of condensation.
- Page 13 TROUBLESHOOTING PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Unusual noises/ • Ensure appliance is positioned level on the ground. Gurgling or Cracking • Caused by the ow of refrigerant when each cooling Noises cycle ends. • Check if there is enough spacing around the appliance and ensure it is not touching other items.
- Page 14 SM-130F EXPLODED DIAGRAM...
- Page 15 SM-130F EXPLODED DIAGRAM Top cover Evaporator Top cover support foam SS screw ST4.2X16 Door hinge cover Defrost heating wires(220V) Screw M5X16 Lower door axis sleeve Upper door hinge front feet Lower door hinge （S.S.) Screw ST4.2X16 Top cover fixed plate...
- Page 16 CAPE TOWN LIFESTYLE CENTRE CENTRE & SERVICE CENTRE & SERVICE CENTRE 49 Koornhof Road 31 Stella Road Meadowdale Montague Gardens Germiston, 1614 Cape Town, 7441 011 392 5315 / 3147 021 100 5695 info@snomaster.co.za info@snomaster.co.za snomaster.co.za @SnoMasterSA SnoMaster SA snomaster_south_africa @SnoMaster...
