- Page 1 USER MANUAL AND PRODUCT SPECIFICATIONS VT-41PRO BEVERAGE COOLER...
-
Page 3: Table Of Contents
CONTENTS WARRANTY, SERVICE AND SUPPORT Warranty Registration Service and Support IMPORTANT SAFETY INFORMATION Before Using Your Appliance Critical Safety Information For Your Safety INSTALLATION INSTRUCTIONS Accessories Included Control Panel MAINTENANCE Cleaning the Interior Cleaning the Exterior ENERGY SAVING TIPS TROUBLESHOOTING... -
Page 4: Warranty, Service And Support
Register your SnoMaster 145L Should an instance arrive where Under-Counter Beverage Cooler you require assistance, contact VT-41PRO now for warranty, and our service team: allow us to provide you with the best possible after sales service: • Please log onto our website at www.snomaster.co.za... -
Page 5: Important Safety Information
• If the appliance power supply cord is damaged, it must be replaced by SnoMaster, its approved agent, or a similarly qualified person to prevent any hazard. • Cleaning and maintenance should be supervised by adults, especially if children are involved. - Page 6 • Unless specifically recommended in this manual, do not attempt to repair or replace any part of the appliance. All other servicing should be referred to a qualified technician. • The appliance needs to be levelled for optimal operation. You can adjust the appliance feet to level it +- 10mm.
-
Page 7: Product Features
PRODUCT FEATURES INTERNAL LIGHT SELECTION | DIGITAL THERMOSTAT | TEMPERED GLASS DOOR (LEFT HINGED ONLY) | DOOR LOCK | BROTHER / SISTER COMBINATION WITH THE VT-46PRO | FRONT VENTING SPECIFICATIONS: • Dimensions (mm) Unit: (H) 875 (W) 595 (D) 570 •... - Page 8 3 x DOOR LOCK 1 x LOCK FIX PANEL KEYS • Please remove the appliance from the box, ensure all packaging materials, stickers, and films are removed from the product and any additional cords. • Ensure the appliance is placed on a stable, level floor for quieter operation and be sure that the floor is strong enough to support the appliance weight when fully loaded.
- Page 9 HOW TO REVERSE DOOR • Use screwdriver to unscrew the 6 screws which are connected to the appliance and the removable hinge. • Remember to secure the bottom of the door with your hand to avoid the door falling. • Gently place all attachments on a level area to avoid losing any items. •...
-
Page 10: Control Panel
CONTROL PANEL Power Upper Temp Zone Light Indicator Lower Temp Zone Temp Up/Down Door Lock On/O Temp Range Set THERMOSTAT SETTINGS Lowest temperature setting (low 2°C) Highest temperature setting (high 20°C) POWER ON/OFF CONTROL • Press to turn the control panel back light buttons if they are off. •... -
Page 11: Interior Lighting On/Off Control
INTERIOR LIGHTING ON/OFF CONTROL Your wine cellar comes equipped with 3 different lighting options: Red, Blue, or a Red & Blue cycle where the colour changes every 10 seconds. Press the light button once and the lights will run on a 10-second cycle, alternating between Red &... -
Page 12: Internal Cleaning
SURGE PROTECTOR PLUG To avoid electrical surges, it is advised to use a surge protector plug. (Please note that this must be purchased separately and does not come with the unit.) MAINTAINENCE To ensure safety, remember to always disconnect the appliance from the power supply before any form of maintenance or cleaning. -
Page 13: Food Storage
FOOD STORAGE • The appliance compartment is suitable for short-term storage of fresh food. The temperature inside varies depending on the amount of food stored. • To maintain good cooling efficiency and save energy, we recommend less frequent opening and closing of the appliance door. - Page 14 • Not enough ventilation around the unit. • Check if Thermostat probe is not faulty, if so please contact SnoMaster support to replace. Moisture forms on the • Hot and humid weather usually in the coastal inside/ outside walls locations increases the internal rate of condensation.
- Page 15 TROUBLESHOOTING PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Unusual noises/ • Ensure appliance is positioned level on the ground. Gurgling or Cracking • Caused by the ow of refrigerant when each cooling Noises cycle ends. • Check if there is enough spacing around the appliance and ensure it is not touching other items.
- Page 16 VT-41PRO EXPLODED DIAGRAM Dry Filter Power Cord Mainboard AC Cable Door Hinge Upper/Left Evaporator Heater NTC Sensor Fan_Evaporator Air Deflector Shelf Shelf Stopper Lamp PCB Backlight Board Operation Panel PCB Door Gasket Front Louver Door Foot Door Shaft Sleeve Door Hinge_Lower/Left...
- Page 17 CAPE TOWN LIFESTYLE CENTRE CENTRE & SERVICE CENTRE & SERVICE CENTRE 49 Koornhof Road 31 Stella Road Meadowdale Montague Gardens Germiston, 1614 Cape Town, 7441 011 392 5315 / 3147 021 100 5695 info@snomaster.co.za info@snomaster.co.za snomaster.co.za @SnoMasterSA SnoMaster SA snomaster_south_africa @SnoMaster...
