Rear Components

Ref Component
Power Connector
Voltage Switch
Ventilation
Opening
Reset Switch
RJ-45 Connectors
0/1/2/3
USB Ports
9
Description
Connects to the power cord.
Select the voltage matching your local standard setting.
Maintain proper operating temperature. Do not cover or
block the openings.
Allows you to reset the system to the factory default
username, password, and DHCP.
Connects the LAN cable to any one of the four
connectors.
Connect USB devices, such as a USB disk, printer, and/or
USB-UPS.
