Ref Component
Network Indicator Shows the current network status.
RAID Indicator
RAID
DIAG
Hard Disk Drive
Compartment
Disk Information
Indicator
STATUS
DIAG
5
Description
Glows green at 10/100 Mbps or blue at 1000 Mbps when
system is connected to the network.
Blinks green or blue to indicate system is trying to
establish a network connection.
Shows the current RAID status.
Glows blue to indicate RAID function is implemented.
Blinks blue to indicate RAID function is rebuilding the
hard disk drive.
Glows red to indicate RAID function is inactive or
malfunctioning.
Inside are four hard disk drive slots.
Shows the current hard disk drive status.
Glows blue to indicate hard disk drive is at Standby mode.
Blinks blue to indicate hard disk drive read/write
function.
Glows red to indicate hard disk drive is inactive or
malfunctioning.
