- Page 1 INSTALLATION GUIDE eGrabber Installing PC3629 Coaxlink CXP-12 to QSFP+ Converter © EURESYS S.A.2024 - Document D222ET-PC3629 Installation Guide-eGrabber-24.12.1.2193 built on 2024-12-17...
- Page 2 1. Installation Box content Quantity Item PC3629 Coaxlink CXP-12 to QSFP+ Converter 2-pin 5.08mm pitch terminal plug 3629 Coaxlink CXP-12 to QSFP+ Converter Installation Guide Mounting The out-of-the box product is ready for a desktop or a wall-mount usage. The enclosure is fitted with 4 holes, 2 on each side, that can be used to attach the product on any flat surface.
- Page 3 Use exclusively certified 24V DC power sources. □ Check power supply wiring before applying power. □ NOTE: PC1676 AC-DC Power Adapter, 24V, 160W, a 24V DC 160 W universal power supply, is available as accessory CoaXPress input Connect one CoaXPress camera with 1, 2 or 4 connections to the CoaXPress input connector: inner outer...
- Page 4 Notice for Korea Registered products under the Clause 3, Article 58-2 of Radio Waves Act: Registration Number Euresys Products R-R-EUr-PC3629 PC3629 Coaxlink CXP-12 to QSFP+ Converter This product is in conformity with the European Union 2015/863 (ROHS3) Directive, that stands for "the restriction of the use of certain hazardous substances in electrical and electronic...
