Euresys PC1656 Handbook

Firmware version 5.x. high definition video ip encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PC1656 Picolo.net HD4 Handbook
Firmware Version 5.x
EURESYS s.a. 2013 - Document version 1.0.288 built on 2013-02-15
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC1656 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euresys PC1656

Summary of Contents for Euresys PC1656

  • Page 1 PC1656 Picolo.net HD4 Handbook Firmware Version 5.x EURESYS s.a. 2013 - Document version 1.0.288 built on 2013-02-15 ©...
  • Page 2 PC1656 Picolo.net HD4 Handbook Disclaimer EURESYS s.a. shall retain all property rights, title and interest of the documentation of the hardware and the software, and of the trademarks of EURESYS s.a. All the names of companies and products mentioned in the documentation may be the trademarks of their respective owners.

  • Page 3: Table Of Contents

    PC1656 Picolo.net HD4 Handbook Contents Contents Short Description ............................Mechanical Specification ........................Product Pictures............................... 8 Dimensions and Weight............................9 Mounting Methods..............................9 Desktop Mount..............................10 Wall Mount................................10 DIN-Rail Mount..............................14 Connectors, LED Indicators, and Switches......................15 Location and Markings............................15 Connectors................................
  • Page 4 PC1656 Picolo.net HD4 Handbook Contents Video Encoder Specification..........................37 Audio Specifications............................... 39 Streaming Specifications............................40 Media Transport Protocols..........................40 RTP Transport Modalities........................... 41 RTP Transport Media Types..........................41 Network Specifications............................42 IP Address Allocation Methods.......................... 42 TLS Protocol............................... 43 System Integration Specifications.......................... 44 Temperature Monitor..............................
  • Page 5 PC1656 Picolo.net HD4 Handbook Contents Users Management Page............................87 Hidden Pages................................. 90 Check Status Page.............................90 Open Source Licenses Page..........................91 Video Status Page..............................92 Product Maintenance ..........................Firmware Upgrade..............................93 Configuration Backup and Restore........................93 Appendix ................................About ONVIF................................94 Detailed Access Policy - Firmware version 5.0..................... 95 Optional ONVIF Capabilities - Firmware version 5.0...................103...

  • Page 6: Short Description

    PC1656 Picolo.net HD4 Handbook Short Description Short Description Picolo.net HD4 is a four-channel High Definition Video IP encoder. Video Features Picolo.net HD4 captures high-definition video from up to four HD-SDI or HDcctv 1.0 video sources. It supports 720p and 1080p progressive-scan formats, and a large set of frame rates for both 50Hz and 60Hz regions.
  • Page 7 PC1656 Picolo.net HD4 Handbook Short Description The streaming is controlled by means of the RTSP protocol. Each RTSP session may include: One encoded video stream from any of the Video Encoders One encoded audio stream from any of the Audio Encoders...

  • Page 8: Mechanical Specification

    When fitted with one or two Audio Module for Picolo.net HD4, the front side holds the audio connectors, the video connectors, and the "Video Present" green LED indicators. The top side is embossed with the Euresys logo. The rear side holds the power input, I/O, and LAN connectors together with the Power OK and LAN status LED indicators Picolo.net HD4 without audio module(s) - Front view...

  • Page 9: Dimensions And Weight

    PC1656 Picolo.net HD4 Handbook Mechanical Specification Picolo.net HD4 Rear view Dimensions and Weight Dimensions Value [mm] Value [inches] Characteristic 8.27 Length 6.85 Width 2.09 Thickness - Desktop or wall mount 2.52 Thickness - DIN-rail mount Weight Value [g] Value [lb] Characteristic 1.81...

  • Page 10: Desktop Mount

    PC1656 Picolo.net HD4 Handbook Mechanical Specification Desktop Mount Picolo.net HD4 "Desktop" The out-of-the box product, namely the Picolo.net HD4 "Desktop", is ready for a desktop usage. The baseplate and the DIN-rail clip may be discarded. The enclosure is designed in such a way that its bottom side faces the table. The four embossings on the bottom side of the plastic caps act as anti-skid feet, and avoid direct contact between metallic parts and the table.
  • Page 11 The enclosure and the baseplate are designed in such a way that the enclosure can be mounted on a vertical flat surface with three possible orientations: Horizontal: the BNC video connectors are facing rightwards and the Euresys logo is horizontal. Vertical Downwards: the BNC video connectors and the Euresys logo are oriented downwards.
  • Page 12 PC1656 Picolo.net HD4 Handbook Mechanical Specification Note. The void area around the baseplate is required to allow easy installation and removal of the enclosure on the baseplate, and easy wiring on both the rear and front sides. Wall Mount - Vertical Orientations...
  • Page 13 PC1656 Picolo.net HD4 Handbook Mechanical Specification 100 mm 4’’ 150 mm 6’’ 100 mm 4’’ Wall mount - Vertical...

  • Page 14: Din-Rail Mount

    PC1656 Picolo.net HD4 Handbook Mechanical Specification Note. The void area around the baseplate is required to allow easy installation and removal of the enclosure on the baseplate, and easy wiring on both the rear and front sides. DIN-Rail Mount To mount Picolo.net HD4 on a DIN rail, the DIN-rail clip must be installed on the back side of the baseplate, and the enclosure must be hooked-up on the baseplate like for the wall-mount usage.

  • Page 15: Connectors, Led Indicators, And Switches

    PC1656 Picolo.net HD4 Handbook Mechanical Specification Connectors, LED Indicators, and Switches Location and Markings Front panel layout HDcctv 1.0 Input 1 Input 2 Input 3 Input 4 Present Present Present Present Picolo.net HD4 HDcctv 1.0 Input 1 Input 2 Input 3...

  • Page 16: Connectors

    PC1656 Picolo.net HD4 Handbook Mechanical Specification Connectors HDcctv Input 1 Connector 2-pin female receptacle, right-angled PCB-mount, BNC connector Signal Usage HDcctv IN1 HDcctv input 1 Center Chassis ground Outer HDcctv Input 2 Connector 2-pin female receptacle, right-angled PCB-mount, BNC connector...
  • Page 17 PC1656 Picolo.net HD4 Handbook Mechanical Specification HDcctv Input 4 Connector 2-pin female receptacle, right-angled PCB-mount, BNC connector Signal Usage HDcctv IN4 HDcctv input 4 Center Chassis ground Outer LAN Connector 8-pin RJ45 jack connector with 2 built-in LED indicators Signal...
  • Page 18 PC1656 Picolo.net HD4 Handbook Mechanical Specification COM Connector 1 2 3 4 4-pin 3.5mm pitch terminal socket Signal Usage SHLD Chassis ground Signal ground 485+ Transmit/Receive - Positive terminal 485- Transmit/Receive - Negative terminal ALARM I Connector 1 2 3 4 4-pin 3.5mm pitch terminal socket...
  • Page 19 PC1656 Picolo.net HD4 Handbook Mechanical Specification RELAY I Connector 1 2 3 4 4-pin 3.5mm pitch terminal socket Signal Usage Relay Output 1 - Terminal A Relay Output 1 - Terminal B Relay Output 2 - Terminal A Relay Output 2 - Terminal B...
  • Page 20 PC1656 Picolo.net HD4 Handbook Mechanical Specification Sleeve Ring Black TRS 3.5mm jack socket connector Signal Usage Unused Ring AUDIO IN1 Analog audio input 1 Chassis ground Sleeve Audio Input 2 Connector This connector is optional. Sleeve Ring Black TRS 3.5mm jack socket connector...
  • Page 21 PC1656 Picolo.net HD4 Handbook Mechanical Specification Audio Input 4 Connector This connector is optional. Sleeve Ring Black TRS 3.5mm jack socket connector Signal Usage Unused Ring AUDIO IN4 Analog audio input 4 Chassis ground Sleeve Audio Output 1 Connector This connector is optional.
  • Page 22 PC1656 Picolo.net HD4 Handbook Mechanical Specification Sleeve Ring Black TRS 3.5mm jack socket connector Signal Usage Unused Ring AUDIO OUT2 Analog audio output 2 Chassis ground Sleeve Audio Output 3 Connector This connector is optional. Sleeve Ring Black TRS 3.5mm jack socket connector...

  • Page 23: Led Indicators And Switches

    PC1656 Picolo.net HD4 Handbook Mechanical Specification LED Indicators and Switches LED indicators Picolo.net HD4 LED indicators Location Type and Colour Marking Function Front panel Circular green LED HDcctv Input 1 Present HDcctv/HD-SDI signal status Front panel Circular green LED HDcctv Input 2 Present...
  • Page 24 PC1656 Picolo.net HD4 Handbook Mechanical Specification Device Status LED State Meaning LED State Meaning Power OFF or Operating System kernel startup Fast blink (10 Hz) 50% ON time Operating System Kernel startup completed, system boot in progress System is Ready...

  • Page 25: Electrical Specification

    PC1656 Picolo.net HD4 Handbook Electrical Specification Electrical Specification Power Input Picolo.net HD4 is powered from an external single voltage DC power source. Operating characteristics Min. Typ. Max. Unit Operating characteristics 14.4 Voltage range (pre-series devices) Voltage range (full-spec devices) Power consumption – normal operation Note.

  • Page 26: Com I/O

    PC1656 Picolo.net HD4 Handbook Electrical Specification Operating characteristics Min. Typ. Max. Unit Operating characteristics Peak-to-peak signal amplitude (short cable) 1.485 Gbps Serial data rate PLL loop filter bandwidth Achievable cable length with Belden 1694 coaxial cable Ω Input impedance Return loss measured over the 5MHz to 2.25GHz...

  • Page 27: Alarm Inputs

    PC1656 Picolo.net HD4 Handbook Electrical Specification Absolute Maximum Ratings Absolute maximum ratings Min. Typ. Max. Unit Absolute maximum ratings DC voltage Driver output current Note. Exceeding the above limits may irreversibly damage Picolo.net HD4. Alarm Inputs Picolo.net HD4 has 4 identical Alarm Input ports.

  • Page 28: Relay Outputs

    PC1656 Picolo.net HD4 Handbook Electrical Specification Relay Outputs Picolo.net HD4 has 4 identical Relay Output ports. Each port has two pins named RxA and RxB respectively, where x is a number ranging from 1 to 4. This output port emulates a potential-free and polarity-free solid-state contact. It is capable of switching both AC- and DC-powered resistive loads.

  • Page 29: Using Relay Outputs

    PC1656 Picolo.net HD4 Handbook Electrical Specification Relay Output port U-I diagram Absolute Maximum Ratings Absolute Maximum Ratings Test Condition Min. Typ. Max. Unit Contact open Absolute maximum DC voltage Contact open Absolute maximum AC voltage Contact closed -100 +100 Absolute maximum DC current...
  • Page 30 PC1656 Picolo.net HD4 Handbook Electrical Specification The load Circuit Diagram Power Supply Operating the relay output circuit requires an external power source. The power source can be either DC or AC since the relay output port is capable of switching current of both polarities.

  • Page 31: Audio Inputs

    PC1656 Picolo.net HD4 Handbook Electrical Specification Audio Inputs Audio Module for Picolo.net HD4 has 2 identical analog audio input ports. Operating Characteristics Min. Typ. Max. Unit Operating characteristics 1.35 Full-scale input voltage kΩ Input impedance (@ 1 kHz) Sampling frequency Absolute Maximum Ratings Min.

  • Page 32: Environmental Specification

    PC1656 Picolo.net HD4 Handbook Environmental Specification Environmental Specification Operating Conditions The following requirements are applicable to Picolo.net HD4 during operating conditions: Requirements Min. Max. Unit Requirement during operating conditions °C Ambient air temperature range +131 °F % RH non-condensing Ambient humidity range Dissipated power Typ.

  • Page 33: Compliance

    PC1656 Picolo.net HD4 Handbook Environmental Specification Compliance Electromagnetic Picolo.net HD4 complies with: The European Council EMC Directive 2004/108/EC The Unites States FCC rule 47 CFR 15 It has been tested and found to comply with the following standards: Radiated emission...

  • Page 34: Functional Specification

    PC1656 Picolo.net HD4 Handbook Functional Specification Functional Specification Video Specifications Video Processing Chain The processing chain of Picolo.net HD4 is composed of the following elements: 4 video sources 4 scalers 12 H.264 encoders The video source implements an HD-SDI receiver capable of automatically identifying and decoding 720p and 1080p video signals at various frame rates.

  • Page 35: Video Source Specification

    PC1656 Picolo.net HD4 Handbook Functional Specification Video encoder #3 Video encoder #2 Encoded video bit stream #3 Video source Video encoder #1 Encoded video bit stream #2 HD-SDI or Frame rate control HDcctv 1.0 signal Encoded video bit stream #1...
  • Page 36 PC1656 Picolo.net HD4 Handbook Functional Specification 720p Frame Rates 720p Frame Rate [fps] Data Rate [Gbit/s] 23.98 1.485/1.001 1.485 1.485 29.97 1.485/1.001 1.485 1.485 59.94 1.485/1.001 1.485 1080p Frame Rates 1080p Frame Rate [fps] Data Rate [Gbit/s] 23.98 1.485/1.001 1.485 1.485...

  • Page 37: Video Encoder Specification

    PC1656 Picolo.net HD4 Handbook Functional Specification No CRC errors are detected by the SDI receiver Video Encoder Specification Encoding Method The following video encoding methods are available: H.264 JPEG H.264 Video Encoder Specification Resolution The H.264 encoder delivers images in one of the following resolutions: H.264 Encoding Resolution...
  • Page 38 PC1656 Picolo.net HD4 Handbook Functional Specification Rate Control - Frame Rate The EncodingInterval and FrameRateLimit properties of the VideoEncoderConfiguration object determine the frame rate of the encoded video stream: FrameRateLimit is an integer value expressed in frames per second [fps] specifying the upper limit of the frame rate of the encoded video stream.

  • Page 39: Audio Specifications

    PC1656 Picolo.net HD4 Handbook Functional Specification JPEG Video Encoder Specification Resolution The JPEG encoder delivers images in one of the following resolutions: JPEG Encoding Resolution Width Height Short Name Image Aspect Ratio Remark 1920 1080 Full HD 16:9 Native for 1080p...

  • Page 40: Streaming Specifications

    PC1656 Picolo.net HD4 Handbook Functional Specification The audio source interface that digitizes the analog audio signal The audio encoder that encodes the digital audio signal and performs the time-stamping Source interface Description Characteristics 2 single-channel Number of analog audio input ports...

  • Page 41: Rtp Transport Modalities

    PC1656 Picolo.net HD4 Handbook Functional Specification Media Transport Control Protocol Picolo.net HD4 uses the Real-time Streaming Protocol - RTSP - as the control protocol for all the flavors of RTP streams. RSTP is described by RFC 2326. It allows controlling another protocol (usually RTP), implementing commands such as Play (start a stream), Pause (pause a stream) and Describe (describe the streams controlled by the current RTSP session).

  • Page 42: Network Specifications

    PC1656 Picolo.net HD4 Handbook Functional Specification RTP Payload Format for JPEG-compressed Video The RFC 2435 describes the methodology used to encapsulate JPEG-compressed Video data in a RTP stream. Network Specifications Network Description Characteristics 1 x Ethernet 10BASE-T/100BASE-TX/1000BASE-T, automatic speed negotiation...

  • Page 43: Tls Protocol

    PC1656 Picolo.net HD4 Handbook Functional Specification At Power On, providing that the "LLA method" is Enabled, the Picolo.net HD4 negotiates with the peer device(s) a unique IP address in the 169.254.0.0/16 special block of IPv4 addresses reserved for that purpose.

  • Page 44: System Integration Specifications

    PC1656 Picolo.net HD4 Handbook Functional Specification System Integration Specifications System integration Characteristics Description ONVIF Profile S + Proprietary web services Application Programming Interface 4 x non-isolated polarity insensitive inputs for closing contacts or electronic sensor Alarm inputs with CMOS digital outputs...

  • Page 45: Auto Setup Profiles

    The generated ONVIF Media Profiles bind the corresponding Video Source object to a particular combination of Video Source Configuration, Video Encoder Configuration, and PTZ Configuration objects. Note. Euresys reserves the rights to modify the composition of the collection and/or the settings of the configuration objects in future firmware upgrades.

  • Page 46: Access Control

    PC1656 Picolo.net HD4 Handbook Functional Specification Time Zones and Daylight Savings Time Picolo.net HD4, supports time zone and daylight savings time settings. To configure the time zone, the user must provide the appropriate POSIX.1 TZ string describing the UTC offset and, when applicable, the daylight saving rule.
  • Page 47 PC1656 Picolo.net HD4 Handbook Functional Specification In addition to the access rights of User-level users, Operator-level have access to the following service class: The "ACTUATE" class: a set a service functions affecting the runtime behaviour. An Administrator-level user has access to all function classes. It has an exclusive access to the following service classes: The "READ_SYSTEM_SECRET"...

  • Page 48: Software Specification

    PC1656 Picolo.net HD4 Handbook Software Specification Software Specification Software Components Picolo.net HD4 is a Network Video Transmitter (NVT) device as defined by ONVIF. Components Overview...
  • Page 49 PC1656 Picolo.net HD4 Handbook Software Specification ONVIF Media Profiles The ONVIF Media Profile can be viewed as the object interconnecting the different types of configuration objects. Each one may contain configuration for: Up to one Video Source Up to one Video Stream...

  • Page 50: Client Interfaces

    PC1656 Picolo.net HD4 Handbook Software Specification To stream video, an ONVIF Media Profile must be associated to one VideoSourceConfiguration object and one VideoEncoderConfiguration object. To stream audio, an ONVIF Media Profile must be associated to one AudioSourceConfiguration object and one AudioEncoderConfiguration object.

  • Page 51: Web Services

    PC1656 Picolo.net HD4 Handbook Software Specification Web Services ONVIF Web Services The Web Services API of Picolo.net HD4 provides the following ONVIF web services: ONVIF Device service ONVIF Media service ONVIF Event service ONVIF PTZ service ONVIF Device IO service Proprietary Web Services The Proprietary Web Services API of Picolo.net HD4 complements the Web Services API.

  • Page 52: Proprietary Device Service

    PC1656 Picolo.net HD4 Handbook Software Specification ONVIF Device Service - Mandatory Discovery Capabilities The ONVIF Device Service provides the following mandatory discovery capabilities for an NVT device. Namely: Target Service role (WS-Discovery) on port 80 Discoverable and non-discoverable modes Hello, Status changes, Probe and Resolve, and Bye Messages...

  • Page 53: Proprietary Media Service

    PC1656 Picolo.net HD4 Handbook Software Specification Configure audio sources and audio encoders Configure metadata streams Request stream URI ONVIF Media Service - Mandatory Codec Capabilities The ONVIF Media Service provides the following mandatory codecs capabilities for an NVT device. Namely: JPEG video encoding - QVGA resolution G.711 µ-law audio encoding...

  • Page 54: Onvif Ptz Service

    PC1656 Picolo.net HD4 Handbook Software Specification The ONVIF event service allows to: Find out what notifications a device support and what information they contain Poll the device to check for the occurrence of events using the Real-time Pull-Point Notification Interface...

  • Page 55: Proprietary Ptz Service

    PC1656 Picolo.net HD4 Handbook Software Specification Proprietary PTZ service The proprietary PTZ service extends the ONVIF PTZ service. WSDL filename: hd4PTZProprietary.wsdl XML schema: hd4PTZProprietary.xsd The proprietary PTZ service extends the ONVIF PTZ service to manage up to 4 PTZ cameras sharing the COM IO port of Picolo.net HD4.

  • Page 56: Onvif Device Io Service

    PC1656 Picolo.net HD4 Handbook Software Specification The request message GetPelcoNodeAddressConfigurationRequest specifies the token of the PTZ node configuration in a XML data structure of type ConfigurationToken The response message GetPelcoNodeAddressConfigurationResponse returns the configuration of the PTZ node in a XML data structure of type: eur:PelcoNodeAddressConfiguration.

  • Page 57: Proprietary Device Io Service

    PC1656 Picolo.net HD4 Handbook Software Specification Number of video sources: 4 Picolo.net HD4 supports the following Device IO features for relay outputs: DeviceIORelayOutputs DeviceIORelayOutputsMonostableClosed DeviceIORelayOutputsMonostableOpen DeviceIORelayOutputsMonostable DeviceIORelayOutputsBistableClosed DeviceIORelayOutputsBistableOpen DeviceIORelayOutputsBistable Proprietary Device IO service The proprietary Device IO service extends the ONVIF Device IO service.
  • Page 58 PC1656 Picolo.net HD4 Handbook Software Specification State type This type is composed of: Element <State> of type eur:InputStateEnum The element <State> specifies the state of the alarm input port. Possible values are: OPEN: the alarm input port has detected an high-impedance. Possible causes are:result of an open contact or an unused port.

  • Page 59: Web Pages Description

    PC1656 Picolo.net HD4 Handbook Web Pages Description Web Pages Description Home Page The Home Page of the Picolo.net HD4 Web Server is accessible at the following URL: http://[device_ip_address]/. It appears as follows: Picolo.net HD4 Web Server - Home Page The Home Page provides: General information about the device in the Device Information panel.
  • Page 60 PC1656 Picolo.net HD4 Handbook Web Pages Description Device Information Panel Device Information panel The Device Information Panel provides the following device information: Field name Field Description Model Product code and product name of the device Manufacturer Manufacturer name of the device...

  • Page 61: Home Page - Anonymous User

    PC1656 Picolo.net HD4 Handbook Web Pages Description A a snapshot image providing that the source corresponding to that camera is referenced by a properly configured ONVIF Media Profile. If this condition is missing, the image is replaced by a black background overlayed by a crossed rectangle.
  • Page 62 PC1656 Picolo.net HD4 Handbook Web Pages Description Home Page - Anonymous user Clicking on the [login] link opens the Login page. Login Page Login Page Login panel Field name Description Username User name Password User password Use advanced options Cross the checkbox if specific password derivations are required.

  • Page 63: Media Profiles Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Possible Password Derivations values are: Value Description None No password derivation. Default setting. Onvif 1.0 Password derivation according to ONVIF 1.0 specification. Onvif 1.0+ Password derivation according to ONVIF 1.02 (or later) specification.

  • Page 64: Media Profile Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Media Profile Page on page 64 Configurations Page on page 67 Media Profile Page The Media Profile page of the Picolo.net HD4 Web Server is relative to a single ONVIF Media Profile. It allows the...
  • Page 65 PC1656 Picolo.net HD4 Handbook Web Pages Description The Play Fullscreen button allowing the user to display the live video on the entire screen The Start Multicast button Clicking on the Play Fullscreen button enlarges the live video on the entire screen.
  • Page 66 PC1656 Picolo.net HD4 Handbook Web Pages Description Media Profile Video Encoder Configuration panel Audio Source Configuration panel Audio Encoder Configuration panel Media Profile PTZ Configuration panel Media Profile Metadata Configuration panel...

  • Page 67: Configurations Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description The configuration panels of the Media profile page allow to: View the composition of the profile and the characteristics their components Modify the composition of the profile by addition or deletion of components.
  • Page 68 PC1656 Picolo.net HD4 Handbook Web Pages Description The lower area of the panel shows the properties of the selected object: Field name Description Name The name of the VideoSourceConfiguration object Video Source - Name The name of the video source Video Source - Resolution The resolution [H x V] of the video source, e.g.
  • Page 69 PC1656 Picolo.net HD4 Handbook Web Pages Description Video Encoder Configurations panel - JPEG The lower area of the panels shows the properties of the selected object. Video Encoder Configurations panels - Common properties Field name Description Name The token name of the VideoEncoderConfiguration object, e.g. VideoEncoderConfiguration01 Encoding Used video codec.
  • Page 70 PC1656 Picolo.net HD4 Handbook Web Pages Description Video Encoder Configurations panels - H.264 specific properties Field name Description H264 - GOP Size Group of Pictures (or Video frames) length. H264 - H264 Profile The H.264 profile: baseline, main or high.
  • Page 71 PC1656 Picolo.net HD4 Handbook Web Pages Description The lower area of the panel shows the properties of the selected object: Field name Description Name The name of the AudioEncoderConfiguration object Encoding Used audio codec Bitrate The bit rate of the encoded audio stream...
  • Page 72 PC1656 Picolo.net HD4 Handbook Web Pages Description Metadata Configurations Panel Metadata Configurations panel The drop-down box in the upper area allows to select one MetadataConfiguration object. Clicking the Edit button opens the Metadata Configuration Edition page. The lower area of the panel shows the properties of the selected object:...

  • Page 73: Edit Video Encoder Configuration Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Edit Video Encoder Configuration Page The Edit Video Encoder Configuration Page allows the edition of the properties of the Video Encoder Configuration object. It shows a single panel: the Video Encoder Configuration panel.

  • Page 74: Edit Audio Encoder Configuration Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Video Encoder Configurations panels - Common properties Field name Description Token The token name of the VideoEncoderConfiguration object, e.g. VideoEncoderConfiguration01. This field cannot be edited. Name A friendly name given to the configuration. Default value = token name Encoding Video encoding method: H.264 or JPEG...

  • Page 75: Edit Metadata Configuration Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Audio Encoder Configuration Edition panel - H.264 encoding method Audio Encoder Configurations panel Field name Description Token The token name of the AudioEncoderConfiguration object, e.g. AudioEncoderConfiguration01. This field cannot be edited. Name A friendly name given to the configuration. Default value = token name Encoding Audio encoding method.

  • Page 76: Digital Inputs & Relay Outputs Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Metadata Configuration Edition panel Metadata Configuration panel Field name Description Token The token name of the MetadataConfiguration object, e.g. MetdataConfiguration01. This field cannot be edited. Name A friendly name given to the configuration. Default value = token name Events - Filter List of filtered event items.
  • Page 77 PC1656 Picolo.net HD4 Handbook Web Pages Description Digital Inputs Panel The Digital Inputs panel allows the user to view the configuration of DigitalInput objects. Digital Inputs panel The drop-down box in the upper area allows to select one DigitalInput object.
  • Page 78 PC1656 Picolo.net HD4 Handbook Web Pages Description Checking the Enable Events check box enables the event generation for that input. Digital Inputs States page The Digital Inputs States page displays a single panel allowing the user to view the state of all DigitalInput objects.

  • Page 79: Ptz Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description The lower area of the panel shows the properties of the selected object: Field name Description Properties - Mode The operating mode of the relay output. Possible values are: Monostable => After setting the state, the relay returns to its idle state after the specified time.
  • Page 80 PC1656 Picolo.net HD4 Handbook Web Pages Description Serial Port Configuration panel Serial Port Configuration panel The Serial Port Configuration panel shows the properties of the serial port: Field name Description Baud Rate The baud rate of the RS-485 asynchronous port...

  • Page 81: Device Management Page - Network Tab

    PC1656 Picolo.net HD4 Handbook Web Pages Description The PTZNodexx panels show the properties of the corresponding PTZNode: Field name Description Maximum Number of Presets Indicates the maximum number of presets supported by the PTZ protocol. 20 for Pelco-D protocol. Home Supported Indicates if the home command is supported by the PTZ protocol.
  • Page 82 PC1656 Picolo.net HD4 Handbook Web Pages Description IP Address Panel The IP Address panel allows to view and/or edit the following network properties: From DHCP: when checked, indicates that the IP address of Picolo.net HD4is obtained automatically using DHCP. IP: IP address assigned to Picolo.net HD4.

  • Page 83: Device Management Page - Time Tab

    PC1656 Picolo.net HD4 Handbook Web Pages Description Clicking on the OK button returns to the last page. The following banner appears on top of it: Must Reboot Banner Device Management Page - Time Tab Device Management Time tab The Time Tab of the Device Management Page allows to view or edit all the time and date related settings.
  • Page 84 PC1656 Picolo.net HD4 Handbook Web Pages Description Clicking on the Set Time and Date button opens the Date and Time Edition page. Date and Time Edition panel The Date and Time Edition panel allows the user to modify all the time and date settings.

  • Page 85: Device Management Page - Discovery Tab

    PC1656 Picolo.net HD4 Handbook Web Pages Description Device Management Page - Discovery Tab Device Management Discovery tab The Discovery Tab of the Device Management Page allows to view and edit all the device discovery settings. Discovery Panel The "Device is discoverable" check box controls the ability to discover the device on the network using the discovery functions of the ONVIF Device Web Service.

  • Page 86: Device Management Page - Maintenance Tab

    PC1656 Picolo.net HD4 Handbook Web Pages Description Device Management Page - Maintenance Tab Device Management Maintenance tab The Maintenance Tab of the Device Management Page allows to perform maintenance tasks. Device Information Panel The Device Information Panel provides the following device information:...

  • Page 87: Users Management Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Get Device Logs Panel The Get Device Logs panel allows to retrieve log files from the device. Clicking on the Get Systems Logs button initiates the download of the system.logs.tar.gz file containing the system logs data.
  • Page 88 PC1656 Picolo.net HD4 Handbook Web Pages Description Users Management Page The Users panel displays the list of users. Each list item contains: User name User level between square brackets An Edit button A Delete button Clicking the Delete button deletes the user.
  • Page 89 PC1656 Picolo.net HD4 Handbook Web Pages Description User Edition panel Field name Description Username User name Password User password Confirm password User password again UserLevel User access level. Possible values: Administrator Operator User Use Advanced Options Enable/disable advanced options. When Use Advanced Options checkbox is unchecked: The advanced options are not shown.

  • Page 90: Hidden Pages

    PC1656 Picolo.net HD4 Handbook Web Pages Description Hidden Pages Check Status Page Check Status Page Web Services Status panel The Web Services Status field OK indicates that all the web services are up.

  • Page 91: Open Source Licenses Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Open Source Licenses Page Open Source Licenses page Open Source Licenses page The Open Source Licenses page lists all the open-source licensed software components, their version, and provides a link to the license text.

  • Page 92: Video Status Page

    PC1656 Picolo.net HD4 Handbook Web Pages Description Video Status Page Video Status page Video Status panel The Video Status panel shows for each video input: The characteristics of the HD-SDI signal identified by the HD-SDI receiver device. A snapshot image for each encoded video stream.

  • Page 93: Product Maintenance

    PC1656 Picolo.net HD4 Handbook Product Maintenance Product Maintenance Firmware Upgrade The user can upgrade, re-install, or downgrade the embedded Firmware of Picolo.net HD4 using one of the following methods: The "Firmware Upgrade" capability of the ONVIF API. The "Firmware Upload" panel available on the Device Management Page of the built-in Web Server.

  • Page 94: Appendix

    PC1656 Picolo.net HD4 Handbook Appendix Appendix About ONVIF First steps with ONVIF To get familiar with ONVIF concepts, read: Chapter 4 - Overview of the core specifications: http://www.onvif.org/specs/core/ONVIF-Core-Specification- v220.pdf Chapter 4 - Media Profiles of the NVT media specifications: http://www.onvif.org/specs/srv/media/ONVIF-Media- Service-Spec-v220.pdf...

  • Page 95: Detailed Access Policy - Firmware Version 5.0

    Appendix Detailed Access Policy - Firmware version 5.0 This topic applies to product PC1656 - Picolo.net HD4 with firmware version 5.0. It provides, for each service function, the minimal user level required to gain access to that function. Note. The list of functions is sorted alphabetically by function name and categorized by service name.
  • Page 96 PC1656 Picolo.net HD4 Handbook Appendix Function Name Minimal User Level GetDynamicDNS User GetEndpointReference Anonymous GetHostname Anonymous GetIPAddressFilter User GetNTP User GetNetworkDefaultGateway User GetNetworkInterfaces User GetNetworkProtocols User GetPkcs10Request User GetRelayOutputs User GetRemoteDiscoveryMode User GetRemoteUser User GetScopes User GetServiceCapabilities Anonymous GetServices Anonymous...
  • Page 97 PC1656 Picolo.net HD4 Handbook Appendix Function Name Minimal User Level SetCertificatesStatus Administrator SetClientCertificateMode Administrator SetDNS Administrator SetDPAddresses Administrator SetDiscoveryMode Administrator SetDot1XConfiguration Administrator SetDynamicDNS Administrator SetHostname Administrator SetHostnameFromDHCP User SetIPAddressFilter Administrator SetNTP Administrator SetNetworkDefaultGateway Administrator SetNetworkInterfaces Administrator SetNetworkProtocols Administrator SetRelayOutputSettings Operator...
  • Page 98 PC1656 Picolo.net HD4 Handbook Appendix DeviceIO Service Functions Function Name Minimal User Level GetAudioOutputConfiguration User GetAudioOutputConfigurationOptions User GetAudioOutputs User GetAudioSourceConfiguration User GetAudioSourceConfigurationOptions User GetAudioSources User GetDigitalInputs User GetRelayOutputOptions Anonymous GetRelayOutputs User GetSerialPortConfiguration User GetSerialPortConfigurationOptions User GetSerialPorts User GetServiceCapabilities Anonymous GetVideoOutputConfiguration...
  • Page 99 PC1656 Picolo.net HD4 Handbook Appendix ProprietaryIO Service Functions Function Name Minimal User Level GetDigitalInputConfiguration User GetDigitalInputState User SetDigitalInputConfiguration Administrator Event Service Functions Function Name Minimal User Level CreatePullPointSubscription User GetCurrentMessage User GetCurrentMessage User GetEventProperties User GetServiceCapabilities Anonymous PullMessages User Renew...
  • Page 100 PC1656 Picolo.net HD4 Handbook Appendix Function Name Minimal User Level GetAudioDecoderConfiguration User GetAudioDecoderConfigurationOptions User GetAudioDecoderConfigurations User GetAudioEncoderConfiguration User GetAudioEncoderConfigurationOptions User GetAudioEncoderConfigurations User GetAudioOutputConfiguration User GetAudioOutputConfigurationOptions User GetAudioOutputConfigurations User GetAudioOutputs User GetAudioSourceConfiguration User GetAudioSourceConfigurationOptions User GetAudioSourceConfigurations User GetAudioSources User GetCompatibleAudioDecoderConfigurations User...
  • Page 101 PC1656 Picolo.net HD4 Handbook Appendix Function Name Minimal User Level GetVideoAnalyticsConfigurations User GetVideoEncoderConfiguration User GetVideoEncoderConfigurationOptions User GetVideoEncoderConfigurations User GetVideoSourceConfiguration User GetVideoSourceConfigurationOptions User GetVideoSourceConfigurations User GetVideoSources User RemoveAudioDecoderConfiguration Operator RemoveAudioEncoderConfiguration Operator RemoveAudioOutputConfiguration Operator RemoveAudioSourceConfiguration Operator RemoveMetadataConfiguration Operator RemovePTZConfiguration Operator RemoveVideoAnalyticsConfiguration Operator...
  • Page 102 PC1656 Picolo.net HD4 Handbook Appendix Function Name Minimal User Level GetExtendedVideoEncoderConfiguration User GetExtendedVideoEncoderConfigurations User SetExtendedVideoEncoderConfiguration Operator PTZ Service Functions Function Name Minimal User Level AbsoluteMove Operator ContinuousMove Operator CreatePresetTour Operator GetConfiguration User GetConfigurationOptions User GetConfigurations User GetNode User GetNodes User...

  • Page 103: Optional Onvif Capabilities - Firmware Version 5.0

    GetPelcoNodeAddressConfiguration User GetPelcoNodeAddressConfigurations User SetPelcoNodeAddressConfiguration Administrator Optional ONVIF Capabilities - Firmware version 5.0 This topic lists the ONVIF 1.02 optional Capabilities of product PC1656 - Picolo.net HD4 with firmware version 5.0. Device Capabilities Capability Name Capability Value Device/XAddr http://192.168.1.71/onvif/device_service Device/Network/IPFilter...
  • Page 104 PC1656 Picolo.net HD4 Handbook Appendix Capability Name Capability Value Device/Security/TLS1.1 false Device/Security/TLS1.2 false Device/Security/OnboardKeyGeneration false Device/Security/AccessPolicyConfig false Device/Security/X.509Token false Device/Security/SAMLToken false Device/Security/KerberosToken false Device/Security/RELToken false Device/Security/onv:Extension/onv:TLS1.0 true Events Capabilities Capability Name Capability Value Events/XAddr http://192.168.1.71/onvif/event_service Events/WSSubscriptionPolicySupport false Events/WSPullPointSupport false Events/...

  • Page 105: Open Source Software

    A package gathering all the source code of the Open Source development tools and open source components used in Picolo.net HD4 is available for download from a Euresys Web or FTP Server. The URL of the appropriate package is given in the above mentioned web page.

  • Page 106: Embedded Firmware Naming Conventions

    PC1656 Picolo.net HD4 Handbook Appendix Risks Due to Poor Grounding Protection Poor ground interconnection, ground loop or ground fault may induce unwanted voltage between equipments, causing excessive current in the interconnecting cables. This faulty situation can damage the electronic devices and its peripherals.
