1.240
.500 .370
1.250
.250 Dia.
SPEEDPOT
(5K 2W)
.437
5/32 3/8
DIA. DIA
SPEEDPOT LOCATOR HOLE DIMENSIONS
-K option
Acceleration Time Ranges
This option provides the Accel time shown below. The standard Accel time is 0.5 seconds.
ACCELERATION TIME------------------------------------------------------------------------------------------ 6
seconds
SPEEDPOT KIT ASSEMBLY
CUSTOMER'S
MOUNTING BRACKET
.370
OPTION DESCRIPTIONS
USE STANDARD HOOK-UP
DIALPLATE
2.00" dia.
HEX NUT
LOCK
WASHER
9
SPEEDPOT
KNOB
Factory Installed
