DART Controls 13DVA Series Instruction Manual page 25

(continued)
P1-5
(+Field) DO NOT use for Permanent Magnet Motor. This supplies +Field voltage for a SHUNT WOUND
P1-6
(Speedpot Hi) Connects to high side (white wire) of Speedpot (CW end). This is internal +12 volts. For start-
P1-7
(Speedpot Wiper) Connects to wiper (red wire) of Speedpot (center lead). For Voltage Follower applications, this
P1-8
(Speedpot Lo) Connects to Low side (orange wire) of 5K Speedpot (CCW end). This input is raised and lower-
1. Be sure the control housing is properly grounded.
2. Armature connections must not be switched or broken while the control is on. Serious control damage may result.
3. For non-speedpot applications, the input connection to the LO, WIPER, and HI terminals must not be grounded!
Serious control damage may result from a grounded input.
Do not attempt to perform Hi-pot test across AC lines with control in circuit.
WARNING: ALL POWER MUST BE TURNED OFF BEFORE PROCEEDING!
1. Recheck all wiring. Accidental grounds, loose or pinched wires on armature or speedpot wires may damage the control when
power is applied.
2. Check to see that incoming service is of correct voltage.
3. Turn speedpot to zero (fully CCW).
4. Turn power on, and advance speedpot while observing motor. Power must be off before step 5 can be accomplished!
5. If motor rotation is incorrect, turn power off at external disconnect and reverse +ARM and -ARM connections.
6. Check for satisfactory operation throughout the speed range.
7. If operation is satisfactory, no readjustments are needed.
8. If instability or surging is observed, or if maximum speed is higher than desired, see "TRIMPOT ADJUSTMENT CHART " on
page 5.
9. For other problems, consult page 10, "IN CASE OF DIFFICULTY".
MOTOR (refer to field voltage table). For motors with dual voltage field (ie. 50/100V or 100/
200V), make sure highest value is connected.
FIELD VOLTAGE TABLE
VAC INPUT
VDC FIELD
stop applications, the connection between this terminal and Speedpot HI can be opened and
closed by a SPST switch. INPUT MUST NOT BE GROUNDED!
INPUT MUST NOT BE GREATER THAN +12V MAXIMUM AND MUST NOT BE GROUNDED!
ed by the MIN. trimpot (5K). Electronic speed input (voltage follower) may be referenced to
Speedpot LO if the MIN trimpot adjustments are to be active. Otherwise, inputs may be refer-
enced to -ARM, which will bypass the MIN trimpot. INPUT MUST NOT BE GROUNDED!
123D/125D HOOK-UP DIAGRAM
This will result in immediate or long term damage to the control.
MIN
MAX
IR COMP
INHIBIT
CUR LIM
CONTROL START-UP
24 36 120
20 30 100
Warning:
Warning:
P2
ADDER BOARD
CONNECTOR
P3
PIN
4
240
200
P1
-8 SPEEDPOT LO (orange lead)
-7 SPEEDPOT WIPER (red lead)
-6 SPEEDPOT HI (white lead)
-5 + FIELD
-4 -ARMATURE / - FIELD
-3 + ARMATURE
-2 VAC INPUT (N)
-1 VAC INPUT (L)
