DART Controls 13DVA Series Instruction Manual page 20

AC input voltage
Acceleration
Amps - DC output
Controller overload capacity
Current limit trimpot range
Deceleration
Dimensions and weights:
WIDTH
ENGLISH 6.016"
METRIC 153mm
Drive service factor
Effi ciency
Input frequency
Max. trimpot speed range
Min. trimpot speed range
Power devices
Shunt fi eld voltage
Speed control
Speed range
Speed regulation
Temperature range
Transient protection
Trigger
Type ramp of accel/decel
Enclosure type
A-5-3336A
125DVE SPECIFICATIONS
LENGTH DEPTH
7.630" 6.845"
194mm 174mm
100VDC for 120VAC input; 200VDC for 240VAC input; 1 amp maximum
WEIGHT
2.61 lb.
1.18 kg.
via 5Kohms potentiometer or 0-10VDC isolated signal
-10 o to 45 o C. ambient (15 o to 115 o F.)
RC time constant (standard) Linear (optional)
2
±10% of rated line voltage
0.5 seconds (standard 125D)
150 mA to 5.5 ADC
200% for one minute
1 to 15 ADC (125DVE)
0.5 seconds (standard)
85% typical
50 or 60 Hertz
60% to 110% of base speed
0% to 30% of maximum speed
isolated case tab
±1% of base speed
opto-coupler
1.0
50:1
G-Mov
Nema 1
LT71
