Summary of Contents for amzchef FD2T2-18
- Page 1 142 . 5 0m m 804- 借（通）用件登记 标志 处数 更改文件号 签 名 日 期 重 量 比 例 说明书 设计 会签 出图审查 标准化 共 1 张 第 1 张 制图 莫子君 日 期 审核 批准 FD2T2-18-08 视角符号 工艺 日期 2023-11-14...
- Page 2 Instruction Manual Ceramic Cooker Hob BRAND:amzchef MODEL: FD2T2-18 120V~ 50/60Hz PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY RETAIN THIS MANUAL FOR FUTURE REFERENCE...
-
Page 4: Selection Of Installation Equipment
Installation Selection of installation equipment 1. Make sure the size of the induction cooktop (DxWxH): 288x520x50mm/ 11.34*20.47*1.97inch 2. Clean the countertop surface and make a proper cutout(DxW): 270x500mm/10.63*19.69inch Kindly Note: For the purpose of installation and use, a minimum of 50mm/1.97inch space shall be preserved around the hole. - Page 5 Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm/29.92inch.
-
Page 6: Table Of Contents
Contents Safety Warnings Product Overview Product Information Choosing the right Cookware Using your Ceramic Hob Cooking Guidelines Heat Settings Care and Cleaning Troubleshooting Technical Specification Warranty Manufacturer:Zhongshan Katro Electrical Appliances Co.,Ltd. Add.:No.5, Yuegui East Road, Suixi Industrial Estate, Nantou Town,Zhongshan City, Guangdong Province, China. -
Page 7: Safety Warnings
Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •... - Page 8 • During use, accessible parts of this appliance will become hot enough to cause burns. • Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool. • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot •...
- Page 9 • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the Induction glass. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
-
Page 10: Product Overview
Product Overview Top View 1.max. 1800W/800W zone 2.max. 1000 W zone 3.Glass plate 4.Control panel Control Panel 1.Upper/lower zone selection 2.Timer Setting 3.Power / Timer regulating controls 4.Child lock 5.ON/OFF Mode 6.Double zone control(Outer circle) Power Sharing Feature: Power sharing technology is a safety and efficiency feature. It is designed to avoid electrical hazards and increase efficiency by allowing the burners to share power between them. -
Page 11: Product Information
Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker focus on customer needs and is use-friendly. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. -
Page 12: Using Your Ceramic Hob
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Tip: Never use pans smaller than 100mm (4") and larger than 250mm (10"). -
Page 13: When You Have Finished Cooking
3) When the furnace head above the product is opened, the default is dual zone 9 level. When you need to switch to single zone, you need to operate as follows. 4. Select a heat setting by touching the “+” or “-” control. •... -
Page 14: Locking The Controls
Locking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls Touch and hold the key lock control for 3 seconds. -
Page 15: Using The Timer
Using the Timer Setting the timer to turn one cooking zone off 1. Touching the heating zone selection control that you want, set the heat power then set the timer. (e.g. zone 1#) 2. Touch timer control, the minder indicator will start flashing and “30” will show in the timer display. -
Page 16: Cooking Guidelines
2. Select a heating zone, set the power level by touching “+” or”-”, and then touch the “Timer” to adjust the time by touching “+” or”-” 3. Select another heating zone, set the power level by touching “+” or”-”, and then touch the “Timer”... -
Page 17: Heat Settings
4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will be. -
Page 18: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling 1. Switch the power to the • When the power to the cooktop glass (fingerprints, cooktop off. is switched off, there will be no marks, stains left by 2. Apply a cooktop cleaner ‘hot surface’... -
Page 19: Troubleshooting
Troubleshooting Problem Possible causes What to do The cooktop cannot No power. Make sure cooktop Be turned on. connected to the power supply and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician. -
Page 20: Technical Specification
Furnace surface high tempera- It will disappear when the surface has ture reminder cooled down to a safe temperature. Technical Specification Cooking Hob FD2T2-18 Cooking Zones 2 Zones Supply Voltage 120V~ 50-60Hz Installed Electric Power shared 1800W Product Size D×W×H(mm/inch)
