KODAK
FLIK HD10
SMART PROJECTOR
User Manual
EN | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLIK HD10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kodak FLIK HD10

Summary of Contents for Kodak FLIK HD10

  • Page 1 KODAK FLIK HD10 SMART PROJECTOR User Manual EN | 1...
  • Page 2 INTRODUCTION Thank you for purchasing the KODAK FLIK HD10 Smart Projector. This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any use that does not conform to the guidelines described in this User Guide may void the limited warranty.

  • Page 3: Specifications

    SPECIFICATIONS Product type: Projector Projection distance: 39.4” – 157.5” (1 m - 4 m) Product length: 5.6” Image input modes: HDMI input x 1, USB Product width: 5.8” input x 1 Product height: 7.4” Speakers: Dual 5-watt speakers Net weight: 4.2 lbs. Audio out: 3.5 mm Native resolution: 1920 x 1080p Audio format: MPEG Audio Layers 1, 2 &...

  • Page 4: Package Contents

    PACKAGE CONTENTS • KODAK FLIK HD10 Smart Projector • Power cord & AC adapter • Remote control • HDMI cable • User guide SAFETY PRECAUTIONS • Do not attempt to disassemble this device for any reason. • Do not store the projector in areas where it will be exposed to high temperatures, humidity, or direct sunlight.
  • Page 5 humidity/moisture. • Never drop or shake the projector, as this could cause it to malfunction or permanently damage the inside parts. • Do not use the projector while bathing or in a shower. • Do not place or store the projector where it can fall or be pulled into a tub or sink. •...

  • Page 6: Product Overview

    PRODUCT OVERVIEW FRONT BACK 6 | EN...
  • Page 7 Lens 2. Feet 3. IR receiver 4. AC port 5. USB port 6. 3.5 mm audio port AV port 8. HDMI port 9. Power button 10. Manual focus wheel EN | 7...

  • Page 8: Remote Control View

    REMOTE CONTROL VIEW Power button 2. Bookmark button 3. GOOGLE assistant button 4. OK button 5. Back button 6. Mute button Volume up (+) button 8. Volume down (-) button 9. YOUTUBE button 10. PRIME VIDEO button 11. Projector settings button 12.

  • Page 9: Install Batteries Into The Remote Control

    INSTALL BATTERIES INTO THE REMOTE CONTROL 1. Press down and slide off the battery cover. 2. Insert the two (2) AAA batteries into the battery compartment. 3. Place the battery cover back on the remote control. SET UP THE PROJECTOR 1.
  • Page 10 PAIR THE REMOTE CONTROL Power on the projector and the remote control should automatically pair with the projector. For manual pairing, press and hold the Back and Home buttons simultaneously for five (5) seconds. The LED light on the remote control will begin to flash. When the pairing is complete, the LED light on the remote control will remain on without flashing.
  • Page 11 projector. 5. On your phone, tap the name of the projector when it shows up. 6. To finish the setup, follow the instructions on your projector. Method 2: Set Up with the Remote Control 1. When your projector says, “Quickly set up your projector with your ANDROID phone?” use the remote control to choose “Skip.”...

  • Page 12: Projector Settings

    NAVIGATING YOUR PROJECTOR When the projector unit is powered on, the ANDROID TV™ home menu will load automatically. The home menu is the starting point for all operations with your projector. When the unit is powered on, the home menu will load automatically. •...
  • Page 13 Sound: Navigate to this icon and press the OK button to select. This will access the Sound window where you can adjust sound settings like sound mode and sound channel. System: Navigate to this icon and press the OK button to select. This will access the System window where you can adjust projector settings like language, timer, and more.
  • Page 14 Manual Keystone – Adjust the keystone manually. Auto Keystone – Turn the auto keystone on or off. Projection Mode – Select between front projection, front ceiling projection, rear front projection, or rear ceiling projection. • Front: The projector is placed on a table in front of the screen. This is the most common way to position the projector for quick setup and portability.
  • Page 15 Image Mode – Select the image mode of the projection or customize to adjust specific settings. SOUND WINDOW Your sound settings will be displayed. Navigate to the setting option you wish to change and press the OK button to confirm your selection. Sound Mode –...
  • Page 16 Sound Channel – Select between Audio Return Channel (ARC) or TV options. Touch Tone – Turn touch tone on or off. SYSTEM WINDOW Your system settings will be displayed. Navigate to the setting option you wish to change and press the OK button to confirm your selection. Language –...
  • Page 17 Window Location – Adjust the location of the window. Time Off – Set a timer for when the projector will turn off. Factory Reset – Reset the projector back to default factory settings. EN | 17...
  • Page 18 SET UP THE REMOTE CONTROL ON YOUR PHONE 1. Open the GOOGLE TV app on your ANDROID phone. 2. Tap “Remote.” Then, tap “Scanning for devices.” 3. Choose your device. 4. To complete pairing, follow the instructions on your phone and projector. 5.
  • Page 19 MIRROR OR STREAM VIDEO FROM YOUR IOS DEVICES TO THE PROJECTOR First, you’ll need to install AirPlay on your projector. Install the AirScreen app from GOOGLE PLAY to enable AirPlay on your projector. Once completed, follow these steps to mirror or stream video from your iOS device. Screen Mirroring from IPHONE or IPAD: 1.

  • Page 20: Adjusting Focus

    phone’s hotspot is also acceptable. 2. Open the streaming apps you want to cast on the projector and select a video to play. 3. Click the AirPlay or cast icons in the top right corner to cast to the projector. NOTE: Be aware that copyrighted content from HULU, NETFLIX, and other similar services CANNOT be mirrored or screencast.

  • Page 21: Google Assistant

    the image appears sharp and clear. NOTE: For best performance, the projector must be located a minimum distance of 3.5 feet (1 meter) from the screen. GOOGLE ASSISTANT With GOOGLE ASSISTANT, you can navigate through the apps and streaming services using your voice.
  • Page 22 HDMI Compatible Devices When using an HDMI-compatible device, such as a laptop, personal computer, smartphone, tablet, or video game console, connect an HDMI cable from the device to your projector to access photos, videos, or music. Then, press the Projector Settings button and under “Signal,”...

  • Page 23: Troubleshooting

    TROUBLESHOOTING If you cannot play your GOOGLE PLAY movies, TV shows, or music on ANDROID TV™ screen, here are a few troubleshooting solutions you can try: Check your Wi-Fi® Connection 1. From the ANDROID TV™ home menu, press the ANDROID TV™ Settings button. 2.
  • Page 24 2. Under “Accounts”, check to make sure you are signed into your ANDROID TV™ account. Sync your Account 1. From the ANDROID TV™ home menu, press the ANDROID TV™ Settings button. 2. Under “Accounts,” select your account. 3. Then, select “Sync Now.” 4.

  • Page 25: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS Can I sideload ANDROID apps to the projector? Yes, you can. Note, there are more than 7,000 native apps on GOOGLE PLAY you can download directly to the projector. For apps not available on GOOGLE PLAY, download the APK file and install them on a USB drive.
  • Page 26 How do I play videos without Wi-Fi®? 1. Download videos to a USB drive. 2. Install the File Explorer app from the GOOGLE PLAY STORE on the projector. 3. Install a media player app such as VLC or KODI. 4. Plug in the USB drive into the projector to play your videos. What capacity of USB drives does the projector support? The projector supports USB drives with or below 128 GB and 1080p @ 60 Hz content.

  • Page 27: Customer Service

    CUSTOMER SERVICE Should you experience any problems with your product, please contact us before returning the item to the place of purchase. We’re here to help! U.S. Support: kodak@camarketing.com, 844-516-1539 International Support: kodakintl@camarketing.com, 844-516-1540 EN | 27...
  • Page 28 Company’s property. Refunds can only be given if the original Product is returned. This Warranty does not apply to: (a) Any non-KODAK FLIK HD10 Smart Projector product, hardware or software, even if packaged or sold with the Product; (b) Damage caused by use with non-KODAK FLIK HD10 Smart Projector products;...
  • Page 29 (g) Consumable parts, such as batteries, fuses, and bulbs; (h) Cosmetic damage; or (i) If any KODAK FLIK HD10 Smart Projector serial number has been removed or defaced. This Warranty is valid only in the country where the consumer purchased the Product, and only applies to Products purchased and serviced in that country.
  • Page 30 ⚠WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. The KODAK trademark, logo, and trade dress are used under license from Eastman Kodak Company. GOOGLE PLAY is a trademark of GOOGLE LLC.
  • Page 31 • Never attempt to take this product apart. You may be injured. • If this product is dropped or damaged so that the inside is showing, do not touch it. Contact Kodak customer support at 844- 516-1539 or email us at kodak@camarketing.com.
  • Page 32 IMPORTANT: Read the following notices before using the product’s built-in Bluetooth transmitter. Use only as part of a Bluetooth network. Kodak and its affiliates do not accept liability for damages resulting from unauthorized use. Do not use in applications requiring a high degree of reliability, for example in medical devices or other systems that may directly or indirectly impact human life.
  • Page 33 The United States Federal Communications Commission (in 47 CFR 15.105) has specified that the following notice be brought to the attention of users of this product. Kodak Luma Flik HD10 Smart Projector. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 34 For further information, contact: 114 Tived Lane East, Edison, NJ 08837 Email: kodak@camarketing.com Telephone: 1-844-516-1539 Website: www.kodakprojectors.caglobal.com This equipment complies with FCC and Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
  • Page 35 EN | 35...
