Akytec ITP15-M User Manual

ITP15-M LED Bargraph Indicator
User guide
1. Introduction
This manual describes the functions, configuration, mounting and
operating instructions of the ITP15– M LED Bargraph indicator
(hereinafter referred to as the device).
Connection, setup and maintenance of the device must be performed
only by fully qualified personnel after reading this user guide.
2. Terms and abbreviations
PC – personal computer
akYtec Tool Pro – configuration software
USB (Universal Serial Bus) – serial communication interface
3. Overview
The device is designed for conversion, indication and signalling of
physical values of temperature, DC voltage and DC (U / I signals).
Functions:
• displaying a value level on the bargraph indicator;
• color-coded indication of changes in the value;
• signalling by color-coded indication about exceeding the set
thresholds of the measured value;
• color-coded signalling when the value is in the critical zone;
• alarm indication:
– indication of a break or short circuit in the "device-sensor"
communication line ;
– cold junction sensor (CJS) failure;
– value out of range.
4. Specifications
Table 1 Specifications
Parameter
Electrical
Power supply
Power consumption, max.
Appliance class
Galvanic isolation for circuits input-to-
output, input-to-power supply, output-to-
power supply, power supply-to-
enclosure
Input signals
Number
Input resistance at voltage measuring,
min.
Input voltage drop at current measuring,
max.
Input signals supported
Sampling time, max.
ITP15-M_3-EN-140091-1.2
© All rights reserved. Subject to technical changes and misprints.
Bargraph indicator error limit (excluding
hysteresis), max.
Measurement accuracy (when reading
using micro-USB interface), max.
• RTD (resistance temperature
detector), U / I signals
• TC (thermocouples), pyrometers
NPN transistor, loading capacity
Connector for configuration with akYtec
Tool Pro
Colors
Segments
Indication range
Display hysteresis (segment switching /
segment color switching)
Display events
Dimensions
IP code (front / rear)
MTBF
Value
Average service life
Weight
24 (10..30) VDC
1 W 5. Environmental conditions
III The device is designed for natural convection cooling which should be
taken into account when choosing the installation site.
The following environmental conditions must be observed:
500 V
• clean, dry and controlled environment, low dust level;
• closed non-hazardous areas, free of corrosive or flammable gases.
Table 2 Environmental conditions
1
Condition
Ambient temperature
100 kΩ
Relative humidity
Transportation and storage
1.6 V
temperature
see Section 6
Transportation and storage relative
humidity
1 s
ITP15-M
ITP15-M LED Bargraph Indicator
Parameter Value
Tolerance
± 10 %
± 0,25 %
± 0,5 %
Output
200 mА, 42 VDC
Configuration interface
micro-USB
Display
red, green, yellow
10 ( 0...100 % scale)
user-configurable in Bar.L
and Bar.H parameters
±1 % of indication range
signal < 0%
signal = 0%
0% < signal < 100%
signal = 100%
signal > 100%
fault
Mechanical
48 × 26 × 72 mm
(IP65 / IP20)
100000 hours
12 years
approx. 150 g
Permissible range
-40...+60 °C
30...80 % (non-condensing)
-25 ... +55 °C
5...95 % (non-condensing)
Condition
Altitude
EMC emission / immunity
conforms to IEC 61000-6-3-2016
NOTE
When operating the device at an altitude above 1000 m above
sea level, it is necessary to take into account the reduction of
the electrical insulation as well as the reduction in the cooling
effect of the air.
6. Input signals
Table 3 Signals and sensors
Indication* Description
RTD
С 50 Cu50 (α = 0,00426 °С -1 )
50 С 50М (α = 0,00428 °С -1 )
P 50 Pt50 (α = 0,00385 °С -1 )
50P 50P (α = 0,00391 °С -1 )
C100 Cu100 (α = 0,00426 °С -1 )
100C 100М (α = 0,00428 °С -1 )
P100 Pt100 (α = 0,00385 °С -1 )
100P 100P (α = 0,00391 °С -1 )
100n 100N (α = 0,00617 °С -1 )
P500 Pt500 (α = 0,00385 °С -1 )
500P 500P (α = 0,00391 °С -1 )
C500 Cu500 (α = 0,00426 °С -1
500C 500М (α = 0,00428 °С -1 )
500n 500N (α = 0,00617 °С -1 )
C 1.0 Cu1000 (α = 0,00426°С -1
1.0 C 1000М (α = 0,00428 °С -1 )
P 1.0 Pt1000 (α = 0,00385 °С -1
1.0 P 1000P (α = 0,00391 °С -1 )
1.0 n 1000N (α = 0,00617 °С -1 )
TC
tC.L L
tP.HA К
tC.J J
tC.n N
tC.t Т
tC.S S
tC.r R
tC.b В
tC.A1 А-1
tC.A2 А-2
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany
Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
Permissible range
up to 2000 m ASL
Measurement
range
–50...+200 °С
–180...+200 °С
–200...+850 °С
–200...+850 °С
–50...+200 °С
–180...+200 °С
–200...+850 °С
–200...+850 °С
–60...+180 °С
–200...+850 °С
–200...+850 °С
) –50...+200 °С
–180...+200 °С
–60...+180 °С
) –50...+200 °С
–180...+200 °С
) –200...+850 °С
–200...+850 °С
–60...+180 °С
–200...+800 °С
–200...+1300 °С
–200...+1200 °С
–200...+1300 °С
–200...+400 °С
0...+1750 °С
0...+1750 °С
+200...+1800 °С
0...+2500 °С
0...+1800 °С
