I
NTRODUCTION

Front Panel RJ-45 Ports

These EZ Switch 10/100 models feature 5/8 1000BASE-T ports with RJ-45
connectors located on the front panel of the switch. Because all ports
support automatic MDI/MDI-X operation, you can use straight- through
cables for all network connections to PCs or servers, or to
other switches or hubs.

Front Panel LEDs

The front panel of the switch provides status LEDs for "at-a-glance"
system monitoring. The following table details the functions of the
various indicators.
Port and System Status LEDs
LED
Power
Ports
Link/Act
1000M
10/100M
2
Condition Status
On The switch is receiving power.
Off The switch is not receiving power.
On The port has established a valid network
connection.
Off The port has not established a network
connection.
Flashing Traffic is passing through the port.
On Indicates the port is operating at 1000 Mbps.
Off Indicates the port is not operating at
1000 Mbps.
On Indicates the port is operating at 100 Mbps.
Off Indicates the port is operating at 10 Mbps.
