BendPak HDS-14 Installation And Operation Manual

Commercial grade four-post lift
Hide thumbs Also See for HDS-14:

Advertisement

Quick Links

Commercial Grade Four-Post Lift
Installation and Operation Manual
Models:
• HDS-14
• HDS-14X
• HDS-14XT
Designed and engineered by BendPak Inc. in Southern California, USA. Made in China.
IMPORTANT SAFETY INSTRUCTIONS, SAVE THESE INSTRUCTIONS
manual thoroughly before installing, operating, servicing or maintaining this Lift. Failure to follow the
instructions and safety precautions in this manual can result in serious injury or death. Make sure all
other operators also read this manual. Keep the manual near the product for future reference.
proceeding with installation and operation, you agree that you fully understand the contents
of this manual and assume full responsibility for product use.
Manual P/N 5900161 — Revision H — September 2024
DANGER
30441 Agoura Road
Agoura Hills, CA 91301 USA
Toll Free: (800) 253-2363
Tel: (805) 933-9970
bendpak.com
Original instructions in
the English language.
Read this
!
By

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDS-14 and is the answer not in the manual?

Questions and answers

Summary of Contents for BendPak HDS-14

  • Page 1 Original instructions in the English language. • HDS-14 • HDS-14X • HDS-14XT Designed and engineered by BendPak Inc. in Southern California, USA. Made in China. ⚠ DANGER IMPORTANT SAFETY INSTRUCTIONS, SAVE THESE INSTRUCTIONS Read this manual thoroughly before installing, operating, servicing or maintaining this Lift. Failure to follow the instructions and safety precautions in this manual can result in serious injury or death.
  • Page 2 Copyright. Copyright © 2024 by BendPak Inc. All rights reserved. You may make copies of this document if you agree that: you will give full attribution to BendPak Inc., you will not make changes to the content, you do not gain any rights to this content, and you will not use the copies for commercial purposes.
  • Page 3 Unit Information. Enter the Model Number, Serial Number, and the Date of Manufacture from the label on your unit. This information is required for part or warranty issues. Model: Serial: Date of Manufature:...
  • Page 4: Table Of Contents

    This manual describes the following BendPak Four-Post Lifts: • HDS-14. Four-Post Lift with an overall width of 131.75 in. (3,346 mm) raising Vehicles up to 14,000 lbs. (6,350 kg). HDS-14X. Has the same overall width as the HDS-14, but with an extended length, raising •...
  • Page 5: Shipping Information

    Keep this manual on or near the product for future reference. Read and follow the warnings and instructions on the labels on the product. Contact BendPak at (800) 253-2363 then follow the prompts, or email support@bendpak.com...
  • Page 6 25. BendPak recommends referring to the ANSI/ALI ALIS Standard Safety Requirements for Installation and Service for more information about safely installing, using, and servicing your Lift. 26. HDS-14 / HDS-14X / HDS-14XT are Four-Post Vehicle Lifts. Use them only for their intended purpose.
  • Page 7: Liability Information

    32. Make an inspection of the Lift before using it. Check for damaged, worn, or missing parts. Do not use it if you find any of these issues. Instead, take it out of service, then contact an authorized repair facility, your dealer, or BendPak (805) 933-9970 or email support@bendpak.com.
  • Page 8: Components

    Components Drawing shows the two possible Power Post locations; only one Post has Mounting Brackets for the Power Unit. Not all components are shown. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 9 The main components of the HDS-14 Series Lift include: • Power Post. The Post that holds the Power Unit. The Power Post can be in either of two locations. The Power Post may be identified by the two Power Unit Mounting Brackets.
  • Page 10: Specifications

    Specifications Top View Side View Approach View HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 11 (or 7,000 lbs. when the rated capacity is 14,000 lbs.). Specifications subject to change without notice. Dimensions rounded to the nearest 0.25 in. (6.3 mm). HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 12 Lock Positions Max. Safety Ladder 3.5 in. (89 mm) Adj. Note: All dimensions are measured with the Safety Ladders adjusted to their maximum height. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 13: Frequently Asked Questions

    Q: Does the Lift have to be anchored in place? A: Yes, BendPak strongly advises that the Lift be anchored. If there are plans to use the optional Rolling Bridge Jack, the Lift must be anchored.
  • Page 14: Installation Checklist

    Installation Checklist Following are the steps required to install the HDS-14 Series Lift. Perform them in the order shown. ☐ 1. Review the safety rules. ☐ 2. Verify the necessary tools are available. ☐ 3. Plan for Electrical work. ☐ 4. Select the installation location.
  • Page 15: Installation

    Only fully trained personnel should be involved in installing this equipment. Always pay attention. Use appropriate tools and lifting equipment. Stay clear of moving parts. BendPak recommends referring to the current version of the ANSI/ALI ALIS Standard Safety Requirements for Installation and Service for more information about safely installing, using, and servicing the Lift.
  • Page 16: Planning For Electrical Work

    Do not perform any maintenance until main electrical power has been disconnected from the Lift and cannot be re-energized until all procedures are complete. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 17: Selecting A Location

    Do not shim a Post more than half an inch using the provided Shims and Anchor Bolts. A maximum shim of 2 in. (51 mm) is possible by ordering optional Shim Plates. Contact BendPak at (800) 253-2363, follow the prompts to order. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts...
  • Page 18 28 days. ⚠ CAUTION BendPak lifts are supplied with installation instructions and Concrete anchors that meet the criteria set by the current version of the American National Standard “Automotive Lifts – Safety Requirements for Construction, Testing, and Validation”, ANSI/ALI ALCTV.
  • Page 19: Checking Clearances

    Checking Clearances Clearance around and above the Lift is required for safety. Refer to the figure below. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 20 This will not impact the use of the Lift in most cases, as the wheelbase length of most Vehicles put the Wheels in the Usable Areas. Top view. Drawing not to scale. Not all components shown. For more information about the BendPak Rolling Jacks, visit our Rolling Jacks website page.
  • Page 21 Installers, the Lift orientation must be decided before placing the Posts into position. Power Post Location – Front Driver-side Power Post Location – Rear Passenger-side HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 22: Creating Chalk Line Guides

    4. When you move the Posts into position, put the corners of the Base Plates inside the corners created by the four Chalk Lines. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 23: Unloading And Unpacking

    Do not stand up the Posts yet; some of the following procedures are easier to complete if the Posts are laying on the ground. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 24: Installing The Crosstubes

    Align the holes in the Slide Blocks with the rods on the side of the Gusset, then press the Slide Blocks in. Make sure the Slide Blocks are oriented so that they create a Slot when pushed in. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 25 Carefully stand up the Posts, use a Forklift or Shop Crane to raise the Crosstube above the top of the two Posts that it goes between, and then slide the Crosstube down to the bottom. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 26 The Crosstubes and Posts are heavy; do not lift without proper assistance. 4. Perform Steps 2 and 3 for the other Crosstube. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 27: About Safety Locks

    The Slack Safety Locks are engaged during installation when you raise the Crosstubes (see Raising Crosstubes). Make sure to disengage them immediately after raising the Crosstubes. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 28 Slot, but it is required that the Ladder be routed through both Slots. 2. Install the remaining three Ladders in the same manner. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 29 Do not securely tighten the Top Nut at the top of the Top Cap at this point; they can Important: be securely tightened after the final leveling to the Lift. 6. Install the remaining Top Caps in the same manner. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 30: Raising The Crosstubes

    Dropping or knocking over the Posts may cause permanent equipment damage or serious personal injury. The Crosstubes and Posts are heavy; do not lift without assistance. BendPak strongly recommends having at least two people work together to raise the Crosstubes.
  • Page 31: Securing The Ladders

    Posts. The difference is the estimated amount of Shim thickness you will need. Do not shim more than 1/2 in. (13 mm). Do not tighten the nuts on the anchors at this point. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 32 Use caution when handling the Sheave components as they can fall and become WARNING damaged, if dropped. Make sure to reinstall the Sheave Shaft Lock Screws when adjustments and installation is complete. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 33: Installing The Runways

    3. Use a Forklift or Shop Crane to pick up the Runways, one at a time, and move them into place. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 34 2. Attach an air pressure source to the Return Line Connector. 3. Use the air pressure to extend the Hydraulic Cylinder’s Piston and Retaining Block. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 35 Come Along Tool) to extend the Piston and Retaining Block; use care not to damage the Piston. 4. Disconnect the Air Line and reinstall the Shipping Plug to the Return Line Connector. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 36: Routing The Lifting Cables

    The following drawing shows all four Cable routes in one drawing. The following illustration displays the Cable Sheave Pairings underneath the Powerside Runway. Lubricate the Cable Sheave Pins and Bores with Red Lithium Grease. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 37 Nut and Washer removed earlier. Only hand tighten the Nut until there is still a little play in the cabling. All four Cable nuts will be adjusted after the Final Leveling. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 38 Retaining Block Button ends facing the viewer. Not all components are shown. Lifting Cables A and C are now correctly routed to their Posts. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 39: Working With Compression Fittings And Tubing

    Threads and then slide it away from the Fitting. See the drawing above. 3. Slide the Ferrule over the Tubing, away from the Fitting and towards the Nut. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 40 The Ferrule routes around the Rod and under the Threads. The Nut is tightened onto the threads. 6. Tighten the Nut. Remember that the Ferrule can only be used once; do not tighten the Nut until everything is ready. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 41 Hydraulic Hoses and Fittings on the Lift, making it inoperable. The Lift is shipped with clean components; however, BendPak strongly recommends that you take secondary precaution to clean all Hydraulic Hoses and Fittings prior to making connections. It is better and less costly to take these extra steps now so that there is no need to take your Lift out of service later to fix issues that could have been prevented at the time of installation.
  • Page 42 Always promptly clean any Hydraulic Fluid spills. If a leak is the source of the spill, lockout the Lift to prevent use until the Hydraulic System is repaired. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 43 3. Tighten the Fitting into the connector; do not over tighten the Fitting. 4. Allow the 24-hour manufacturer-recommended curing time before pressurizing the system. Identifying Hydraulic Fittings Joint Industry Council (JIC) HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 44 Runways. To install the Hydraulic Hose, the following components are required: • The Hydraulic Hose. HDS-14 (5570152) / HDS-14X (5570151) / HDS-14XT (5570306). The Hydraulic Hose has a Curved end and Straight end. •...
  • Page 45 NOTICE near the Power Unit. 8. The radius end of the Hydraulic Hose will be connected to the Power Unit later in the process. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 46: Installing The Return Line

    The figure above is a top view of the Powerside Runway. Not all components shown. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 47 Working with Compression Fittings and Tubing for instructions. 6. Leave the Power Unit end of the Return Line hanging out of the Flex Tube opening for the moment. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 48: Installing The Air Lines

    The Compression Elbow Fittings on the Crosstube Gussets are delivered already installed from the factory. Air Lines shown outside Steel Tubes for clarity. Drawing not to scale. Some components not shown. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 49 6. Leave the Power Unit end of the Air Line hanging out of the Flex Tube opening for now. It will be connected to a Tee Compression Fitting and the Pushbutton Air Valve later. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 50: Installing The Power Unit

    Never mount the power unit motor lower than 18 in. above the ground. ⚠ The Power Unit is heavy. BendPak recommends one person hold the Power Unit CAUTION while another person bolts it in to place.
  • Page 51 5585176: 4.5 gallons (17 liters) 3. When the Reservoir is filled, replace the Reservoir Cap. Do not connect the Power Unit to a power source at this point. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 52: Installing The Flex Tube

    To connect the Flex Tube to the Power Unit, first connect the Flex Tube Bracket and the Flex Tube Angle Bracket. BendPak recommends orienting the Flex Tube so that the Hydraulic, Pressure and Return Lines exiting the Flex Tube are near where it connects on the Power Unit and to the Pushbutton Air Valve.
  • Page 53: Installing The Pushbutton Air Valve

    Drawing shows the Pushbutton Air Valve Assembly and its connections to the Mounting Bracket on the Power Post. Not all components shown. Sample Power Unit shown. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 54: Connecting The Return Line

    Make sure you are attaching the Return Line to the Power Unit and not the Air Line. Important: Do not attach the Air Line to the Power Unit by mistake. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 55: Connecting The Power Source

    The Hydraulic Power Ports are usually labeled P1/P2 on the Power Unit; the Hydraulic Return Ports are commonly labeled T1/T2 or CV1/CV2. The following figure Displays the standard configuration for the Power Unit. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 56 Do not use the Pigtail. NOTICE The Power Cord and Plug are not supplied with the Lift. Wiring Diagrams for wiring information. 3. Close the Electrical Junction Box. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 57: Installing A Power Disconnect Switch

    Lift without first verifying that main electrical power has been disconnected from the Lift and cannot be re-energized until all procedures are complete. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 58 Use only the Anchor Bolts delivered with the Lift. Only install the Lift on a Concrete WARNING floor. Make sure to achieve the correct amount of Effective Embedment and use the correct amount of Torque. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 59: Anchoring The Posts

    Concrete or Anchor Bolts that do not meet these specifications, can lead to product damage, Vehicle damage, severe injury, or even death. BendPak Lifts are supplied with installation instructions and concrete fasteners meeting the criteria as prescribed by the American National Standard “Automotive Lifts – Safety Requirements for Construction, Testing, and Validation”...
  • Page 60 Do not use an impact wrench to torque the Anchor Bolts. Wrenching the Nut forces the Wedge up, forcing out the Expansion Sleeve and pressing it tightly against the Concrete. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 61: Final Leveling

    Crosstube position and slowly tighten the Lift Cable until the top of the Crosstube is even with the bottom of the Safety Lock Window. Refer to the figure below. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 62: Installing Accessories

    1 in. (25 mm) of thread is visible above the Lift Cable Nut. Installing Accessories The accessories available for your HDS-14 Series Lift include: Tire Stops Tire Stops are installed at the Front of the Lift; they prevent the Tires of your Vehicle from moving too far forward.
  • Page 63 Drive-up Ramps The HDS-14 Series Lifts use Drive-up Ramps for Vehicles to be easily driven onto and off the Runways. To install the Drive up Ramps: 1. Find the required components: two Ramps, two Ramp Pins, and four Rotor Clips.
  • Page 64 Applying Anti-Slip Tape The Anti-Slip Tape (SKU 5930195) is provided in a single roll measuring 6 in. x 24 ft. (152 mm x 7.3 m). BendPak suggests cutting the Tape into four equal lengths 72 in. (1,829 mm) long each. IMPORTANT! Surface preparation is important.
  • Page 65 Technical support and service is available from your dealer, on the Web at bendpak.com/support, by email at support@bendpak.com, or by phone at (800) 253-2363, extension 196. You may also contact BendPak for parts replacement information (please have the model and serial number of your unit available) at (800) 253-2363, follow the prompts.
  • Page 66: Bleeding The Hydraulic Cylinder

    Lightly Lubricate the inside of the Lift Posts where the Slide Blocks contact the Lift Post with White Lithium Grease. Refer to the figure below. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 67: Perform An Operational Test

    Perform an Operational Test BendPak recommends performing an operational test of your Lift with a standard Vehicle on the Runways before starting normal service (a typical Vehicle is not required but is recommended). NOTICE Residual air in the Hydraulic Systems can cause the Lift to shake, move erratically, or squeak when you start using it;...
  • Page 68: Final Checklist

    Make sure to leave the Installation and Operation Manual with the owner/operator so that it is available for anyone who needs to read it. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 69: Operation

    Always verify all Hydraulic connections including Hydraulic Fittings, Hydraulic Hoses, and Auxiliary Ports are secure. Do not operate the Lift if you find any issues; instead, take it out of service, then contact your dealer, email support@bendpak.com, or call (800) 253-2363, then follow the prompts.
  • Page 70: Using The Controls

    Using the Controls The Controls for the HDS-14 Series Lift include: • Up button. Press and hold to raise the Runways. Located near the top of the Power Unit. To put Runways onto a Safety Lock position: Raise the Runways a little above the desired height, then press and hold the Lowering Handle to back the Runways down onto the nearest Safety Lock position (do not press and hold the pushbutton on the Pushbutton Air Valve).
  • Page 71: Raising And Lowering Vehicles

    7. With the Runways engaged on the Safety Locks, check around the Vehicle to make sure everything looks good. If you see anything wrong, fix it before anyone gets near the Runways or goes under them. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 72 4. If all four corners of the Lift are descending evenly, bring the Runways all the way to the ground then release the Pushbutton Air Valve and the Lowering Handle. 5. Remove the Tire Chocks, then carefully drive the Vehicle off the Runways. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 73: Maintenance

    Unless stated otherwise, all maintenance may be performed by the owner/employer and does not require trained lift service personnel. Replace worn, damaged or broken parts with original BendPak or BendPak approved parts or with parts that meet or exceed the original specifications.
  • Page 74: Lubrication Procedure

    ⚠ WARNING Do not operate your Lift if you find maintenance issues; instead, take the Lift out of service, then contact your dealer, visit bendpak.com/support, email support@bendpak.com, or call (800) 253-2363, then follow the prompts. Lubrication Procedure ⚠ DANGER Always refer to the lubricant and hydraulic fluid manufacturer’s Material Safety Data Sheet (MSDS) for proper handling and disposal of chemicals.
  • Page 75 5. Use a Step Ladder to access the top of one Lift Post. Do not stand on the Runway while adjusting the Lift Cables. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 76 7. Raise and then lower the Lift Platforms while observing all four corners to verify the Lift is descending evenly. If one corner is not descending, stop the Lift and refer to Troubleshooting HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 77: Wire Rope Inspection And Maintenance

    Visually check for any broken wires. One way to check for crown breaks is to run a cloth along the rope to check for possible snags. d. With an awl, probe between wires and strands and raise any wires that appear loose. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 78: Fastener Torque

    Fastener Torque HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 79 If you are unable to find an appropriate facility, the website has resources that may earth911.com be of help. HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 80: Troubleshooting

    If your Lift is not functioning correctly, you must take it out of service until it is fixed. Important: Replace worn, damaged or broken parts with original BendPak or BendPak approved parts or with parts that meet or exceed the original manufacturer specifications.
  • Page 81 3. If the Lift cannot be put into a safe condition, then contact BendPak support, go to bendpak.com/support, email support@bendpak.com, or call (800) 253-2363, then follow the prompts. 4. Once the Lift is in a safe condition, inspect to verify no damage has occurred. It is critical to Inspect the inner rails of the Lift Post.
  • Page 82: Wiring Diagrams

    Wire #3 Wire #7 Black Wire Screw Connec tor (WHITE) 5585175 208-230VAC, 1 PH., 60 HZ. 2HP 220VAC @ 50 HZ. (BLACK) (GREEN) GROUND HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 83 Wire #3 Wire #7 Black Wire Screw Connec tor (WHITE) 5585175 208-230VAC, 1 PH., 60 HZ. 2HP 220VAC @ 50 HZ. (BLACK) (GREEN) GROUND HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 84: Labels

    Labels HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 85 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 86 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 87 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 88: Parts Drawings

    SANTA PAULA, CA 93060 1799.0mm 48.355in TITLE: HDS-14 PRODUCTION 1228.2mm LIFT VER D (CE CERT) SIZE DWG. NO. 5260598 SCALE: 1:45 SHEET 2 OF 3 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 89 HDS/HDSO-14 POW ER SI DE POST W ELDM ENT 5620605 HDS/HDSO-14 POST W ELDM ENT 5216148 HDS-14 CROSSTU BE ASSEM BLY, SM ALL W I NDOW 1 5216147 HDS-14 CROSSTU BE ASSEM BLY, LARGE W I NDOW 1 5215072 HDS-14 POW ER SI DE RAM P ASSEM BLY...
  • Page 90 DO NOT SCALE I TEM NO NAME DATE DRAWN DIMENSIONS ARE IN MM NOTE: UNLESS OTHERWISE SPECIFIED REFER TO M ODEL FOR ADDITIONAL INFORM ATION HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 91 I TEM PART DESCRI PTI ON QTYREV NU M BER 5601826 HDS-14 CROSSTU BE W ELDM ENT, SM ALL W I NDOW 5215013 HDS-14 CROSSTU BE SHEAVE ASSEM BLY 5575380 D4-12, HD/HDS/HDSO-14 SAFETY ROLLER 5600044 4 POST LI GHT DU TY SLACK SAFETY W ELDM ENT...
  • Page 92 D4-12, HD/HDS-14 PARTS BAG 5215096 PU SH BU TTON AI R ASSEM BLY 5505009 D4-12, HD/HDS-14 DRI VE U P RAM P PI N 5600406 HD/HDS-14 TOP PLATE W ELDM ENT 5700029 HD-SERI ES FLEX TU BE BRACK ET PLATE...
  • Page 93 I TEM NO W ELDM ENT NAME DATE DRAWN DIMENSIONS ARE IN MM NOTE: UNLESS OTHERWISE SPECIFIED REFER TO M ODEL FOR ADDITIONAL INFORM ATION HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 94 PROHIBITED. ISOM ETRIC VIEW FOR REFERENCE ONLY DO NOT SCALE I TEM NO NAME DATE DRAWN DIMENSIONS ARE IN MM NOTE: UNLESS OTHERWISE SPECIFIED HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 95 SANTA PAULA, CA 93060 1970.0mm 1799.0mm TITLE: HDS-14X PRODUCTION 48.355in LIFT VER D (CE CERT) 1228.2mm SIZE DWG. NO. 5260599 SCALE: 1:50 SHEET 2 OF 3 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 96 HDS/HDSO-14 POW ER SI DE POST W ELDM ENT 5620605 HDS/HDSO-14 POST W ELDM ENT 5216148 HDS-14 CROSSTU BE ASSEM BLY, SM ALL W I NDOW 1 5216147 HDS-14 CROSSTU BE ASSEM BLY, LARGE W I NDOW 1 5215241 HDS-14X POW ER SI DE RAM P ASSEM BLY...
  • Page 97 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: HDS-14X POWER SIDE RAM P ASSEM BLY SIZE DWG. NO. 5215241 SCALE: 1:15 SHEET 2 OF 2 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 98 D4-12, HD/HDS-14 PARTS BAG 5215096 PU SH BU TTON AI R ASSEM BLY 5505009 D4-12, HD/HDS-14 DRI VE U P RAM P PI N 5600406 HD/HDS-14 TOP PLATE W ELDM ENT 5216139 FLEX TU BE K I T, U P TO 2000mm...
  • Page 99 AGOURA HILLS, CA 91301 2275.0mm 2104.0mm TITLE: HDS-14XT PRODUCTION 60.363in LIFT VER A 1533.2mm SIZE DWG. NO. 5260716 SCALE: 1:50 SHEET 2 OF 3 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 100 SHEET 3 OF 3 I TEM NO NAME DATE DRAWN DIMENSIONS ARE IN MM NOTE: UNLESS OTHERWISE SPECIFIED REFER TO M ODEL FOR ADDITIONAL INFORM ATION HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 101 I TEM NO NAME DATE DRAWN DIMENSIONS ARE IN MM NOTE: UNLESS OTHERWISE SPECIFIED REFER TO M ODEL FOR ADDITIONAL INFORM ATION HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 102 D4-12, HD/HDS-14 PARTS BAG 5215096 PU SH BU TTON AI R ASSEM BLY 5505009 FL14/HD/HDS-14 DRI VE U P RAM P PI N 5600406 HD/HDS-14 TOP PLATE W ELDM ENT 5216139 FLEX TU BE K I T, U P TO 2000mm...
  • Page 103: Certificate Of Conformity

    Certificate of Conformity HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 104 HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 105: Automotive Lift Institute (Ali) Store

    The ALI Store is your trusted source for workplace safety! Visit today and get the training and materials you need to work safely: http://www.autolift.org/ali-store/ HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 106: Maintenance Logs

    Maintenance Log HDS-14 / HDS-14X / HDS-14XT Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 107 Maintenance Log HDS-14 and HDS-14X Four Post Lifts P/N 5900161 — Rev. H — September 2024...
  • Page 108 30440 Agoura Road Agoura Hills, CA, 91301 USA bendpak.com © 2024 BendPak Inc. All rights reserved.
