Section 1: Scoreboard Setup - Funtronix SCORE-N-TIME SNT-344M Operating Manual

1. If you are using the scoreboard without an AC adapter, open the two battery covers located on the
back-side of the scoreboard and install 8 C-size alkaline batteries (not included). Close the battery
covers.
2. The wireless keypad requires AAA-size alkaline batteries (included). To install or replace these batteries
follow the instructions in Section 9.
3. Use the optional AC adapter if operating the scoreboard near an electrical outlet to conserve batteries.
4. Extend the fold-out leg and lock in place. Place
scoreboard on stable table or floor.
5. Place the scoreboard in a desired location near your playing field. The best location is mid-court on
the sidelines. This will provide the best view of the display. It can also be placed in the corner of the
playing field, as long as everyone in the opposite corner of the field can view it and is within radio
range of the keypad.
6. Follow the next steps when connecting your keypad to the scoreboard:
6.1 For scoreboard operation using a corded sit-behind
keypad, follow the next three steps:
• Make sure scoreboard is turned off before
connecting keypad.
• Connect your CK-300M corded keypad to the
connector found on the back-side of the scoreboard.
• Turn the scoreboard on using the power switch located on the back of the scoreboard.
Proceed to Step 7.
NOTE: The scoreboard power must be off when attaching the corded sit-behind LCD
keypad.
7. Select the display brightness by pressing and holding the GUEST
seconds. Each press and hold of this button will toggle between the low, mid, and high brightness
levels.
You are now ready to use your scoreboard. Proceed to Section 2 for instructions on using your scoreboard.

SECTION 1: SCOREBOARD SETUP

5
Keypad connector found on the
back-side of the scoreboard
button for approximately 3
