Summary of Contents for Vive Comfort TP-N-HP21
- Page 1 Operation Manual Operation Manual 尺寸：120*120mm 材质：105g铜版纸，一颗骑马钉，彩印...
- Page 2 TP-N-HP21 Vive Comfort Web: www.vivecomfort.com Table of Contents Page Caution: Table of Contents Thermostat Operation Equipment damage hazard. Do not switch the system to Thermostat Quick Reference 4-10 cool if the temperature is Warranty Information below 50ºF (10ºC). Una version en español...
-
Page 3: Thermostat Operation
Thermostat Operation Thermostat Operation LCD Display System Switch See page 4 for details about Selects the operation mode on this display read out. your HVAC system. ① Selecting HEAT turns on the Fan Switch heat mode. Selecting COOL Select ON or AUTO. ON will run ③... -
Page 4: Thermostat Quick Reference
Thermostat Quick Reference Thermostat Quick Reference Important: The thermostat will operate from 2 size “AA” alkaline batteries or 24VAC power. When operated from batteries, connection to the “C” (common) or (neutral) terminal is not required. NOTE: When operated from batteries only, the LCD display backlight will be lighted less than 5 seconds after each button pressed, when backlight option are set to 2) or 3). - Page 5 Thermostat Quick Reference Thermostat Quick Reference Con guration operation Filter review Move the SYSTEM switch to the HEAT or COOL position, then press and The con guration menu allows you to set certain thermostat operating hold the buttons for 5 seconds to review lter running days. characteristics to your system or personal requirements.
-
Page 6: Troubleshooting
Thermostat Quick Reference Thermostat Quick Reference Set Time Troubleshooting Move the SYSTEM switch to the OFF position, then press and hold the ▼ If a voltage spike or static discharge blanks out the display or causes erratic thermostat operation, you can reset the thermostat by pressing the reset buttons for 5 seconds to enter the clock setting mode. -
Page 7: Warranty Information
Thermostat Quick Reference Warranty Information Troubleshooting (Continue...) Warranty Registration 4. Select lter replacement run time Your new thermostat has 1 year limited warranty. You must register The thermostat will display the Filter Alarm after a set time of operation. This is your thermostat within 60 days of installation. -
Page 8: Speci Cations
Speci cations Installation Manual Power Supply......20VAC-30VAC 50-60HZ or Battery power for display not control TP-N-HP21 Terminal Load......1.0A per terminal, 3.0A maximum total load Set Point Temp. Range..45ºF to 90ºF (7ºC to 32ºC). Accuracy........+/- 1ºF or +/- 0.5ºC. Vive Comfort Web: www.vivecomfort.com Dimensions......6.0”... -
Page 9: Installation Tips
Subbase Installation Installation Tips Mount Thermostat Horizontal Mount Installation Tip: Electrical Hazard Vertical Mount Always turn off power at the main power 1. Push the button to open source by removing the fuse, or switch thermostat front cover the circuit breaker to the off position before installing, removing, cleaning, or servicing this thermostat. -
Page 10: Getting To Know Your Thermostat
Thermostat Quick Reference Thermostat Quick Reference Getting to know your thermostat Getting to know your thermostat ① ③ ⑤ ② ④ Figure 5 Figure 4 Indicates the current room temperature Time and day of the week LCD Display System Switch See page 5 for details about Selects the operation mode on your HVAC system. - Page 11 Important WARNING ! Installing batteries backwards can damage the thermostat. Electrical Shock Hazard 1. Install two fresh “AA” alkaline batteries in the battery compartment. Be sure to match positive (+) ends of batteries with positive (+) battery terminals in the battery Turn off...
-
Page 12: Wiring Diagrams
Wiring Terminal Designations Wiring Diagrams Power from C wire(Without battery) Heat Pump System 1 HEAT 1 COOL / 2 HEAT 1 COOL Transformer Power Transformer Common Changeover Valve Energized in HEAT 2H/1C conventional wiring diagram Changeover Valve Energized in COOL Fan Relay Auxiliary Heat (Require a jumper to connect Aux and E in two stage of heating) - Page 13 Con guration and operation Displayed Press Press ▲ or ▼ Step (Factory Buttons Description to select Defaults) The con guration menu allows you to set certain thermostat operating ▲ ▼ Select (FA)st or (SL)ow cooling characteristics to your system or personal requirements. Move the SYSTEM CC (FA) FA or SL 5 seconds...
- Page 14 C O M F O R T www.vivecomfort.com...
