L9-ET-C-IP66
INSTRUCTION MANUAL
EMERGENCY LIGHTING AND
POWER EQUIPMENT
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To prevent electric shock, switch off the mains power supply until installation is complete and AC
power is supplied to this product.
2. This product requires an un-switched AC power supply of 120-277V, 50/60Hz.
3. Make sure all connections are in accordance with the National or Canadian Electrical code and
any local regulations.
4. To reduce the risk of electrical shock, disconnect both normal and emergency power supplies
and connector of this product before servicing.
5. It can provide minimum 90 minutes illumination under the emergency mode.
6. The product is UL Listed for field installation, and use with grounded, Listed fixtures and the
case should be grounded.
7. This product is suitable for use in outdoor or wet locations.
8. Use this product in -40°C minimum, 50°C maximum ambient temperatures (Ta).
9. Do not mount near gas or electric heaters.
10. Do not attempt to service the batteries. A sealed, non-maintenance battery is used that is not
field replaceable. Contact the manufacturer for information or service.
11. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition and void warranty.
12. Do not use this product for other than intended use.
13. Installation and service should be performed by qualified service personnel.
14. This product should be mounted in locations and at heights where it will not be subjected to
tampering by unauthorized personnel.
THIS PRODUCT CONTAINS A RECHARGEABLE LI-ION BATTERY.
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Li-ion
Assurance Emergency Lighting, a division of Assurance Engineering LLC, 357 Cumberland Street Memphis, TN 38112 1-877-774-4775 AssuranceLighting.com
SAVE THESE INSTRUCTIONS
Assurance
Emergency Lighting
a d i v i s i o n o f A s s u r a n c e E n g i n e e r i n g L L C
Toll Fee: 1-877-774-4775
AssuranceLighting.com
28E24
BC
3KLH
E506473
