IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C. power
1.
is supplied to the unit.
2.
CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and by disconnect-
ing the unit connector.
CAUTION – This is a sealed unit. The integral, high temperature Ni-Cad battery is not replaceable. Replace the
3.
entire unit when necessary and recycle or dispose of the nickel-cadmium battery properly.
4.
DO NOT USE OUTDOORS. The RHB1201 is for use with grounded, UL Listed, damp location rated, indoor
fixtures. Not for use in heated air outlets or hazardous locations.
The RHB1201 requires an unswitched A.C. power source of either 120 or 277 volts. Properly cap the unused A.C.
5.
lead.
When the RHB1201 is installed on the same branch circuit, refer to Illustration 3, Figures A and B for input wiring.
6.
When installed on separate branch circuits, refer to Illustration 3, Figures C and D for input wiring. Per NEC, the
RHB1201 and A.C. ballast must be on the same panel board.
7.
Do not mount near gas or electric heaters.
The RHB1201 should be mounted in locations and at heights where it will not readily be subjected to tampering
8.
by unauthorized personnel.
The RHB1201 will cold strike and operate one 14W through 54W T5 or 2´-4´ T8 instant start or rapid start fluo-
9.
rescent lamp, including energy saving and 4-pin compact lamps for 90 minutes.
10.
The RHB1201 is compatible with most A.C. ballasts (including multiple lamp) as follows:
Magnetic ballasts – one lamp emergency operation.
Electronic ballasts – one lamp emergency operation.
11.
Suitable for use in damp locations and enclosed and gasketed fixtures.
12.
For use in 0° C minimum, 50° C maximum ambient temperatures.
13.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
14.
Do not use this equipment for other than intended use.
15.
Install in accordance with the National Electrical Code and local regulations.
16.
Installation and servicing should be performed by qualified personnel.
17.
Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility
before final installation.
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS
RHB1201
TBTS SERIES AC
EMERGENCY
LIGHTING EQUIPMENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHB1201 and is the answer not in the manual?

Questions and answers

Summary of Contents for Assurance Emergency Lighting RHB1201

  • Page 1 When the RHB1201 is installed on the same branch circuit, refer to Illustration 3, Figures A and B for input wiring. When installed on separate branch circuits, refer to Illustration 3, Figures C and D for input wiring. Per NEC, the RHB1201 and A.C.
  • Page 2: Installation Instructions

    5. WIRING THE A.C. INPUT A. When the RHB1201 is installed on the same branch circuit, refer to Illustration 3, Figures A and B for input wiring. When installed on separate branch circuits, refer to Illustration 3, Figures C and D for input wiring. Per NEC, the RHB1201 and A.C.
  • Page 3: Completing Installation

    OPERATION Normal Mode – A.C. power is present. The A.C. ballast operates the fluorescent lamp(s) as intended. The RHB1201 is in the standby charging mode. The TBTS will be lit providing a visual indication that the battery is being charged.
  • Page 4: Typical Wiring Diagrams

    5. ONE LAMP INSTANT START BALLAST ONE LAMP RAPID START BALLAST ONE LAMP INSTANT START BALLAST SWITCHED OR UNSWITCHED LINE BLUE BLUE BLACK WHITE BLUE BLUE/WHT A.C. EMERGENCY RHB1201 RHB1201 RED/WHT BALLAST Ballast YELLOW WHT/BLK UNIT *LAMP CONNECTOR TBTS / CHARGE TBTS TBTS...
  • Page 5: Additional Wiring Diagrams

    For wiring diagrams of ballasts not shown, consult our Customer Service. 1. THREE LAMP RAPID START BALLAST THREE LAMP RAPID START BALLAST SWITCHED OR UNSWITCHED LINE BLACK BLUE BLUE/WHT WHITE EMERGENCY ORANGE RED/WHT RHB1201 A.C. ORANGE BLUE BALLAST Ballast YELLOW YELLOW BLUE YELLOW WHT/BLK BLU/WHT...
