- Page 1 VREC-H320SC VREC-H320SC-D DASH CAMERA Quick Start Guide Pioneer Electronics Australia Pty Ltd Unit 13, 135-155 Rooks Road, Vermont, Victoria, 3133, Australia Tel: (03) 9586-6300...
- Page 2 Unit 13, 135-155 Rooks Road, Vermont, Victoria, 3133, Australia Tel :(03) 9586-6300 Do not ship your unit in for repair without contacting Pioneer first. Always produce the warranty card with serial number affixed on it. Units sent without a return authorization number or without serial number will be refused.
-
Page 3: Safety Precautions
Precautions Information for users on collection and Warning disposal of old equipment and used batteries. • Do not install this product in your vehicle if its location or use would obstruct the driver’s clear view of (Symbol for Symbol example for the road or the operation of any equipment) batteries... -
Page 4: Precautions Before Installation
Periodically inspect the door. this product. • Pioneer recommends that only authorized service company • personnel, who have special training and experience in mobile electronics, set up and install this product. - Page 5 Packaging Contents 1N Dash Camera [VREC-H320SC or VREC-H320SC-D], 1N Power Adapter, 1N Power Cable, 1N Electrostatic Film, 1N Mount With Double-Sided Adhesive, 1N Quick Start Guide, 64GB SD card Product Appearance Rear camera connection System Indicator terminal (to connect rear...
- Page 6 Status Display The status display shows the operating status of this product. Recording in progress Elapsed recording time Event recording status Parking mode Sound recording*1 Wi-Fi connection status*2 GPS reception status*3 Date/Time/Vehicle speed *1 A red “\” is displayed when sound recording is set to OFF. *2 During a Wi-Fi connection, this is displayed in green, and when Wi-Fi is disconnected, this is displayed in white.
-
Page 7: During Playback
During playback 5 Back 6 Previous file 7 Next file 8 Play/pause, delete During MENU screen display 9 Back 10 Up 11 Down 12 Confirm Inserting and Ejecting the microSD Card Turn OFF the power to this product when inserting and removing the microSD card. Inserting the microSD Card Ejecting the microSD Card Hold the top edge of the microSD card,... - Page 8 Always install this product in the specified installation position to ensure a safe field of view while driving and to achieve full performance from the product. Pioneer is not liable for any damages due to faulty or improper installation or use of the...
- Page 9 Installing the Dash Camera • Route the power cable to the 1. Clean the installation area of dirt passenger seat side and oils using a clean cloth. A column Connecting cable 2. Install this product. (Included with the 2nd Peel off the double-sided tape This camera sold separately) Product...
- Page 10 Recommended Installation Position on Rear Windshield For installation on the rear glass, a 2nd camera (sold separately) is required. If installing only this product, then skip the instructions regarding installation on the rear glass. When installing the 2nd camera (sold 2.
-
Page 11: Connection Precautions
Direct connection with Vehicle Battery (Parking mode) Be sure to disconnect the y terminal of the vehicle’s battery before connecting the power cable. Parking mode can be enabled on this dash camera for which user have to purchase a Hardwire Kit and get it installed by a trained automobile technician. By using the power cable to draw power directly from the vehicle, this product can detect and record vehicle movement caused by vibration even when the vehicle’s engine is turned OFF. - Page 12 Parking Mode provides added security by monitoring your vehicle when it is parked, and the engine is turned OFF. This mode is especially useful for capturing video footage of incidents such as theft, vandalism, or collisions that may occur while your vehicle is unattended. When activated, the dash camera enters a state of low power consumption and starts recording if vibration (detected by the G-sensor) or motion is detected.
