ROOMS TO GO AUGR Elko RTG5888-HC Assembly Instructions

ASSEMBLY INSTRUCTIONS
*** Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and
heavy. Therefore, two people are recommended in order to prevent personal injury and ensure the parts are not
damaged during the assembly
No.
A
Chair Back With Seat
BL
Left Front Leg
BR
Right Front Leg
CL Left Back Leg
Right Back Leg
CR
DL Left Stretcher
DR Right Stretcher
Hardware Pack Location(s):
AUGR RTG5888-HC HOST CHAIR
MADE IN VIET NAM
AUGR RTG5888-HC HOST CHAIR
Manufactured by AUGR for
.
Part list
CR
CR
1
3
- SKU# 42658899
- SKU# 42658899
ROOMS TO GO
Qty No.
1pc
1
2
3
1pc
TOOLS REQUIRED (NOT PROVIDED)
1pc
Phillips Screwdriver
1pc
1pc
1pc
1pc
CL
Residential Use Only
Hardware List
Bolt Ø5/16"-18 x 2"
Spring Washer Ø5/16"
Flat Washer Ø5/16"
Screw #4 x 1-1/2"
Allen Key M4
A
Version 1 - 08/05/2024
Qty
8pcs
8pcs
8pcs
4pcs
1pc
CL
1
3
1 of 2
