ROOMS TO GO AUGR RTG1576-60H Assembly Instructions

Caution: Please read instructions thoroughly before unpacking assembly parts.
1. We recommend that you assemble this product with the assistance of another person. This will make assembly easier and
help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during shipment.
3. Please put all parts on a non-abrasive surface and follow the assembly steps to assemble your newly purchased product
correctly and efficiently.
No
1
Wood Screw
*Above Hardware Parts packed in RTG1576-65F for assembly.
STEP 1
Loosen the Allen Bolt, Spring Washer, Flat Washer in the Headboard Leg
(B) and Footboard (D) with Allen Wrench (2). Do not remove the bolt,
leave it inserted halfway.
STEP 2 (Option 1 - Low Position)
Thread Long Support Legs (F) into the insert nut on Slats (E).
Short Support Legs (E) will not be use in Option 1.
D
Hardware Pack Location(s):
AUGR RTG1576-60F QUEEN PANEL FOOTBOARD
ASSEMBLY INSTRUCTIONS
AUGR RTG1576-60H QUEEN PANEL HEADBOARD
AUGR RTG1576-60F QUEEN PANEL FOOTBOARD
AUGR RTG1576-60R QUEEN & KING SIDE RAILS
Hardware List
Ø8x32mm
A
C
MADE IN VIETNAM
Qty No Description
8pcs
A Headboard
*Above Parts packed in RTG1576-60H.
B Footboard
Slats
C
D Long Support Leg
E
Short Support Leg
B
*Above Parts packed in RTG1576-60F.
F
Side Rails
*Above Parts packed in RTG1576-60R.
Assembly Requires Phillips Head screwdriver (not included).
2
STEP 2 (Option 2- High Position)
Thread Short Support Legs (G) into the insert nut on Slats (E) and
then Thread Long Support Legs (F) into the insert nut on Short
Support Legs (G) as show below.
SKU: 32315764
SKU: 32715762
SKU: 32915766
Sketch Qty
1pc
1pc
4pcs
4pcs
4pcs
2pcs
C
E
D
SKU: 32715762
Page 1 of 2
