LOXONE NFC Code Touch Air Quick Start Manual

Technical Specifications
Power supply 9 ... 28VDC or 2xAAA batteries
Power consumption typ. 0.05W, max. 0.8W
(while reading NFC)
Power loss max. 0.8W
Battery lifetime up to 2 years
Interfaces Loxone Air: 868MHz (SRD Band
Europe), 4 channels available,
max. Power 15.1mW e.r.p.
915MHz (ISM Band Region 2),
10 channels available, max.
Power 13.2mW internal antenna
Ambient temperature -20 ... 60°C / -4 ... 140°F
Humidity max. 95% r.H. (non condensing)
Touch points capacitive touch detection
Click feedback
Yes
Access possibilities NFC, Key code
NFC Frequency: 13.56MHz
Safety rating IP44
Maintenance & Cleaning
This device is free of
maintenance and may only
be cleaned with a dry cloth.
For more information
about this product, visit
loxone.com/nfc-code-touch-air-2
Loxone Loxone UK
Electronics GmbH The Forum
Smart Home 1 Station Road
4154 Kollerschlag Theale, RG7 4RA
Austria United Kingdom
For additional information,
declaration of conformity, visit
www.loxone.com/datasheets
Need Help?
loxone.com/support
NFC
Code
Touch
Air
V270623
Part No.: 100483 (White)
Part No.: 100482 (Anthracite)
