Air Quality Engineering SMOKEMASTER X-11Q Owner's And Service Manual

Self-contained electronic air cleaners
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER AND SERVICE MANUAL
SMOKEMASTER ® MODELS C-12,
SELF-CONTAINED ELECTRONIC AIR CLEANERS
Mail:
Air Quality Engineering
7140 Northland Drive N.
Brooklyn Park, MN 55428
USA
© 2015
Air Quality Engineering, Inc. copyrights this manual with all rights reserved. Under the
copyright laws, this manual may not be reproduced in any form, in whole or in part,
without the prior written consent of Air Quality Engineering, Inc.
All statements, technical information and recommendations in this manual or related
documents are believed reliable, but the accuracy and completeness thereof are not
guaranteed or warranted, and they are not intended to be, nor should they be
understood to be representation or warranties concerning the products described.
Specifications are subject to change without notice.
These air cleaners have not been tested for compliance to California Air Resource Board requirements and are not
available for sale, resale or installation in California.
X-11Q and X-400
Phone:
1.800.328.0787
763.531.9823
Fax:
763.531.9900
e-mail:
info@air-quality-eng.com
web:
www.air-quality-eng.com
CAUTION!
SHARP EDGES
WEAR GLOVES FOR
INSTALLATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the SMOKEMASTER X-11Q and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Air Quality Engineering SMOKEMASTER X-11Q

Summary of Contents for Air Quality Engineering SMOKEMASTER X-11Q

  • Page 1 © 2015 Air Quality Engineering, Inc. copyrights this manual with all rights reserved. Under the copyright laws, this manual may not be reproduced in any form, in whole or in part, without the prior written consent of Air Quality Engineering, Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRINCIPLES OF OPERATION INTRODUCTION C-12 SPECIFICATIONS X-11Q SPECIFICATIONS X-400 SPECIFICATIONS SAFETY PRECAUTIONS COMPONENTS PARTS LIST INSTALLATION 10-16 CHECKOUT OPERATING INSTRUCTIONS MAINTENANCE SERVICE 19-21 ELECTRICAL SCHEMATICS 22-24 ELECTRICAL TROUBLESHOOTING WARRANTY PRINCIPLES OF OPERATION HOW YOUR ELECTRONIC AIR CLEANER WORKS A process called “Electrostatic Precipitation”...

  • Page 3: Introduction

    INTRODUCTION Your SMOKEMASTER Electronic Air Cleaner is Recommended quantities of clean outdoor ® an advanced self-contained electronic air ventilation air for various applications are cleaner. The model C-12, X-11Q and X-400 described in Table 2 of the ASHRAE Standard indoor air pollution control units offer low cost, 62-89, “Ventilation for Acceptable Indoor Air energy efficient air cleaning solutions with Quality.”...

  • Page 4: X-11Q Specifications

    X-11Q SPECIFICATIONS DIMENSIONS: 48” x 24” x 13 5/8”; AMBIENT TEMPERATURE RATING: [1218 mm x 609 mm x 436 mm] Shipping and Storage: -40°F to +150°F; [-40°C to +66°C] WEIGHT: 101 Lbs. [46 Kg] shipping; 83 Lbs. [38 Kg] installed, including electronic cells. Each Size Range Efficiency cell weighs 9 ½...

  • Page 5: Safety Precautions

    Do not disassemble or modify. - Fire and/or electrical shock may occur as a result. For repair, contact your dealer or Air Quality Engineering, Inc. Do not damage power cord or use unit with a damaged power cord. Fire, electrical shock, and/or damage may occur as a result.
  • Page 6 Fan Motor - Motor driven fan operates at three Adjustable Exhaust Grille - Four louvered speeds. Elastomeric suspension system exhaust grilles direct the cleaned air in four eliminates vibration noise. directions. X-400 COMPONENTS COMPONENTS OF THE X-400 ELECTRONIC Power Supply – Solid state power supply assures AIR CLEANER trouble-free, highly reliable service.

  • Page 7: Parts List

    C-12 Parts List Figure 2: C-12 Parts Breakdown Part Number Description 120V 220V 60 Hz 50 Hz Models Models 1 Prefilter 41009 (2) 41009 (2) 2 Electronic Cell 38001 (2) 38001 (2) 3 Contact Board Assembly 46113 (2) 46113 (2) 4 Power Supply 07071 07089...
  • Page 8 X-11Q PARTS LIST Figure 3: X-11Q Parts Breakdown DESCRIPTION PART # Motor Replacement Kit/60 Hz 05299 Motor Replacement Kit/50 Hz 05360 Grille Assembly 05112 Prefilter 41021 Louver Assembly 05113 Heavy Duty Prefilter 41107 Power Module Assembly/60 Hz 05116 Contact Board Assembly 05110 Power Module Assembly/50 Hz 05367...
  • Page 9 X-400 Parts List Figure 4: X-400 Parts Breakdown Part Part 11 Power Supply 07099 07106 Description 60 Hz 50 Hz 1 Grille Assembly 05298 05298 Parts Not Part Illustrated 2 Speed Control Switch 10110 10110 Ionizer Wire 38004 3 Interlock Switch 10106 10203 Carbon Filters...

  • Page 10: Installation

    C-12 INSTALLATION Over 14 inches [355 mm] from the ceiling, the IMPORTANT! effect is not a problem. But in the space between, Read these instructions carefully. A slow moving, dirty air is drawn into the area of the hazardous condition or damage to the discharge outlets and can stain a light colored product could result if instructions are not ceiling.

  • Page 11: Wall Mounting

    both directions. This makes it easy to fasten the Be sure that you select a strong structural part air cleaner directly to the ceiling framework with 8 of the ceiling. Do not fasten it to a false ceiling or inch lag screws. Leave space for the power cord to plaster or plaster-board.

  • Page 12: Equipment Needed

    X-11Q and X-400 INSTALLATION ITEMS SUPPLIED AS LOOSE PARTS IMPORTANT!  Two support bars Read these instructions carefully. A  Six #8, self-tapping, sheet metal screws hazardous condition or damage to the  Four flat washers (Two for X-400) product could result if instructions are not ...
  • Page 13 MOUNTING 1. Attach four 12-gauge, galvanized steel support wires to the true ceiling at the location shown in Figures 10 and 11. Twist each wire at least four times to provide safe support for the air cleaner. The free end of each wire should extend six inches or more below the bottom of the T-bars.

  • Page 14: Electrical Installation

    C-12 ELECTRICAL INSTALLATION CAUTION! Only persons qualified to install electrical wiring should attempt this procedure. All wiring must comply with applicable codes and ordinances. WIRING 4. Connect lead wires with solderless connectors including ground (green) wires. The 120V, 60 Hz C-12 has a standard 3-prong Proper grounding of this device is plug on a 10 foot [3 m] power cord.
  • Page 15 X-11Q and X-400 ELECTRICAL INSTALLATION CAUTION! Only persons qualified to install electrical wiring should attempt this procedure. All wiring must comply with applicable codes and ordinances. 1. Locate an unswitched 120V, 60 Hz or 220V, 50 Hz power circuit with a junction box near Figure 13: X-11Q Input Wiring the air cleaner location.
  • Page 16 *Orienting a louvered grille to blow air back toward the intake grille (fourth direction) is not recommended since good circulation of cleaned air in the room is defeated. Figure 15: X-11Q Louver Orientation X-400 ASSEMBLY COMPLETION 6. Press the test button. An audible snap 1.

  • Page 17: Checkout

    CHECKOUT 1. Make sure the air cleaner is securely 5. Turn the electrical power back on. fastened to the true ceiling. 6. Make sure the fan runs on all three-speed 2. Replace the power module (X-11Q only) and settings. The system light should be on reconnect the electronic plugs.

  • Page 18: Maintenance

    The intake grille may be removed from the machine for periodic washing. A wash kit is 7. Check the electronic cells for broken wires and available from Air Quality Engineering. bent collector plates. The cells may be installed in the air cleaner and energized. The 1.

  • Page 19: Service

    SERVICE 5. Remove the screws holding the motor to the unit to remove the motor. WARNING! 6. Install the new motor, connect the electrical lines and replace the fan, cells, prefilter and The following instructions are intended for grille. qualified service personnel only. Dangerous line voltage circuits are exposed during this 7.
  • Page 20 power module to swing forward and drop c. Charcoal/grey and pink high down. voltage wires (one each) at power supply. 5. With the power module on a workbench, remove the back cover from the power module 5. Cut wire ties holding the above wires to the air by removing eight sheet metal screws.
  • Page 21 Figure 18: Ionizer Wire Replacement...

  • Page 22: Electrical Schematics

    C-12 ELECTRICAL SCHEMATIC...
  • Page 23 X-11Q ELECTRICAL SCHEMATIC...
  • Page 24 X-400 ELECTRICAL SCHEMATIC...

  • Page 25: Electrical Troubleshooting

    If arcing still occurs when the cell is clean and Be sure the electronic cells are in place, the dry, consult your Air Quality Engineering, Inc., intake grille is closed and the unit is turned on. representative or dealer for repair.
  • Page 26 Notes:...
  • Page 27 Notes:...

  • Page 28: Warranty

    (“product”) fail to perform by reason of improper workmanship or material, Air Quality Engineering, Inc., (AQE) will, during the period of one (1) year from the date of original purchase either (i) replace the Product or (ii) provide all necessary parts to repair the Product, without charge.

This manual is also suitable for:

Smokemaster c-12Smokemaster x-400
