- Page 1 Item No. 554RNDFHSS, 554RNDFHSTL, 554RNDFHBLK, 554RNDFHBZ ROUND PATIO HEATER User Manual Retain this manual for future reference. Unit must be kept clear of combustibles at all times. 3177588...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Owner’s Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Information . -
Page 3: Safety Information
SAFETY INFORMATION Read the Manual: Thoroughly read and understand the manual before setting up, operating, or cleaning the Commercial Electric Heater. Ventilation: Ensure the heater has sufficient ventilation. Do not use in buildings, garages, or other enclosed areas. May be installed with shelter if it meets the following conditions: •... -
Page 4: Safety Warning
SAFETY WARNING • Hose Leak Test: Always test the hose for leaks with soapy water at both connections. • Rain Precautions: Never use the heater while it is raining; the glass tube can break when suddenly met with water. Always turn off the heater while it is raining. Never splash any liquid onto the glass tube when the heater is working. -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS PARTS LIST Components: A: Reflector G: Burner B: Reflector Plate H: Tank Housing C: Heat Insulation Plate I: Belt D: Flame Screen J: Wheel Assembly E: Glass Tube K: (3) Mesh Guards F: Glass Tube Ring L: (3) Anchoring Arms HARDWARE M5 x 12 M5 Nuts... - Page 6 ASSEMBLY INSTRUCTIONS Step 1 Wheel Assembly Position the Tank Housing: • Flip the tank housing (H) upside down to provide easier access to the base. 2. Attach Wheel Assembly: • Position the wheel assembly (J) at the base of the tank housing (H). •...
- Page 7 ASSEMBLY INSTRUCTIONS Step 3 Glass Tube Ring Attachment Remove Preassembled Screws: • Carefully remove the three preassembled screws (EE) from the top of the burner (G). 2. Attach Glass Tube Ring: • Align the glass tube ring (F) with the top of the burner (G).
- Page 8 ASSEMBLY INSTRUCTIONS Step 5 Mesh Guards Installation Attach Mesh Guards: • Position the three mesh guards (K) onto the hooks located at the top of the burner (G). • Secure the bottom of the mesh guards using three M5 nuts (DD). Place the guards (K) •...
- Page 9 ASSEMBLY INSTRUCTIONS Step 7 Heat Insulation Plate Installation Position Double Headed Screws: • Insert the three M8 x 65 double headed screws (HH) into the heat insulation plate (C). 2. Secure Double Headed Screws: • Ensure the double head screws are properly aligned and tightly secured to the heat insulation plate (C) and...
- Page 10 ASSEMBLY INSTRUCTIONS Step 9 Final Reflector Assembly Secure Reflector: • Align the reflector assembly (A+B) with the top of the insulation plate (C). • Use three M8 nuts (II) and three flat washers (JJ) to attach the reflector assembly to the burner. •...
-
Page 11: Operation
OPERATION Installation of Tank Step 1: Gas Cylinder Requirement: • Provide Propane Gas and Cylinder: Use a standard 20 lb. propane cylinder only (Figure 1). 12.125" Figure 1 20lb. Propane Cyclinder 17.625" Ensure the Heater is used only with a propane vapor withdrawal supply system. •... - Page 12 Cylinder Handling and Storage • Storage Restrictions: Do not store a spare LP gas cylinder under or near the appliance. Store the cylinder outdoors in a well-ventilated area, out of reach of children. A disconnected cylinder must have dust caps tightly installed and must not be stored in a building, garage, or any other enclosed area.
- Page 13 Black Cylinder Valve Coupling Nut Pressure Relief Valve Turn Clockwise to Connect. Regulator Bleed-Off Valve Turn Clockwise Figure 3 to Reseal. Step 3: Connect the Regulator to the Gas Cylinder Valve • Close the Gas Supply: Turn the cylinder valve clockwise to close the gas supply on the gas cylinder. Refer to Figure 3.
- Page 14 Flame Height Observe flame height when lit. Flame should be a yellow/blue color between 20 to 28 inches high. • Lighting Instructions: 1. Battery Check: Ensure a AA battery (not included) is inside the ignition chamber and has power. The anode (+) should face outward. 2.
-
Page 15: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Regular Maintenance: Keep exterior surfaces clean. Use warm, soapy water for cleaning. Never use flammable, corrosive, or abrasive cleaners. • Burner and Pilot Assembly: Ensure the area around the burner and pilot assembly remains dry. If the gas control is exposed to water, do not use it;... - Page 16 Storage Instructions • Between Uses: 1. Turn Off the Heater: Turn the control knob to the OFF position. 2. Turn Off the LPG Cylinder: Turn the LPG cylinder valve to the OFF position. 3. Store the Heater Upright: Store the Heater upright in an area sheltered away from weather conditions such as rain, sleet, hail, snow, and wind.
