85368 Rev. C
PITCH PRO
Part #: 10540; 10541, 10542, 10543, 10544,
10545
Instruction Manual
Do not throw instructions away.
Read and understand instructions before
using this equipment.
2
Introduction
2
Applicable Safety Standards
2
Worker Classifications
3
Product Specific Applications
3
Weight Capacities
3
Maintenance, Cleaning, and Storage
3
Limitations
5
Compatibility
5
Components and Specifications
6
Installation and Use
8
Safety Information
9
Labels
10
Diagram
10
Inspection
11
Inspection Log
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Guardian PITCH PRO 10540
Summary of Contents for Guardian PITCH PRO 10540
- Page 1 85368 Rev. C PITCH PRO Part #: 10540; 10541, 10542, 10543, 10544, 10545 Instruction Manual Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Weight Capacities Maintenance, Cleaning, and Storage Limitations Compatibility Components and Specifications Installation and Use Safety Information Labels Diagram Inspection...
-
Page 2: Applicable Safety Standards
Introduction CAUTION! Understand following Thank you for purchasing a Guardian PitchPro. definitions of those who will work near or This manual must be read and understood in its who may be exposed to a fall. entirety, and used as part of an employee training... -
Page 3: Product Specific Applications
6‘ (1.8 m), or up to 12’ (3.7 m) if used in immediately remove it from service, and contact combination with equipment explicitly certified Guardian to inquire about its return or repair. D-ring: Dorsal for such use. - Page 4 This chart details allowable working zones required to reduce risk of swing falls and improper side loading. ALWAYS adhere to information specified by chart. Anchor Distance From Working Distance Along Roof Working Direction from Leading Edge (Y) Edge (Either Direction) (X) Perpendicular (Ø) 6 ft (1.8 m) 8 ft (2.4 m)
-
Page 5: Components And Specifications
Compatibility Components and Specifications When making connections with PitchPro, Type A anchorage connector. eliminate all possibility of roll-out. Roll-out Minimum permitted service temperature: occurs when interference between a hook and -30° F (-34 ° C). the attachment point causes the hook gate to unintentionally open and release. -
Page 6: Installation And Use
applications only when used in combination Concrete: 6” (152 mm) thick and 2,500 psi. with Guardian HLL part # 30800, and only for Substrate fastener requirements (do not mix connection of a maximum 2 PFAS to HLL. fastener types): Wood: (12) #8 2.5”... - Page 7 For wood install, 8 fasteners Installation location must be selected and deemed compatible with PitchPro by a (center column and either adjacent Competent Person. column) must penetrate into truss/ support beam. PitchPro must lie flush against substrate. Place PitchPro selected installation...
-
Page 8: Safety Information
Safety Information Harnesses and connectors selected must be compliant with manufacturer’s instructions, and WARNING! Failure to understand and must be of compatible size and configuration. comply with safety regulations may result in Snap hooks, carabiners, and other connectors serious injury or death. Regulations included must be selected and applied in a compatible herein are not all-inclusive, are for reference fashion. - Page 9 Labels OSHA 1926.502 & 1910.140 ANSI Z359.18-17 Guardian PITCH PRO TYPE A- ANCHORAGE CONNECTOR Maximum 1 connection per anchor Materials: Powder-coated stainless steel Minimum Breaking Strength (MBS): 5,000 lb. (22,2 kN) User Weight Range (including tools and equipment): 100-420 lb. (45-191 kg) Minimum Service Temperature: -30°...
- Page 10 Inspection Diagram A - Connections Prior to EACH use, inspect PitchPro for deficiencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating, alteration, broken stitching, fraying, and missing or illegible labels. IMMEDIATELY remove PitchPro from service if defects or damage are found, or if exposed to forces of fall arrest.
-
Page 11: Inspection Log
Inspection Log Serial No: Date of first issue: Model #: User: Date: Results/Condition: Inspected by: Next Inspection Date:... - Page 12 This warranty is not transferable to any other Guardian service and does not apply to product that is resold after having been put into service. No other person, firm, entity, or the like is authorized to assume or assign for Guardian any other liability in connection with the sale or use of Guardian’s products.
