STEP 1 – KNOW YOUR PC'S OPERATING SYSTEM
You will need to know the exact version of Microsoft Windows installed in your computer. If you do not know or
are unsure, please proceed as follows to determine your version of the Microsoft Operating System.
On your desktop, right-click My Computer. Then select Properties. The version number of the Microsoft
Windows Operating System installed in your computer will be displayed on the General tab. Refer to the
following table for more detailed information.
Windows OS System Properties Description
Win 95A
Win 95B
Win 98
Win 98SE
Win 2000
Win NT
If you have questions regarding your PC system and the Microsoft Windows Operating System, please contact
your original PC manufacturer or Microsoft for assistance.
Before installing the SMC7003-PCI, it is important to verify that the ADSL data port RJ -11 jack is configured so that the center
two pins, pins 3 and 4, are used for ADSL data, otherwise the SMC7003-PCI will not make a proper connection. If the ADSL
data port installation uses pins 2 and 5 for data, then a wiring converter will be required. Do not alter or remove a wiring
converter if present. Consult with your ADSL service provider regarding a wiring converter or before attempting any wiring
changes.
4.00.950A
4.00.950B
4.10.1998
4.10.2222A 2nd Edition
5.00.2195
4.00.1381
I
NSTALLING THE
Release (Microsoft Web)
Windows 95 OSR1
Windows 95 OSR2
Window 98
Windows 98 2nd Edition
Windows 2000
Windows NT 4.0
SMC7003-PCI
3
