Connectivity Rules

When adding hubs (repeaters) to your network, please follow the
connectivity rules listed below for Ethernet or Fast Ethernet.
However, note that because switches break up the path for
connected devices into separate collision domains, you should not
include the switch or connected cabling in your calculations for
cascade length involving other devices.

1000 Mbps Gigabit Ethernet Collision Domain

Maximum Fiber Optic Cable Distance for 1000BASE-SX

Fiber Size
62.5/125 micron
50/125 micron

Maximum Fiber Optic Cable Distance for 1000BASE-LX

Fiber Size
9/125 micron

Maximum Cable Distance for 1000BASE-T

Type
Cat. 5, 5e
100-ohm UTP
Fiber Bandwidth
160 MHz/km
200 MHz/km
400 MHz/km
500 MHz/km
Fiber Bandwidth
N/A
Connector
RJ-45
C
ONNECTIVITY
Maximum Cable Length
2-220 m (7-722 ft)
2-275 m (7-902 ft)
2-500 m (7-1641 ft)
2-550 m (7-1805 ft)
Maximum Cable Length
2 m - 5 km (7 - 16404 ft)
Maximum Cable Length
100 m (328 ft)
R
ULES
2-5
