DELTA GROUP VIVOTEK TB9332-E User Manual

Thermal network bullet camera
Hide thumbs

Advertisement

Quick Links

Download this manual
VIVOTEK Thermal Network Bullet Camera
User Manual
TB9332-E
Issue
V1.0
Date
2024-09-02

Advertisement

loading
Need help?

Need help?

Do you have a question about the VIVOTEK TB9332-E and is the answer not in the manual?

Questions and answers

Related Manuals for DELTA GROUP VIVOTEK TB9332-E

Summary of Contents for DELTA GROUP VIVOTEK TB9332-E

  • Page 1 VIVOTEK Thermal Network Bullet Camera User Manual TB9332-E Issue V1.0 Date 2024-09-02...
  • Page 2 This page is left blank intentionally.

  • Page 3: Table Of Contents

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual Table of Contents Table of Contents ..........................i 1 Product Overview ........................3 1.1 Thermal Imaging Principles and Advantages ..............3 1.2 Device Structure ......................3 1.3 Device Dimensions ......................5 1.4 Out Wire Connection ....................... 6 1.4.1 The Multi-connector Cables .................
  • Page 4 Thermal Imaging Integrated Network Camera User Manual 4.6 FFC Control ........................49 4.7 Noise Reduction ......................51 5 AI Multiobject .......................... 52 6 Intelligent Analysis ........................54 6.1 Intrusion......................... 54 6.2 Single Line Crossing ..................... 57 6.3 Double Line Crossing ....................60 6.4 Multi-Loitering ......................

  • Page 5: Product Overview

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual 1 Product Overview 1.1 Thermal Imaging Principles and Advantages For any object, as long as its temperature is above the absolute zero (-273.15°C), although the object does not give out light, it can radiate infrared. The infrared is also known as thermal radiation.

  • Page 6: Physical Interface

    Thermal Imaging Integrated Network Camera User Manual Physical Interface Connection Network indicator The network is working normally, the light is on; When it is transferring data, the light is splash. SD card indicator The SD indicator has the following states: OFF: The SD card is not inserted.

  • Page 7: Device Dimensions

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual 1.3 Device Dimensions The Bracket With Junction Box Dimensions (unit: mm) Short Sunshield VIVOTEK TB9332-E (9mm) & TB9332-E (15mm) The Bracket With Junction Box Dimensions (unit: mm) Long Sunshield VIVOTEK TB9332-E (35mm) & TB9332-E (50mm)

  • Page 8: Out Wire Connection

    Thermal Imaging Integrated Network Camera User Manual 1.4 Out Wire Connection There are two ways to connect the Thermal Imaging Network Bullet Camera, the multi-connector cables and the integrated cable management bracket. Users can choose the corresponding method and installation method according to their bracket. 1.4.1 The Multi-connector Cables The following picture shows the multi-connector cable of the Thermal Imaging Network Bullet Camera.
  • Page 9 VIVOTEK Thermal Imaging Integrated Network Camera User Manual Multi-connector Combination Cable Multi-connector Combination Cables Core of Cable Functions Connection Audio output Connect to the external audio device such as the voice box. Audio input port (cable Input the audio signal and input) receive the analog audio signals from the sound pick-up device.

  • Page 10: Installation

    Thermal Imaging Integrated Network Camera User Manual Core of Cable Functions Connection Blue Alarm out 1 white Alarm in 1 com Green Alarm in 1 Pink RS485RS+ RS485 interface, connect to devices with PTZ function. Black / white RS485RS- 1.5 Installation 1.5.1 Preparations Tools needed (Not included) and supplied parts are shown below.

  • Page 11: Installation Mode

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual 1.5.2 Installation Mode The thermal imaging network bullet camera can be installed on the ceiling or the wall. You can select the appropriate installation according to your requirements. If the camera needs to be installed on the cement wall, you need to install the expansion screws (the mounting holes of the screws must be consistent with that of the support), and then install the support.
  • Page 12 Thermal Imaging Integrated Network Camera User Manual Step 4 Connect the multi-connector cable. Loosen screw 1 and screw 2, adjust the surveillance angle. Adjust the Surveillance Angle Step 5 After adjusting angle, fix screw 2 and screw 1 in turn to complete the installation.

  • Page 13: Quick Configuration

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual There are three pipe thread interface in the junction box, one of which needs to be used with cable gland, so our company provides two plugs. Figure 1-1 Installing Plug 2 Quick Configuration 2.1 Login and Logout To access the web interface through Microsoft Edge, Chrome or Firefox browser;...

  • Page 14: Homepage Layout

    Thermal Imaging Integrated Network Camera User Manual Login Page The default name is root. Create a password when you log in the system for first time to ensure system security. User can change the system display language on the login page. Step 1 Input the user name and password.
  • Page 15 VIVOTEK Thermal Imaging Integrated Network Camera User Manual Homepage Layout Elements on the Homepage Element Description Live Video View the real-time videos. Playback You can query the playback videos in this area if you plug in an SD card and open the recording. Configuration You can choose a menu to set device parameters, including the device information, image settings, audio...

  • Page 16: Browse Video

    Thermal Imaging Integrated Network Camera User Manual Element Description Sign Out, you can click the icon to return to the login page. Switch to No When users download the IPC Local Server, you can Plugin Play switch to plugin or no-plugin to play live video. Stream The visible light channel has two streams.
  • Page 17 VIVOTEK Thermal Imaging Integrated Network Camera User Manual The Plugin Download Page Step 1 Click “ Please download the latest plugin” to download the IPC Local Server plugin. Step 2 Open the download file; double-click to install the file. Step 3 Click “Run” to select the destination location. Select Destination Location Step 1 Click “Next”, ready to install the plugin.
  • Page 18 Thermal Imaging Integrated Network Camera User Manual Select Additional Tasks Step 2 Tick “Create a desktop shortcut” and click “Next” to install the plugin. Installing Step 3 Click “Finish” and complete the plugin installation.

  • Page 19: Changing The Password

    VIVOTEK Thermal Imaging Integrated Network Camera User Manual Complete to Install the Plugin Step 4 Reopen the browser after installing. If the repair tips are displayed when installing the control, please ignore the prompt and continue the installation. During installing the plugin, the browser should be closed. 2.4 Changing the Password Description You can click...

  • Page 20: Setting Local Network Parameters

    Thermal Imaging Integrated Network Camera User Manual Change Password Dialog Box Step 2 Enter the old and new passwords, and confirm the password. Step 3 Click OK. If the message "Change own password success" is displayed, the password is changed successfully.
  • Page 21 VIVOTEK Thermal Imaging Integrated Network Camera User Manual Step 2 Set the parameters. Parameter Description Setting IP Protocol IPv4 is the Internet Protocol [Setting method] which adopts a 32-bit address. Select a value from the drop-down list box. [Default value] IPv4 DHCP Enable DHCP;...
  • Page 22 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Default Gateway This parameter must be set if [Setting method] the client accesses the device Enter a value manually. through a gateway. [Default value] 169.254.45.1 Preferred DNS IP address of a DNS server. [Setting method] Server Enter a value manually.

  • Page 23: Thermal Settings

    Thermal Imaging Integrated Network Camera User Manual 3 Thermal Settings 3.1 Temperature Parameters Temperature parameters include: temperature unit, ambient temperature, cavity temperature, correctional coefficient area temperature display mode, and so on. The temperature and length unit are used for all parameters which occur at the software. The Open Temperature Measure should be enabled in advance, if not there are no temperature showing on screen, and the alarms settings are invalid.
  • Page 24 Thermal Imaging Integrated Network Camera User Manual Temperature Parameters Interface Step 2 Set the parameters according to the following table. Temperature Parameters Parameter Description Setting Temperature Enable to open temperature [Setting method] Measurements measure. Enable...
  • Page 25 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Temperature Units Celsius and Fahrenheit [Setting method] temperature units are available. Select a value from the drop-down list box. [Default value] Celsius Length Units Meters and Feet [Setting method] Select a value from the drop-down list box.
  • Page 26 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Font Border Enable to bold the font. [Setting method] Enable or disable [Default value] Disable Font Size Custom font size. There are [Setting method] three sizes can be chosen. Select a value from the drop-down list box.
  • Page 27 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Prevent Overheating You can enable it to prevent [Setting method] over heat function if Select a value from the temperature of the testing area drop-down list box. is too high. There are three [Default value] types, close, auto and manual.

  • Page 28: Ambient Temperature

    Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Mix Stream Mode This function is used for mixing [Default value] thermal and visible imaging. For Close the single thermal camera, it’s close by default. 3.2 Ambient Temperature Set the ambient temperature of camera, click “Apply” to save the setting, click “Refresh”...

  • Page 29: Temperature Alarm

    Thermal Imaging Integrated Network Camera User Manual 3.3 Temperature Alarm Operation Procedure Step 1 Choose Configuration > Thermal > Temperature Alarm. The Temperature Alarm page is displayed in the following picture. Temperature Alarm Configuration Step 2 Set the parameters according to the table below.
  • Page 30 Thermal Imaging Integrated Network Camera User Manual Temperature Alarm Configuration Parameter Description Setting Channel [Setting method] Select a value from the drop-down list box. [Default value] Measure Mode Set at temperature parameter interface. Enable Tick to enable the area alarm [Setting method] Tick Name...
  • Page 31 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Alarm Value Camera will alarm when the [Setting method] object temperature reaches the Enter a value manually. alarm value. [Default value] Maximum Alarm At section alarm type, the [Setting method] Value device would not alarm when Enter a value manually.
  • Page 32 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting The temperature of high Reflect [Setting method] temperature object. Temperature Enter a value manually. [Default value] 50.00 Enable to shield the temperature Ignore Object [Setting method] of area capturing AI object. Select a value from the drop-down list box.
  • Page 33 Thermal Imaging Integrated Network Camera User Manual Step 3 Set area. temperature Step 1. Select an area ID Step 2. Select type from the drop-list. Step 3. Press and hold the left mouse button, and drag in the video area to draw a temperature area, as shown in the picture below0.

  • Page 34: Privacy Zone Masking

    Thermal Imaging Integrated Network Camera User Manual 1. Select an area ID. 2. Click Clear. 3. Remove the tick of area ID. 4. Click Apply, the message “Apply success” is displayed, the temperature area is deleted successfully. Step 4 Click Apply. The message "Apply success"...

  • Page 35: Schedule Linkage

    Thermal Imaging Integrated Network Camera User Manual Privacy Zone Masking Step 2 Enable the Privacy Zone Masking. Step 3 Enable Privacy Zone Masking Display, then the setting masking areas will show on live video. Step 4 Left-click to select polygon area, right-click to save. Step 5 Click Apply to save the settings.
  • Page 36 Thermal Imaging Integrated Network Camera User Manual Step 2 Tick the output channel. Enable wanted linkage: “Alarm Record”, “SMTP”,”FTP Upload” , “Audible Alarm” Step 3 button. Step 4 Set schedule linkage. Method 1：Click left mouse button to select any time point within 0:00-24:00 from Click the armed icon to set the arming time.

  • Page 37: Parameter Description

    Thermal Imaging Integrated Network Camera User Manual NOTE When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected. Step 5 Click Apply. The message "Apply success" is displayed, the system saves the settings. Alarm output: Users should connect the external alarm device (such as siren) to alarm output cables.
  • Page 38 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Alarm Output When the device receives I/O alarm [Setting method] Mode signals, the device sends the alarm Select a value from the information to an external alarm device drop-down list box. in the mode specified by this parameter.
  • Page 39 Thermal Imaging Integrated Network Camera User Manual Alarm Record: Users insert the SD card in camera. The recording time is set at “Configuration > Device Record > Record Policy” interface. SMTP: At “ Configuration > Network > SMTP” interface, users should set the parameters of SMTP in advance.
  • Page 40 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Recipient_E- (Mandatory) Email address of [Setting method] mail_Address recipient 1. Enter a value manually. Recipient_E- (Optional) Email address of mail_Address recipient 2. Recipient_E- (Optional) Email address of mail_Address recipient 3. Recipient_E- (Optional) Email address of mail_Address...
  • Page 41 Thermal Imaging Integrated Network Camera User Manual FTP Upload: At “ Configuration > Network > FTP” interface, users should set the parameters of FTP upload in advance,. FTP Upload FTP Upload Parameters Parameter Description Setting FTP Upload Indicates whether to enable the [Setting method] FTP service.
  • Page 42 Thermal Imaging Integrated Network Camera User Manual Audible Alarm: At “ Configuration > Alarm > Audible Alarm Output” interface, users should set the parameters of Audible Alarm output in advance. Audible Alarm Output to upload the audible file (The type should User can set the audio file manually.

  • Page 43: Defect Pixel Correction

    Thermal Imaging Integrated Network Camera User Manual Upload Audio File 3.6 Defect Pixel Correction Description The points that can’t move when the environment or scenario change is defect pixel. You can correct the these points manually. Procedure Step 1 Choose Configuration > Thermal > Defect Pixel Correction. The Defect Pixel Correction page is displayed as the picture below.
  • Page 44 Thermal Imaging Integrated Network Camera User Manual Step 2 Click the white points one by one at image, click Apply to recover the bad point.
  • Page 45 Thermal Imaging Integrated Network Camera User Manual Step 3 Click Reset to return the previous settings. Step 4 Click Apply. The message "Apply success" is displayed, the system saves the settings.

  • Page 46: Image Settings

    Thermal Imaging Integrated Network Camera User Manual 4 Image Settings 4.1 Image Settings Interface Operation Procedure On the web choose “Configuration > Image Settings” interface to set,. Step 1 Thermal Channel Image Settings Step 2 Choose Debug Mode at mode item. There are four schemes can be set.

  • Page 47: Mode

    Thermal Imaging Integrated Network Camera User Manual 4.2 Mode It shows the Mode interface below. Mode Interface Operation Procedure Step 1 Click Mode tag on image settings interface. Step 2 Choose switch mode form drop-down list. Step 3 Set the Start Time. Step 4 Set the End Time.

  • Page 48: Images

    Thermal Imaging Integrated Network Camera User Manual 4.3 Images It shows the Image interface. Image Interface Step 1 Click the Image tag on the image settings interface. Drag the slider to adjust the parameter of image. Brightness: It indicates the total brightness of an image. As the value increases, the image becomes brighter.

  • Page 49: Scene

    Thermal Imaging Integrated Network Camera User Manual 4.4 Scene It shows the Scene interface. Scene Interface Step 1 Click the Scene tag on the image settings interface. Step 2 Choose mirror mode from the drop-list. Step 3 Click Save; the message "Save succeed" is displayed, and the system saves the settings. NOTE Mirror providing the selection of image pixel locations.
  • Page 50 Thermal Imaging Integrated Network Camera User Manual Figure 4-1 Set Pseudocolor Interface Step 1 Click Set pseudocolor tag on the image settings interface. Step 2 Choose Pseudo-colors modes from the drop-down list. Step 3 Enable or disable the Legend of Temperature Value. Step 4 Click Save;...

  • Page 51: Ffc Control

    Thermal Imaging Integrated Network Camera User Manual 4.6 FFC Control FFC Control Interface The following table lists the parameters on the FFC control interface. Parameter Description Setting The internal of the thermal imaging camera may comprise the mechanical action correction mechanism that can periodically improve the image quality.
  • Page 52 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting ranges from 5 to 255 minutes. The temperature change of the camera is based on the temperatures collected by the internal temperature probe. The temperature of the camera sharply changes when the camera is powered on.

  • Page 53: Noise Reduction

    Thermal Imaging Integrated Network Camera User Manual 4.7 Noise Reduction Noise Reduction Interface The following table lists the Noise Reduction parameters. Parameters on the Noise Reduction Interface Parameter Description Setting [How to set] Select from the drop-down list box. Decrease the image 2DNR noise.

  • Page 54: Ai Multiobject

    Thermal Imaging Integrated Network Camera User Manual 5 AI Multiobject To enable full body detection and vehicle detection, when the device detects an object, it will trigger the alarm. Parameters of AI Multiobject Parameter Description How to set Full body The camera will snap the whole body when Enable detection...
  • Page 55 Thermal Imaging Integrated Network Camera User Manual Parameter Description How to set Coefficient type, such as high, mid and low. The higher list. confidence, the better the detecting quality. If the target is static, the device will filter this Static Target target.

  • Page 56: Intelligent Analysis

    Thermal Imaging Integrated Network Camera User Manual 6 Intelligent Analysis 6.1 Intrusion The Intrusion function refers to that an alarm is generated when the targets of specified types (such as person, car, and both person and car) enter the deployment area. Operation Procedure Step 1 Select Intelligent Analysis >...
  • Page 57 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click Enable to enable. [Default value] Sensitivity The sensitivity of detecting the target, when [How to set] the value is high, the target can be detected Choose from the easily, but the accuracy will be lower.
  • Page 58 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting FTP Upload Enable the button to enable File Transfer [How to set] Protocol. Click to enable FTP The parameters of FTP can be set at Upload. Configuration > Network Service > FTP [Default value] interface.

  • Page 59: Single Line Crossing

    Thermal Imaging Integrated Network Camera User Manual Deployment Time Setting Interface Step 5 Click Apply to save the settings. 6.2 Single Line Crossing A Single Line Crossing is a line that is set at a concerned position within the monitored field of view and specifies the forbidden travel direction, an alarm is generated when the targets of specified types (such as person or car) cross this line.
  • Page 60 Thermal Imaging Integrated Network Camera User Manual Step 2 Set all parameters for the Single Line Crossing. Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click Enable to enable. [Default value] Limit Target Effective alarms are set based on target type, [How to set] Type with options of Person or Car, person, car.
  • Page 61 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting indicator, the alarm indicator signals when an alarm is triggered. Audible Enable, when happen the alarm, it will play [How to set] alarm audio to alarm. Click to enable Audio Choose the audible alarm file (set at the Detection Alarm “Configuration >...

  • Page 62: Double Line Crossing

    Thermal Imaging Integrated Network Camera User Manual NOTE Try to draw the Single Line Crossing in the middle, because the recognition of a target takes time after target appearance on the screen and an alarm is generated only when the object is recognized to have crossed the single virtual fence. The Single Line Crossing which detects person foot as the recognition target cannot be too short, because a short Single Line Crossing tends to miss targets.
  • Page 63 Thermal Imaging Integrated Network Camera User Manual Double Line Crossing Interface Set all parameters for the Double Line Crossing. Parameters of Double Line Crossing Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click to enable. [Default value] Limit Target Effective alarms are set based on target type,...
  • Page 64 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Output If you check to set the Output Channel and the [How to set] Channel device is connected to an external alarm Click to select an indicator, the alarm indicator signals when an alarm is triggered.

  • Page 65: Multi-Loitering

    Thermal Imaging Integrated Network Camera User Manual endpoint of a virtual fence and move the mouse to modify the position and length of this virtual fence. You can right-click to delete the double line crossing. NOTE The two virtual fences are in sequential order. An alarm is generated only when a target crosses virtual fence 1 and then virtual fence 2 within the set maximum passing time.
  • Page 66 Thermal Imaging Integrated Network Camera User Manual Multi-Loitering Setting Interface Step 2 Set all parameters for Multiple-Loitering. Parameters of Multiple Loitering Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click Enable to enable. [Default value] Limit Target The target size for triggering an effective [How to set]...
  • Page 67 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Limit Numbers When Limit Numbers is set to OFF, an alarm [How to set] is generated no matter how many people Click to enable loiter. When Limit Numbers is set to ON, if Limit Numbers.

  • Page 68: Retrograde

    Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Video Stream Enable, the deployment frame will show on [How to set] Draw Line the live video. Click to enable Video Stream Draw Line. [Default value] Step 3 Set a deployment area. Move the cursor to the drawing interface and click to generate a point, move the cursor to draw a line, and then click to generate another point.

  • Page 69: Parameter Description

    Thermal Imaging Integrated Network Camera User Manual Retrograde Setting Interface Step 2 Set all parameters for Retrograde. Parameter of Retrograde Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click Enable to enable. [Default value] Limit Target Effective alarms are set based on target type, [How to set]...
  • Page 70 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Output If you check to set the Output Channel and the [How to set] Channel device is connected to an external alarm Click to select an indicator, the alarm indicator signals when an alarm is triggered.

  • Page 71: Enter Area

    Thermal Imaging Integrated Network Camera User Manual NOTE A drawn line cannot cross another one, or the line drawing fails. Any shape with 8 sides at most can be drawn. The quantity of deployment areas is up to 8. Step 4 Set deployment time Click “Apply”...
  • Page 72 Thermal Imaging Integrated Network Camera User Manual Enter area Step 2 Set all parameters for Enter Area. Parameter Description Setting Enable Enable the button to enable the enter area alarm. [How to set] Click Enable to enable. [Default value] Sensitivity The sensitivity of detecting the target, when the [How to set] value is high, the target can be detected easily,...
  • Page 73 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Limit Target Effective alarms are set based on target type, [How to set] Type with options of Person or Car, person, car. When Click to enable the device is used indoors, because of small Limit Target Type.

  • Page 74: Leave Area

    Thermal Imaging Integrated Network Camera User Manual Move the cursor to the drawing interface and click to generate a point, move the cursor to draw a line, and then click to generate another point. This is how a line is generated. In this way, continue to draw lines to form any shape, and right-click to finish line drawing.
  • Page 75 Thermal Imaging Integrated Network Camera User Manual Parameters of Leave Area Parameter Description Setting Enable Enable the button to enable the leave area alarm. [How to set] Click Enable to enable. [Default value] Sensitivity The sensitivity of detecting the target, when the [How to set] value is high, the target can be detected easily, Choose from the...
  • Page 76 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting FTP Upload Enable the button to enable File Transfer [How to set] Protocol. Click to enable FTP The parameters of FTP can be set at Upload. Configuration > Network Service > FTP [Default value] interface.

  • Page 77: Advanced Intelligent Analysis

    Thermal Imaging Integrated Network Camera User Manual 7 Advanced Intelligent Analysis At the advanced intelligent analysis interface, users can set the parameters of smoker detection, fire spot detection. Enable the linkage actions, the alarm information can be sent to users by the linkage. The advanced intelligent analysis can be used for detecting the smoking, if someone smoke in the indoor where smoking is forbidden.
  • Page 78 Thermal Imaging Integrated Network Camera User Manual Smoker Detection Interface Step 2 Set all parameters for Smoker Detection. Parameters of Smoker Detection Parameter Description Setting Enable Enable the button to enable the alarm. [How to set] Click Enable to enable. [Default value] Output Channel If you check to set the Output Channel...
  • Page 79 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Audible alarm Enable, when happen the alarm, it will [How to set] play audio to alarm. Click to enable Audio Choose the audible alarm file (set at the Detection Alarm “Configuration >...

  • Page 80: Fire Spot Detection

    Thermal Imaging Integrated Network Camera User Manual A drawn line cannot cross another one, or the line drawing fails. Any shape with 8 sides at most can be drawn. The quantity of deployment areas is up to 8. Step 4 Set deployment time.
  • Page 81 Thermal Imaging Integrated Network Camera User Manual Step 2 Set all parameters for Fire Spot Detection. Fire Spot Detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm. Click Enable to enable. [Default value] Output Channel If you check to set the Output Channel...
  • Page 82 Thermal Imaging Integrated Network Camera User Manual Parameter Description Setting Audible alarm Enable, when happen the alarm, it will [How to set] play audio to alarm. Click to enable Audio Choose the audible alarm file (set at the Detection Alarm “Configuration >...
  • Page 83 Thermal Imaging Integrated Network Camera User Manual A drawn line cannot cross another one, or the line drawing fails. Any shape with 8 sides at most can be drawn. The quantity of deployment areas is up to 8. Step 4 Set deployment time.

  • Page 84: A Troubleshooting

    Thermal Imaging Integrated Network Camera User Manual A Troubleshooting Common Possible Cause Solution Issues Unable to Network is not Connect the network cable of the camera to access the connected. the PC to check whether the network cable is in good contact. Run the ping command to check the network connection and whether the device works normally.
  • Page 85 Thermal Imaging Integrated Network Camera User Manual Common Possible Cause Solution Issues Intelligent "Limit Type" isn't Go to Intelligent Analysis, Event type, enable Analysis - enabled and "Event Type" and then choose "Person, Car or event cannot configured. Both". be triggered by human or vehicle An error...

  • Page 86: B Common Emission Rate

    Thermal Imaging Integrated Network Camera User Manual B Common Emission Rate Emission Rate The emission rate is the capability of an object to emit or absorb energy. An ideal transmitter provides an emission rate of emitting 100% of intake energy. An object with an emission rate of 0.8 can absorb 80% of intake energy, and reflect the remaining 20%.
  • Page 87 Thermal Imaging Integrated Network Camera User Manual Cobalt 599/1110 0.19 199/390 0.52 Steel 599/1110 0.57 Tinned iron sheet (Light) 28/82 0.23 Brass(High-polish) 247/476 0.03 Brass (Tough rolled, polished 21/70 0.04 metal wire) Tinned Iron (Light) 0.13 Iron plate (Rust eaten) 20/68 0.69 Rolled steel sheet...
  • Page 88 Thermal Imaging Integrated Network Camera User Manual Glass (Glossy) 22/72 0.94 Granite (Surfaced) 21/70 0.85 0/32 0.97 Marble (I Polished, grey) 22/72 0.93 Asbestos board 23/74 0.96 38/100 0.93 Asbestos paper 371/700 0.95 Asphalt (Paving the road) 4/39 0.97 Paper (Black tar) 0.93 Paper (White) 0.95...
