INSTALLATION MANUAL

ONE-WAY CASSETTE INDOOR UNIT

DRAL0612F2A, DRAL18F2A

R-454B, 208/230V, 1ph 60HZ

Model Number:

Serial Number:

Purchase Date:

Installing Contractor Company Name:

TIP

Capture relevant information about your Durastar mini-split equipment before it is

installed and write it above for future reference.

DURASTAR.COM

Table of Contents

Need help?

Do you have a question about the DRAL18F2A and is the answer not in the manual?

Questions and answers

Summary of Contents for DURASTAR DRAL18F2A

Page 1 ONE-WAY CASSETTE INDOOR UNIT DRAL0612F2A, DRAL18F2A R-454B, 208/230V, 1ph 60HZ Model Number: Serial Number: Purchase Date: Installing Contractor Company Name: Capture relevant information about your Durastar mini-split equipment before it is installed and write it above for future reference. DURASTAR.COM...
Page 2: Table Of Contents
STEP 5: DRILL WALL HOLE FOR CONNECTIVE PIPING ......31 STEP 6: PREPARE REFRIGERANT PIPING ............31 STEP 7: WRAP PIPES AND CABLE ................32 STEP 8: ATTACH WATER RECEIVER ..............32 STEP 9: INSTALL PANEL ....................33 STEP 10: COMPLETE A WATER DISCHARGE TEST ........37 TROUBLESHOOTING .....................38 WIRING DIAGRAM ......................42 DURASTAR.COM...
Page 3: Introduction
• Read the troubleshooting section of this manual as it will help you diagnose and solve common issues. • Visit us on the web at www.durastar.com to download product guides and up-to-date information. • If you need warranty service, our friendly customer service representatives are available via email at questions@durastar.com or by telephone at 1-888-320-0706.
Page 4: Important Safety Precautions
Do not operate your air conditioner in a wet room such as a bathroom or laundry room. Too much exposure to water can cause electrical components to short circuit. • If the air conditioner is used together with burners or other heating devices, thoroughly ventilate the room to avoid oxygen deficiency. DURASTAR.COM...
Page 5: Electrical Safety
For units that have an auxiliary electric heater, do not install the unit within 3 feet (1 meter) of any combustible materials. • Do not install the unit in a location that may be exposed to combustible gas leaks. If combustible gas accumulates around the unit, it may cause a fire. DURASTAR.COM...
Page 6 When the refrigerant sensor malfunctions, the indoor unit will display the error code “FHCC”. The refrigerant sensor can not be repaired and can only be replaced by the manufacturer. It shall only be replaced with the sensor specified by the manufacturer. DURASTAR.COM...
Page 7 All training shall follow the ANNEX HH requirements of UL 60335-2-40 4th Edition. Examples for such working procedures are: • breaking into the refrigerating circuit; • opening of sealed components; • opening of ventilated enclosures. DURASTAR.COM...
Page 8: Work Procedure
Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s technical department for assistance. The following checks shall be applied to installations using FLAMMABLE REFRIGERANTS: DURASTAR.COM...
Page 9: Detection Of Flammable Refrigerants
(25 % maximum) is confirmed. • Leak detection fluids are also suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. DURASTAR.COM...
Page 10: Charging Procedures
Prior to recharging the system it shall be pressure tested with OXYGEN FREE NITROGEN • (OFN). The system shall be leak tested on completion of charging but prior to commissioning. • A follow up leak test shall be carried out prior to leaving the site. DURASTAR.COM...
Page 11 If in doubt, the manufacturer should be consulted. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition. DURASTAR.COM...
Page 12 The effectiveness of signs should not be diminished by too many signs being placed together. Any pictograms used should be as simple as possible and contain only essential details. Disposal of equipment using flammable refrigerants: See national regulations. Storage of equipment/appliances: The storage of the appliance should be in accordance with DURASTAR.COM...
Page 13: Additional Precautions
The air conditioner’s circuit board (PCB) is designed with a fuse to provide over-current protection. The specifications of the fuse are printed on the circuit board , for example : T3.15AL/250VAC, T5AL/250VAC, T3.15A/250VAC, T5A/250VAC, T20A/250VAC, T30A/250VAC, etc. Note Only a blast-proof ceramic fuse can be used. DURASTAR.COM...
Page 14 When the unit detects a refrigerant leak, the minimum airflow of the indoor unit is as follows : Model DRAL0612F2A DRAL18F2A 6K/9K Nominal Air Volume 342 CFM (580 m³/h) 353 CFM (600 m³/h)
Page 15: Operating Temperatures
Regularly inspect and clean air filters. NOTE Your Durastar air conditioner's outdoor unit is equipped with a base pan heater, allowing it to continue to operate at freezing temperatures as low as -22°F (-30°C). When outdoor air temperatures are at or below 32°F (0°C), we strongly recommend keeping the unit plugged in at all times to ensure smooth ongoing performance.
Page 16: Accessories
Image Manual Remote Control Installation Cardboard AAA Battery Template Remote Control Water Receiver Holder Remote Control Screw ST8*50 Holder Mounting Screw Drain Pipe Screw M4*22 Adaptor Screw ST4.8*12 Copper Nut Screw ST3.9*10 Rubber ring Screw ST3.9*16 Panel Cable Tie DURASTAR.COM...
Page 17: Tools Needed
Indoor and outdoor connection wire • Outdoor power supply cord • Drain pipe • Pipe and cable wrapping tape • Wall hole sleeve and cover • Putty • Suspension bolts and necessary hardware to hang indoor unit • Wiring u-lugs DURASTAR.COM...
Page 18: Parts Identification
Display Panel Display Panel Signal Cable Wiring Air Inlets Terminal Refrigerant Pipes Outdoor Unit Power Cable Valve Cover Air Outlet NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your mini-split equipment may vary slightly. DURASTAR.COM...
Page 19: Unit Dimensions
UNIT DIMENSIONS 16-5/8" (423mm) 13-3/16" (335mm) 43-1/2" (1105mm) 53-1/2" (1360mm) DURASTAR.COM...
Page 20: Installation Overview - Indoor Unit
INSTALLATION OVERVIEW - INDOOR UNIT Select Installation Location Install Ceiling Cassette Connect Wiring Prepare Drain Pipe Drill Wall Hole Connect Piping Wrap Piping and Cable Attach Water Receiver Install Panel Perform Water Discharge Test DURASTAR.COM...
Page 21: Indoor Unit Installation
If there is no pre-existing piping, when choosing a location, leave ample room for a wall hole (See Step 5: Drill Wall Hole for Connective Piping). Think about the path the signal cable and refrigerant piping may take and if drilling joists may be necessary. DURASTAR.COM...
Page 22 CLEARANCES ROOF ＞20” ＞20” (500mm) (500mm) Wall Ceiling hole Ceiling GROUND Wall Ceiling ＞7-7/8” (200mm) Air inlet Air outlet Ceiling hole GROUND DURASTAR.COM...
Page 23: Step 2: Install The One-Way Ceiling Cassette
2. With two (2) people, use the provided holes running along to the long sides of the cassette to screw the cassette to the ceiling joists. Use six (6) ST8.0*50 screws. Secure with screws Joist NOTE The cassette fits between beams spaced 16" apart, with 1/2" allowance on both sides. DURASTAR.COM...
Page 24 Ceiling Bottom of unit ≤ 5/8 ” (16 mm) Ceiling board WARNING Ensure that the indoor unit is completely level. Improper installation can cause the drain pipe to back up into the unit and water leaks. DURASTAR.COM...
Page 25: Step 3: Connect Signal Wires To Indoor Unit
• Outdoor Power Cable: Determined by the amperage of system and the local codes in your area. CABLE SIZING Use a minimum of 14 AWG for power and signal cables connected to and between the indoor and outdoor units. DURASTAR.COM...
Page 26 To connect the signal wires to the indoor unit circuit breaker, do the following: 1. Remove the four (4) screws to open the indoor control box and the circuit breaker box. Four Screws Indoor Control Box Circuit Breaker Box DURASTAR.COM...
Page 27 Three Knock-Out Holes (one hidden underneath) 3. Install the provided rubber ring in the hole to cover the sharp sides. 4. Connect the wires to the breaker according to the wiring diagram. Ensure the ground wire is screwed in tightly. DURASTAR.COM...
Page 28 If installing a wired thermostat, it is recommended to do that now before closing the breaker cover. Please see the wired thermostat instructions provided with the thermostat at www.durastar.com. 6. Install the breaker cover by replacing the two screws. Two screws...
Page 29: Indoor Unit Btu Setting (For Multi-Zone)
1. Connect a 1" OD drain pipe (field supplied) to the unit's connecting port using the drain adaptor and metal worm clamps provided.. Make sure it secured tightly and can not be easily pulled loose. Insulated drain connector Drain Metal Drain port clamps pipe DURASTAR.COM...
Page 30 6. Pass the drain pipe through the wall hole to the outside. The end of the pipe should be at least 2" (50mm) above the ground. If it touches the ground, the pipe may become blocked. Make sure the water drains to a safe location where it will not cause water damage or a slipping hazard. DURASTAR.COM...
Page 31: Step 5: Drill Wall Hole For Connective Piping
Be extremely careful not to dent or damage the piping while bending them away from the unit. Any dents in the piping will affect the unit’s performance. IMPORTANT NOTE: The TOTAL SYSTEM CHARGE WEIGHT should be noted on the label adjacent to the unit rating label on the outdoor unit. DURASTAR.COM...
Page 32: Step 7: Wrap Pipes And Cable
Gas Leak Checks section of the outdoor unit's installation manual). STEP 8: ATTACH WATER RECEIVER Attach the water receiver, supplied with the accessories, to the indoor unit using the ST4.8*12 screw. An extra ST4.8*12 screw is provided. Water Receiver ST4.8*12 Screw DURASTAR.COM...
Page 33: Step 9: Install Panel
Screw Covers 3. Hold open the grille and push both latches toward the middle to unlock the grille. 4. Remove the grille panel. Latches 5. Fix the panel to the one-way cassette by two (2) plastic buckles. Plastic buckle DURASTAR.COM...
Page 34 ST3.9*16 screw. NOTE: The ST3.9*16 screw is behind a cover. ST3.9*16 Screw M4*22 Screw 7. Open the two covers on both sides of the panel , fix the panel to the cassette by using 3× M4*22 screws. M4*22 Screw DURASTAR.COM...
Page 35 Display panel CN10 Wiﬁ CN38 (4 core) (white 10-core) (if available) When the connection is completed, please clip the wires to the buckle. 9. Install the control box cover. Two screws for Circuit Breaker Two screws for control box DURASTAR.COM...
Page 36 10. Turn the breaker on and close the two (2) plastic covers, located on both sides of the panel. 11. Reinstall the grille by pushing it into the latch to lock it. 12. Reinstall the two screws under the screw covers. Control box cover DURASTAR.COM...
Page 37: Step 10: Complete A Water Discharge Test
The drainage plug at the bottom of the unit body is used to discharge accumulated water from the drain pan when the air conditioner malfunctions. When the air conditioner is operating normally, make sure the drainage plug is properly plugged to prevent water from leaking. DURASTAR.COM...
Page 38: Troubleshooting
The indoor unit makes A rushing air sound may occur when the louver resets its position. noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts. DURASTAR.COM...
Page 39 • Press ON/OFF button on remote control to restart operation. NOTE If problem persists, contact a local dealer or your nearest customer service center. Provide them with a detailed description of the unit malfunction as well as your model number. DURASTAR.COM...
Page 40 Incompressible gas or moisture has Evacuate and recharge the system with frequently entered the system. refrigerant. The compressor is broken. Replace the compressor. The voltage is too high or too low. Install a manostat to regulate the voltage. DURASTAR.COM...
Page 41 5 to 6 minutes before stopping. You can also press any button on the remote controller to stop the buzzer. The unit will go into Turbo to mitigate the leak. Check connections and perform a leak test as described in the outdoor unit installation manual. DURASTAR.COM...
Page 42: Wiring Diagram
WIRING DIAGRAM DURASTAR.COM...
Page 43 Refrigerant sensor error PC00 ODU IPM module protection PC01 ODU voltage protection PC02 Compressor top (or IPM) temp. protection PC03 Pressure protection (low or high pressure) PC04 Inverter compressor drive error PC0L Low ambient temperature protection ---- IDUs mode conflict (Multi-zone) DURASTAR.COM...
