- Page 1 Installation Instructions Bronco HD Pivot Part #S/B6143 For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
-
Page 2: Tools Required
Introduction Thank you for choosing Smittybilt accessories for your Ford Bronco. If you would like to view our full range of available accessories, please visit us at www.smittybilt.com Ford® and Bronco® are registered trademarks of Ford Motor Company. Important Notes Before Starting Carefully read through this entire instruction manual thoroughly before attempting to install this part. - Page 3 SHEET METAL SPACER TIRE BUMP STOP SPACER M8X1.25X50 M8X1.25X40 M8X1.25X35 M10X1.25X16 M8 WASHERS PUSH PIN For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
-
Page 4: Important Note
Open the box containing your Ford Bronco HD Pivot, check all parts against the Bill of Materials outlined in the first pages of these instructions. If anything is missing, contact Smittybilt Technical Support immediately. Step 2: License Plate Removal. First remove the 2X 19mm bolts (a) holding... - Page 5 For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
- Page 6 For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
- Page 7 4X screws (q), with a 13mm socket and wrench remove the 6X bolts (r) that hold the hinges. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
- Page 8 IMPORTANT NOTE Be sure to not pinch license plate light wire when installing tire carrier. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
- Page 9 OE Phillips push pin. NOTE: This step is optional. wire when installing tire carrier. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
- Page 10 Your installation is now complete. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023 Part # S/B6143...
-
Page 11: Bolt Torque Specifications
Use this only as a guide for hardware without a called out torque specification in the instruction manual. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Bronco HD Pivot Rev 1/10/2023... - Page 12 Rollover and other types of vehicle accidents may result in serious injury or death to you, your passengers and others sharing the road. Smittybilt accessories are decorative and are not intended to reduce or avoid injury or damage in the event of an accident.
