Summary of Contents for WAGNER 2341501
- Page 1 WOOD & METAL SPRAYER W 250 18V ORIGINAL INSTRUCTIONS wagner-group.com...
- Page 2 W 250 18V...
- Page 3 W 250 18V click ...
- Page 4 W 250 18V 5-15 cm ...
- Page 5 W 250 18V 5 4 3...
-
Page 6: Table Of Contents
W 250 18V MANY THANKS FOR PLACING YOUR TRUST IN US We would like to congratulate you on purchasing this brand product from Wagner; we are sure that you will enjoy working with it greatly. Please read the Operating Manual carefully and observe the safety information before starting the device. -
Page 7: Explanation Of Symbols Used
W 250 18V 1. Explanation of symbols used This symbol indicates a potential danger for you or for the device. Under this symbol you can find important information on how to avoid injuries and damage to the device. Danger of electrical shock Indicates tips for use and other particularly useful information. - Page 8 W 250 18V the lead or by pulling on the lead to remove the plug. Keep the lead away from heat, oil, sharp edges or moving tool parts. Damaged or twisted leads increase the risk of an electric shock. e) If you work outdoors with a power tool, only use extension cables suitable for outdoor use.
- Page 9 W 250 18V 4. Usage and treatment of the electric tool a) Do not overload the tool. Use the power tool designed for the work that you are doing. You work better and safer in the specified performance range if you use the suitable power tool.
-
Page 10: Safety Instructions For Spray Guns
W 250 18V d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. e) Do not use a battery pack or tool that is damaged or modified. -
Page 11: Safety Instructions For The Charger And Battery
• Do not lay the spray gun. With original WAGNER accessories and spare parts, you have the guarantee that all safety regulations are fulfilled. 4. Safety instructions for the charger and battery Only use the tool with BOSCH PROFESSIONAL compatible GBA 18V batteries with at least 2.0 Ah and suitable chargers. -
Page 12: Description/ Scope Of Delivery
W 250 18V • Vapours may also escape if the battery is damaged or used improperly. Take in fresh air and consult a doctor if you have any symptoms. The vapours may irritate the respiratory tract. • If the battery is defective, liquid may leak out and wet adjacent objects. Check affected parts. -
Page 13: Coating Materials
W 250 18V 6. Coating Materials Coating Materials Suitable for Use Glazes, wood preservatives, staining sealers, oils, stains undiluted Paints containing solvents and water-soluble paints, primers dilute by 5 - 10% Wall paints dilute by 10% Coating Materials Not Suitable for Use Materials that contain highly abrasive components, facade paint, caustic solutions and acidic coating substances. -
Page 14: Start-Up
W 250 18V Once the battery is fully charged, remove the battery from the charger. Unplug the mains plug of the charger from the socket. The W250 vibrates when the battery needs to be recharged. 8. Start-up • Unscrew the container from the spray gun. •... -
Page 15: Adjusting The Material Volume (Fig. 6)
W 250 18V 10. Adjusting the Material Volume (Fig. 6) Set the material volume by turning the regulator on the trigger guard of the spray gun. - turn to the left lower material volume + turn to the right higher material volume 11. -
Page 16: Maintenance
W 250 18V back into the material tin. 5) Pull out the suction tube with container seal. 6) Preclean the container and suction tube with a brush. Clean the ventilating bore (Fig. 9, C). CAUTION! Never clean seals, diaphragm and nozzle or air holes of the spray gun with metal objects. -
Page 17: Spare Parts List
The CLICK&PAINT SYSTEM with additional spray attachments and accessories offers the right tool for each work. We recommend against using the W 250 with the Wall Extra I-Spray spray attachment. Further information about the WAGNER range of products for renovating is available under wagneraustralia.com.au... -
Page 18: Correction Of Malfunctions
W 250 18V 17. Correction of Malfunctions Problem Problem Cause Cause Remedy Remedy • • No coating Device not switched on Press the ON/OFF switch on material (trigger cannot be pulled) the side of the device • • emerges from Battery flat, faulty or incompatible Charge or replace •... -
Page 19: Technical Data
W 250 18V 18. Technical Data Technical Data* Max. viscosity 60 DIN-s Power source 230 V , 50 Hz Rechargeable battery (GBA 18 V, 2.0 Ah): Li-Ion, 18 V , 2.0 Ah Max. flow rate: 250 ml/min Charger (GAL 18V-40): Input voltage 220-240 V , 50-60 Hz;... -
Page 20: Environmental Protection
F +61 3 9580 9120 L� +34 91 879 72 00 100% F +34 91 883 19 59 www.fsc.org Part. No. 2459241 D RECYCLED 12/2024_RS Paper made from recycled material © Copyright by J.Wagner GmbH Not responsible for errors and changes. ® C 143544...
