OPERATION AND PARTS MANUAL
SERIES
MODEL MTR40HF
TAMPING RAMMER
(HONDA GX100RTKRB6 GASOLINE ENGINE)
Revision #0 (09/14/17)
www.discount-equipment.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mikasa Series and is the answer not in the manual?

Questions and answers

Related Manuals for MULTIQUIP Mikasa Series

Summary of Contents for MULTIQUIP Mikasa Series

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODEL MTR40HF TAMPING RAMMER (HONDA GX100RTKRB6 GASOLINE ENGINE) Revision #0 (09/14/17) www.discount-equipment.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 One of our experienced staff members will get back to you with a quote for the right part that your machine needs. We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone, Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,...

  • Page 3: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)

  • Page 4: Table Of Contents

    TABLE OF CONTENTS MTR40HF Rammer Honda GX100RTKRB6 Gasoline Engine Proposition 65 Warning ........... 2 Cylinder Barrel Assembly ......... 42-43 Table Of Contents ............ 4 Crankcase Cover Assembly ......44-45 Parts Ordering Procedures ........5 Crankshaft Assembly ........46-47 Safety Information ..........6-9 Piston/Connecting Rod Assembly ....

  • Page 5: Safety Information

    SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 6 „ NEVER lubricate components or attempt service on a „ NEVER use accessories or attachments that are not running machine. recommended by Multiquip for this equipment. Damage NOTICE to the equipment and/or injury to user may result. „ ALWAYS keep the machine in proper running condition.
  • Page 7 SAFETY INFORMATION ENGINE SAFETY FUEL SAFETY DANGER DANGER „ The engine fuel exhaust gases contain poisonous carbon „ DO NOT add fuel to equipment if it is placed inside truck monoxide. This gas is colorless and odorless, and can bed with plastic liner. Possibility exists of explosion or cause death if inhaled.
  • Page 8 SAFETY INFORMATION TRANSPORTING SAFETY CAUTION „ NEVER allow any person or animal to stand underneath the equipment while lifting. NOTICE „ Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are not loose or missing. „...

  • Page 9: Dimensions

    DIMENSIONS MTR-40 Table 1. Rammer Dimensions Reference Dimension in. (mm) Letter 14.57 (370) 24.41 (620) 43.70 (1,110) 10.63 (270) 5.90 (150) PAGE 10 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)

  • Page 10: Specifications

    SPECIFICATIONS Table 2. Rammer Specifications Overall Height 43.70 in. (1,110 mm)) Overall Width 14.57 in. (370 mm) Over Length 24.41 in. (620 mm) Shoe Size (W x L) 5.9 x 10.6 in. (150 x 270 mm) No. of Impacts 10.7 ~ 11.6 Hz (644 ~ 695 vpm) Tamping Area 1,453 sq.

  • Page 11: General Information

    GENERAL INFORMATION The Multiquip MTR40HF tamping rammer is a powerful This rammer is equipped with a lifting grip handle. Check compacting tool capable of applying a tremendous force the following before placing rammer into operation: in consecutive impacts to a soil surface. Its applications „...

  • Page 12: Components

    COMPONENTS SIDE B SIDE A Figure 2. MTR40HF Rammer Figure 2 shows the location of the controls and components 9. Fuel Tank/Cap — Remove this cap to add unleaded for the MTR40HF Tamping Rammer. The functions of each gasoline to the fuel tank. Make sure cap is tightened control is described below: securely.

  • Page 13: Basic Engine

    BASIC ENGINE Figure 3. Honda GX100RTKRB6 Engine The engine (Figure 3) must be checked for proper 5. Muffler — Used to reduce noise and emissions. lubrication and filled with fuel prior to operation. Refer 6. Dipstick/Oil Filler Cap — Remove this cap to to the manufacturer's engine manual for instructions and determine if the engine oil is low.

  • Page 14: Inspection

    INSPECTION FUEL CHECK This section is intended to assist the operator with the inspection of the rammer. It is extremely important that WARNING this section be read carefully before attempting to operate the rammer. Adding fuel to the tank should be accomplished only when the engine is CAUTION stopped and has had an opportunity to...
  • Page 15 INSPECTION ENGINE OIL CHECK Table 4. Motor Oil Grade 1. To check the engine oil level, place the rammer on Grade of motor oil Season or Temperature secure level ground with the engine stopped. (higher than MS class) 2. Remove the filler cap/dipstick from the engine oil filler Spring, Summer or Autumn SAE 30 hole (Figure 6) and wipe it clean.

  • Page 16: Operation

    OPERATION OPERATION 4. In cold weather, start the unit with choke lever "Fully Closed" OPERATION Operation 4. In cold weather, start the unit with choke lever "Fully (Figure 10). In warm weather or when the engine is warm, The following steps outline the procedure for starting the engine: Closed"...
  • Page 17 OPERATION NOTICE While the spark plug is removed, pull the starter handle/ rope 2 to 3 times to discharge any fuel from the cylinder. IDLE POSITION 10. To start the rammer tamping action, move the throttle lever (Figure 15) quickly from IDLE (close) to the FULL THROTTLE OPEN position.

  • Page 18: Lifting/Storage

    LIFTING/STORAGE LIFTING „ Before lifting the machine, make sure that there is no damage to any of the components on the machine. „ Inspect the machine for damage to the rubber mounts and the hook. „ Only use the single hook (Figure 19) to lift the machine. DO NOT support it from any other points (such as the handle).

  • Page 19: Maintenance

    MAINTENANCE DAILY PAPER „ Thoroughly remove dirt and oil from the engine FILTER compartment and rammer. Clean or replace the air ELEMENT cleaner elements as necessary. Check and retighten all fasteners as necessary. Check the bellows for oil leaks. Repair or replace as needed. PRE-CLEANER (150 HOURS) COVER COMPRESSED AIR...
  • Page 20 MAINTENANCE CRANKCASE LUBRICATION (8 HOURS) FUEL LINES (2 YEARS) „ The rammer crankcase bearings (Figure 24) should be „ Check the fuel and oil lines regularly for damage and lubricated with five shots of grease with a hand grease ensure that there are no leaks. gun after each eight (8) hours of use.
  • Page 21 MAINTENANCE Table 5. Engine Maintenance Schedule FIRST EVERY EVERY EVERY EVERY MONTH 3 MONTHS 6 MONTHS YEAR 2 YEARS DESCRIPTION (3) OPERATION BEFORE 10 HRS. 25 HRS. 50 HRS. 100 HRS. 200 HRS.. CHECK Engine Oil CHANGE CHECK Air Cleaner CHANGE X (1) Re-tighten If...

  • Page 22: Troubleshooting

    TROUBLESHOOTING Troubleshooting (Engine) Symptom Possible Problem Solution Combo lever in incorrect position? Make sure combo lever is in start position. Spark plug bridging? Check gap, insulation or replace spark plug. Carbon deposit on spark plug? Clean or replace spark plug. Short circuit due to defi cient spark plug Check spark plug insulation, replace if worn.
  • Page 23 TROUBLESHOOTING Troubleshooting (Engine) - continued Symptom Possible Problem Solution Air cleaner dirty? Clean or replace air cleaner. Improper level in carburetor? Check fl oat adjustment, rebuild carburetor. Weak in power, compression is proper and does not misfi re. Defective spark plug? Clean or replace spark plug.
  • Page 24 TROUBLESHOOTING Troubleshooting (Rammer) Symptom Possible Problem Solution Operating speed of throttle lever is Set throttle lever to correct position. incorrectly set? Oil in excess? Drain excess oil. Bring to correct level. Clutch slips? Replace or adjust clutch. Engine runs but rammer jumps erratically or not at all.

  • Page 25: Explanation Of Code In Remarks Column

    A blank entry generally indicates that the item is not sold “Not Sold Separately” — Indicates that an item cannot separately or is not sold by Multiquip. Other entries will be purchased as a separate item and is either part of an be clarifi ed in the “Remarks”...

  • Page 26: Suggested Spare Parts

    SUGGESTED SPARE PARTS MTR40HF TAMPING RAMMER WITH HONDA GX100RTKRB6 GASOLINE ENGINE 1 to 3 units Qty. Description 1....956100077 ....THROTTLE WIRE 3....362030030 ....ELEMENT, AIR CLEANER 1....361910070 ....CAP, FUEL TANK COMP. 3....16910GB2005 ..FILTER, IN-LINE FUEL 3....9805655777 ..SPARK PLUG 1....28462Z0DV03 ..ROPE, RECOIL STARTER 3....17211ZL8023 ..CLEANER, ELEMENT (ENGINE) NOTICE Part numbers on this Suggested Spare Parts list may...

  • Page 27: Nameplates And Decals Assembly

    NAMEPLATES AND DECALS ASSY. CAUTION OPERATION Before Operation To START engine: Open fuel filter valve and close choke lever on carburetor. Check all nuts and bolts for tightness Place starter switch to “ON” and pull start rope. Keep machine at the upright operating position to check When engine starts, open the choke lever and warm up the engine for 4-5 minutes before operation.
  • Page 28 NAMEPLATES AND DECALS ASSY. PART NO. PART NAME QTY. REMARKS 920211000 DECAL, CAUTION 4 CYCLE AND GREASE 920900100 DECAL, SET, (NPA-1472) ........1....INCLUDES ITEMS W/# DECAL, .............1....NOT SOLD SEPARATELY DECAL, CAUTION ..........1....NOT SOLD SEPARATELY DECAL, OPERATION ........1....NOT SOLD SEPARATELY DECAL, LIFTING POSITION ......1....NOT SOLD SEPARATELY DECAL, DO NOT LIFT ........1....NOT SOLD SEPARATELY DECAL, DANGER HEARING PROTECTION ...1....NOT USED DECAL, DANGER EYE PROTECTION ....1....NOT USED...

  • Page 29: Crankcase And Engine Assembly

    MTR-40HF CRANKCASE AND ENGINE ASSY. CRANK CASE & ENGINE 66-2 66-1 66-3 11-1 66-4 11-2 63-2 63-3 63-1 64-3 64-2 64-1 21-1 21-2 64-3 64-2 64-1 63-1 63-3 63-2 PAGE 30 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 30 CRANKCASE AND ENGINE ASSY. PART NO. PART NAME QTY. REMARKS 305117260 CRANKCASE 959409790 SOCKET HEAD SCREW 8X50 022910300 FLANGE NUT M8 351010050 GREASE FITTING 959010320 GREASE FITTING 305343780 CRANK GEAR 041006305 BEARING, 6305Z 041006203 BEARING, 6203Z 952401450 WASHER, 8.5X22X3 11-1 011208025 BOLT 8X25............1....REPLACES P/N 001220825 11-2...
  • Page 31 MTR-40HF CRANKCASE AND ENGINE ASSY. CONT'D. CRANK CASE & ENGINE 66-2 66-1 66-3 11-1 66-4 11-2 63-2 63-3 63-1 64-3 64-2 64-1 21-1 21-2 64-3 64-2 64-1 63-1 63-3 63-2 PAGE 32 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 32 CRANKCASE AND ENGINE ASSY. CONT'D. PART NO. PART NAME QTY. REMARKS 096208020 SOCKET HEAD SCREW 8X20 020408050 NUT, SPECIAL 8 MM 956100077 THROTTLE WIRE 020406040 NUT M6 011206020 BOLT 6X20............2....REPLACES P/N 001220620 952404470 WASHER, FLAT M6 ...........2....REPLACES P/N 031106100 030206150 WASHER, LOCK M6 022130605 NUT, CAP M6...

  • Page 33: Fuel Tank And Handle Assembly

    MTR-40HF FUEL TANK AND HANDLE ASSY. TANK & HANDLE 36-2 36-1 PAGE 34 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 34 FUEL TANK AND HANDLE ASSY. PART NO. PART NAME QTY. REMARKS 351319900 SHOCK ABSORBER 014210020 SOCKET HEAD BOLT 10X20 ......4....REPLACES P/N 001521020 033121009 TOOTHED LOCK WASHER B M10 012210020 BOLT 10X20 H, SW ..........4....REPLACES P/N 002211020 939010210 STOPPER RUBBER 030208200 WASHER, LOCK M8 020108060 NUT M8 .............1....REPLACES P/N 020308060...

  • Page 35: Spring And Guide Cylinder Assembly

    MTR-40HF SPRING AND GUIDE CYLINDER ASSY. SPRING & GUIDE CYLINDER 27-1 27-2 16-1 16-2 PAGE 36 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 36 SPRING AND GUIDE CYLINDER ASSY. PART NO. PART NAME QTY. REMARKS 305464130 PISTON PIN 368459920 PISTON PIN PLUG 305337982 PISTON ROD, M14 305451550 PISTON END, M14 305446400 STOPPER, UPPER 305446410 CYLINDER CAP 305446420 MAIN SPRING 307219790 SPRING CYLINDER 305112730 GUIDE CYLINDER 065105010 DUST SEAL 080510680...

  • Page 37: Foot Assembly

    MTR-40HF FOOT FOOT ASSY. PAGE 38 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 38 FOOT ASSY. PART NO. PART NAME QTY. REMARKS 305910050 FOOT ASSY., 150B ..........1....INCLUDES ITEMS W/$ 009110033 BOLT, SQUARE NECK 10X50 021110120 NYLON NUT M10 ..........2....REPLACES P/N 022711012 030210250 WASHER, LOCK M10 009110034 BOLT, SQUARE NECK 12X65 021112140 NYLON NUT M12 ..........4....REPLACES P/N 022711214 030212300 WASHER, LOCK M12 306461630...

  • Page 39: Foot (Option) Assembly

    MTR-40HF FOOT (OPTION) FOOT (OPTION) ASSY. 100 mm WIDTH 200 mm WIDTH PAGE 40 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 40 FOOT (OPTION) ASSY. PART NO. PART NAME QTY. REMARKS 305910070 FOOT ASSY. 100B ..........1....INCLUDES ITEMS W/# 305910060 FOOT ASSY. 200B ..........1....INCLUDES ITEMS W/$ 009110033 BOLT, SQUARE NECK 10X50 021110120 NUT, NYLON M10 ..........2....REPLACES P/N 022711012 030210250 WASHER, LOCK M10 009110034 BOLT, SQUARE NECK 12X65 021112140 NUT, NYLON M12 ..........4....REPLACES P/N 022711214...

  • Page 41: Cylinder Barrel Assembly

    CYLINDER BARREL CEA0 HONDA GX100RTKRB6 ENG. — CYLINDER BARREL ASSY. PAGE 42 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 42 HONDA GX100RTKRB6 ENG. — CYLINDER BARREL ASSY. PART NO. PART NAME QTY. REMARKS 12000Z0D405 BARREL ASSY., CYLINDER ......1....INCLUDES ITEMS W/$ 12201Z0D305 GUIDE ASSY., EXHAUST VALVE (OS) 12204Z0D305 GUIDE, INLET VALVE (O.S.) 12311Z0D000 COVER, HEAD 12355Z0D000 COVER COMPLETE A, BREATHER 12365Z0D000 COVER COMPLETE B, BREATHER 15171Z0DV00 PIPE, BREATHER...

  • Page 43: Crankcase Cover Assembly

    HONDA GX100RTKRB6 ENG. — CRANKCASE COVER ASSY. PAGE 44 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 44 HONDA GX100RTKRB6 ENG. — CRANKCASE COVER ASSY. PART NO. PART NAME QTY. REMARKS 11300Z0D409 COVER ASSY., CRANK CASE ......1....INCLUDES ITEMS W/# 11511Z0DV00 FLANGE, P.T.O. 15600ZDF000 CAP ASSY., OIL FILLER ........1....INCLUDES ITEMS W/$ 15625Z0T800 PACKING, OIL FILLER CAP 16510ZL8000 GOVERNOR ASSY. 16531ZE1000 SLIDER, GOVERNOR 16541Z0D000...

  • Page 45: Crankshaft Assembly

    HONDA GX100RTKRB6 ENG. — CRANKSHAFT ASSY. PAGE 46 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 46 HONDA GX100RTKRB6 ENG. — CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13310Z0DV00 CRANK SHAFT COMPLETE ......1....INCLUDES ITEM W/$ 91001Z0DV01 BEARING, RADIAL BALL MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17) — PAGE 47...

  • Page 47: Piston/Connecting Rod Assembly

    GX100RT-KRB6 PISTON/CONNECTING ROD CED0 HONDA GX100RTKRB6 ENG. — PISTON/CONN. ROD ASSY. PAGE 48 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 48 HONDA GX100RTKRB6 ENG. — PISTON/CONN. ROD ASSY. PART NO. PART NAME QTY. REMARKS 13010Z0D003 RING SET, PISTON 13101ZDD000 PISTON 13111ZE0000 PISTON PIN 13200Z0D000 CONNECTING ROD ASSY........1....INCLUDES ITEM W/# 90001ZM7000 CONNECTING ROD BOLT 90551ZE0000 CLIP, PISTON PIN 13MM MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17) — PAGE 49...

  • Page 49: Camshaft Pulley Assembly

    HONDA GX100RTKRB6 ENG. — CAMSHAFT PULLEY ASSY. PAGE 50 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 50 HONDA GX100RTKRB6 ENG. — CAMSHAFT PULLEY ASSY. PART NO. PART NAME QTY. REMARKS 12209KT7013 SEAL, VALVE STEM 14320ZDD000 PULLEY COMP., CAMSHAFT/RTE 14324Z0D000 SHAFT, CAM PULLEY 14400Z0D003 TIMING BELT 14431ZDD000 ROCKER ARM, INTAKE VALVE 14441ZDD000 ROCKER ARM, EXHAUST VALVE 14461ZL8000 SHAFT, ROCKER ARM 14711Z0D000 INLET VALVE 14721Z0D000...

  • Page 51: Recoil Starter Assembly

    GX100RT-KRB6 RECOIL STARTER CEF0 HONDA GX100RTKRB6 ENG. — RECOIL STARTER ASSY. PAGE 52 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 52 HONDA GX100RTKRB6 ENG. — RECOIL STARTER ASSY. PART NO. PART NAME QTY. REMARKS 28400Z0DV04ZA RECOIL STARTER ASSY........1....INCLUDES ITEMS W/$ 28410Z0DV02ZA CASE COMPLETE/RECOIL *5-3-5(B) 28421ZDD003 REEL, RECOIL STARTER 28422ZG0W02 RATCHET, STARTER 28433ZG0W02 GUIDE, RATCHET 28441ZW9003 SPRING, FRICTION ..........1....REPLACES P/N 28441ZW6003 28442ZH8003 SPRING, RECOIL STARTER 28461ZDD003...

  • Page 53: Fan Cover Assembly

    HONDA GX100RTKRB6 ENG. — FAN COVER ASSY. PAGE 54 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 54 HONDA GX100RTKRB6 ENG. — FAN COVER ASSY. PART NO. PART NAME QTY. REMARKS 19610Z0DV00ZB FAN COVER COMPLETE, BLK. 35120Z0DV81 SWITCH ASSY., ENGINE STOP/U 90014952000 BOLT, FLANGE 6X14 MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17) — PAGE 55...

  • Page 55: Carburetor Assembly

    HONDA GX100RTKRB6 ENG. — CARBURETOR ASSY. GASKET SET NOTICE Gasket set, item 2 included with items 6, 8, 10 and 30. PAGE 56 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 56 HONDA GX100RTKRB6 ENG. — CARBURETOR ASSY. PART NO. PART NAME QTY. REMARKS 16010Z4EW51 GASKET SET 16011ZDJ851 VALVE SET, FLOAT 16013ZG0811 FLOAT SET 16015Z4EW51 FLOAT CHAMBER SET ........1....INCLUDES ITEM W/% 16016Z0DV21 SCREW SET 16024124760 SCREW SET, DRAIN ........1....INCLUDES ITEM W/% 16028ZC0005 SCREW SET .............1....INCLUDES ITEM W/% 16044Z0DV21 LEVER SET, CHOKE...

  • Page 57: Air Cleaner Assembly

    HONDA GX100RTKRB6 ENG. — AIR CLEANER ASSY. PAGE 58 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 58 HONDA GX100RTKRB6 ENG. — AIR CLEANER ASSY. PART NO. PART NAME QTY. REMARKS 17211ZL8023 CLEANER, ELEMENT 17220Z0DV22 CASE COMPLETE, AIR CLEANER 17228Z0DV21 PACKING, AIR CLEANER 17231Z0DV62 COVER, AIR CLEANER 90011Z0D000 BOLT, AIR CLEANER COVER 90041Z0DV20 STUD BOLT 90042Z0DV20 STUD BOLT 5X75 9405005000 FLANGE NUT 5MM 9405006000...

  • Page 59: Muffler Assembly

    HONDA GX100RTKRB6 ENG. — MUFFLER ASSY. PAGE 60 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 60 HONDA GX100RTKRB6 ENG. — MUFFLER ASSY. PART NO. PART NAME QTY. REMARKS 18310ZDD810 MUFFLER COMPLETE 18321Z0DV22 MUFFLER PROTECTOR 18350ZL8000 ARRESTER COMP.,SPARK/RT-E 18381Z0D000 GASKET, MUFFLER 90014952000 BOLT, FLANGE 6X14 90048Z0DV00 STUD BOLT 6X78 90055ZE1000 TAPPING SCREW 4X6 90343ZE6000 NUT, SELF-LOCK 6 MM MTR40HF RAMMER •...

  • Page 61: Flywheel/Ignition Coil Assembly

    HONDA GX100RTKRB6 ENG. — FLYWHEEL/IGN. COIL ASSY. PAGE 62 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 62 HONDA GX100RTKRB6 ENG. — FLYWHEEL/IGN. COIL ASSY. PART NO. PART NAME QTY. REMARKS 13331ZM7000 WOODRUFF KEY 25X18 28451Z0DV03 STARTER PULLEY 30500Z0DV02 IGNITION COIL ASSY........1....INCLUDES ITEM W/# 30564ZA5000 GROMMET, CORD 30700Z0DV01 TERMINAL ASSY. 30701883000 CLIP, HIGH TENSION CORD 31110Z0D003 FLYWHEEL COMPLETE 32195Z0D000 CORD, STOP SWITCH 90022888010...

  • Page 63: Control Assembly

    HONDA GX100RTKRB6 ENG. — CONTROL ASSY. PAGE 64 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 64 HONDA GX100RTKRB6 ENG. — CONTROL ASSY. PART NO. PART NAME QTY. REMARKS 16500Z4ES30 CONTROL ASSY..........1....INCLUDES ITEMS W/$ 16550Z0DV21 GOVERNOR ARM ..........1....INCLUDES ITEM W/# 16555Z0DV20 GOVERNOR ROD 16561Z0DV20 GOVERNOR SPRING 16562Z0DV20 SPRING,THROTTLE 16594883010 HOLDER, WIRE 90014952000 BOLT, FLANGE 6X14 90015Z5T000 BOLT, GOVERNOR ARM 90605230000 CIR CLIP 92301050220A...

  • Page 65: Label Assembly

    HONDA GX100RTKRB6 ENG. — LABEL ASSY. PAGE 66 — MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17)
  • Page 66 HONDA GX100RTKRB6 ENG. — LABEL ASSY. PART NO. PART NAME QTY. REMARKS 87516ZDD000 MARK, OPERATOR CAUTION/ENG 87521ZDDP10 EMBLEM (GX100) (RAMMER) 87528Z0D000 MARK, CHOKE 87539Z0J000 MARK, EX. CAUTION/PICTO 87601ZDJV20 MARK, TYPE (KRB6) MTR40HF RAMMER • OPERATION AND PARTS MANUAL — REV. #0 (09/14/17) — PAGE 67...

  • Page 67: Terms And Conditions Of Sale - Parts

    One of our experienced staff members will get back to you with a quote for the right part that your machine needs. We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone, Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,...
