  • Page 1 Big Round Modular Table System Installation guide...

  • Page 2: Mounting Materials

    Mounting materials Frame parts The size and amount of delivered materials depends on the chosen table type M6x35 (full thread) PZ 5x16 M8x16 Sliding nut M8 Adjustable feet Big Round profile 360mm Big Round profile 540mm Big Round profile 700mm Domino Tabletop connector Big Round corner piece...
  • Page 3 Assembling hexagon frame Assembling table legs Make sure the surface you are working Insert sliding nuts Assembly of Big Round Table requires at least two people. on is flat and use a protective blanket on the floor to prevent damage Insert the M8 sliding nuts in three opposing profiles.
  • Page 4 Connect legs to the frame Attach adjustable feet Connect the table legs to the Please, take into account that hexagon frame with 4x M8x16 adjustable feet are intended for bolts per leg using the allen key. levelling the tabletop and not for height adjustment.
  • Page 5 Connecting tabletops Place the domino's in the corresponding holes Place one part of the tabletop onto the frame Make sure the tabletop is centered with the frame. Place the second tabletop part onto the frame, align it and push the two sides together so Fasten the tabletop using one screw the tabletops are leveled.
  • Page 6 Insert tabletop connectors underneath the Fasten the tabletop upon the frame tabletop Use PZ 5x16 screws to attach the tabletop to the frame. Make sure the tabletop connectors are not too tight to be able to align the tabletops. You are all set! Align the tabletop parts Make sure the tabletop parts align perfectly before...
  • Page 7 Find us at Get in touch Stay up to date Dijkgraaf 38 +31 (0) 26 820 03 60 @de_vorm 6921 RL Duiven sales@devorm.nl /company/de-vorm W www.devorm.nl The Netherlands /devorm_interiorproducts...
