- Page 1 Big Modular Table System Installation guide...
-
Page 2: Mounting Materials
Mounting materials Frame parts The size and amount of delivered materials depends on the chosen table type Center grooved pin Butt connector M8x16 Bolt plate Adjustable feet Big profile 1200mm Big profile 1800mm Big profile 2400mm Big profile cover 460mm Big profile cover 680mm Big profile cover 980mm Domino... - Page 3 Preparation Place the butt connectors in the corresponding cavities. Make sure the surface you are working Assembly of Big Table requires at least two people. on is flat and use a protective blanket on the floor to prevent damage. Assembling table frame Connect profiles Place 1x center-grooved pin in each opposing slot of...
- Page 4 Insert crossbars Make sure the frame ends are perfectly aligned with each other. Slide the crossbars into the profiles - divide them equally depending on the number of crossbars. Tighten crossbars When the table has more than Tighten the bolts in the 4 legs, please, consider the crossbar to secure them to crossbar layout carefully.
- Page 5 Assembling table legs Connect the middle legs to the frame (only applicable to tables with 6 or 8 legs) Connect the outer legs to the frame The table legs in the middle of Each table leg is atttached the profile are mounted with to the frame using 2x M8 four M8 sliding nuts.
- Page 6 Attach adjustable feet Mount profile covers Please, take into account that Use the self-tapping screws adjustable feet are intended for M3x10 to mount the profile levelling the tabletop and not cover on the both sides of the for height adjustment. frame.
- Page 7 Connecting tabletops Insert tabletop connectors underneath the tabletop Place the domino's in one part of the tabletop and connect it with another part Align the tabletop parts Make sure the tabletop parts align perfectly before tightening the tabletop connectors. Please, double check the tabletop alignment before proceeding to the next step.
- Page 8 Tighten the tabletop connectors You are all set! Use an allen key to tighten the tabletop connectors when both tabletops are perfectly aligned. Fasten the tabletop upon the frame...
- Page 9 Find us at Get in touch Stay up to date Dijkgraaf 38 +31 (0) 26 820 03 60 @de_vorm 6921 RL Duiven sales@devorm.nl /company/de-vorm W www.devorm.nl The Netherlands /devorm_interiorproducts...
