Moes ZC-LP01 Instruction Manual

Instruction Manual
HOME, SMART MOES HOME
Smart Sliding Windows Pusher
Zigbee 3.0
English
ZC-LP01-MS-DE22
Bitte scannen Sie den QR-Code, um das deutsche Handbuch, das Installationsvideo und die
Funktionseinführung zu erhalten
Escanee el código QR para obtener el manual en español, el video de instalación y la intro-
ducción de la función
Veuillez scanner le code QR pour obtenir le manuel en français, la vidéo d'installation et
l'introduction des fonctions
Отсканируйте QR-код, чтобы получить руководство на русском языке, видео по
установке и описание функций
Scansionare il codice QR per ottenere il manuale in italiano, il video di installazione e la
guida alle funzionalità. Video di installazione e funzionalità
Leia o código QR para obter o manual em português, o vídeo de instalação e a introdução
das funções
Zeskanuj kod QR, aby uzyskać instrukcję obsługi, film instalacyjny i wprowadzenie do funkcji
QR コードをスキャンして、英語のマニュアル、インストールビデオ、機能紹介を入手してくだ
さい
QR 코드를 스캔하여 영어 설명서, 설치 동영상, 기능 소개를 확인하세요.
1.Attention
1. Lithium battery powered equipment was used with an ambient temperature of 0 ℃ to
45 ℃, and equipped with temperature protection. When the temperature exceeds 55 ℃,
the battery power will be stopped to avoid risks. After the overall temperature of the
equipment drops, it will start running again. Do not place this product near a heat source;
2. The equipment has no waterproof design, and it is strictly prohibited to install and use
it outdoors! Avoid getting wet or soaking the equipment;
3. During daily use, if both the APP and the buttons cannot be controlled properly, you
can try pressing the reset button to reset. If the problem is not resolved, you need to
contact the after-sales service for coordination and resolution. Any losses caused by
dismantling the equipment will be borne by yourself;
4. If adhesive bonding is chosen, the product cannot be used, and it will be extremely
difficult to disassemble and may cause damage to the window frame. Before installation,
please carefully evaluate according to the installation instructions or video tutorials. If the
usage conditions are not met, please do not install;
5. It is strictly prohibited to install windows on the outer side at high altitudes to prevent
them falling off;
6. The rubber wheel is easy to grip during operation, please do not touch and keep away
from children;
7. The attached lubricating oil is door and window track lubricating oil, which is prohibited
from consumption.
2.Product Introduction
The Smart Sliding Windows Pusher is a low-power intelligent device that communicates
through ZigBee. The product uses a wiring free and lithium battery power supply solution
and a hole free solution, supports both solar and USB charging. It has functions such as
APP control, intelligent voice control, manual operation, and also supports manual opening
and closing control, stopping when encountering obstacles.
Left
Indicator
Buckle
Front View
1
Right
Reset
Rubber Wheel
Right View
Figure 1
