  • Page 1 DADF-BA1 SERVICE MANUAL Canon December 3, 2019 Rev. 2 COPYRIGHT 2019 CANON INC. CANON DADF-BA1 Rev. 2 PRINTED IN U.S.A. ©...

  • Page 2: Explanation Of Symbols

    When changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition of this manual.
  • Page 3 Introduction Symbols Explanation Symbols Explanation Disconnect the connector. Connect the power cable. Connect the connector. Disconnect the power cable. Remove the cable/wire from the Turn on the power. cable guide or wire saddle. Install the cable/wire to the cable Turn off the power. guide or wire saddle.

  • Page 4: Table Of Contents

    Contents Contents Safety Precautions....................1 Notes Before Servicing........................2 Points to Note at Cleaning........................2 Notes on Assembly/Disassembly......................2 1. Product Overview.....................3 Features.............................4 Specifications..........................5 Name of Parts............................. 6 External View............................6 Cross Section ........................... 6 2. Technical Explanation..................7 Basic Configuration..........................8 Functional Configuration........................8 Electric Circuit Diagram........................
  • Page 5 Contents External Cover............................ 35 Main Unit............................36 Consumable Parts Requiring Periodic Replacement and Cleaning Points..........36 Sensor............................... 37 Clutch, Solenoid, Motor, PCB.......................38 Other..............................39 Removing this Machine from the Host Machine................40 Procedure............................40 External Cover...........................42 Removing the Front Cover........................42 Removing the Rear Cover........................43 Removing the Feeder Cover........................
  • Page 6 Checking the Contents........................92 Installation Procedure........................93 Installing the ADF..........................93 Connecting the Cable.......................... 96 Affixing the Label..........................99 Cleaning the Stream Reading Glass.....................99 Operation Check ..........................101 APPENDICES....................102 Service Tools...........................103 Special Tools............................ 103 Solvents and Oils..........................103 General Circuit Diagram........................104 DADF-BA1............................104...

  • Page 7: Safety Precautions

    Safety Precautions Notes Before Servicing......2 Points to Note at Cleaning....2 Notes on Assembly/Disassembly..2...

  • Page 8: Notes Before Servicing

    Safety Precautions Notes Before Servicing CAUTION: At servicing, be sure to turn off the power source of the host machine according to the specified steps and disconnect the power plug. CAUTION: Do not turn off the power switch when downloading is under way. Turning off the main power switch while downloading is under way can disable the machine.

  • Page 9: Product Overview

    Product Overview Features..........4 Specifications........5 Name of Parts........6...

  • Page 10: Features

    1. Product Overview Features • Improvement of quick-engaging/disengaging the Pickup roller assembly and the Separation roller • Improvement of paper curl detection by the modification the Document length sensor • Installation of the Document delivery Lamp function...

  • Page 11: Specifications

    1. Product Overview Specifications Item Specifications Document pickup method Automatic pickup and delivery Document loading direction Face-up Document loading position Aligned to center Document separation method Upper separation Document weight Single -sided AB configuration: 42 to 128 g/m (Single-sided one sheet feed: 38 to 128 g/m Inch configuration: 50 to 128 g/m Double-sided 50-128 g/m...

  • Page 12: Name Of Parts

    1. Product Overview Name of Parts External View Name Name Feeder Cover Document supply tray Front Cover Document delivery assembly Rear Small Cover Front Cover Slide guide Cross Section [9] [8] Name Name Lower registration roller Lower delivery reversal roller Upper registration roller Lead roller 2 (upper) Pickup roller assembly...

  • Page 13: Technical Explanation

    Technical Explanation Basic Configuration....... 8 Basic Operation........11 Document Pickup/Feed.......17 Document Reversing......19 Document Delivery......21 Document Detection......22 Detecting Jams........26 Power Supply........28 Original Output Indicator..... 29 Upgrading..........30...

  • Page 14: Basic Configuration

    2. Technical Explanation Basic Configuration Functional Configuration ■ List of Major Electric Parts PCB1 PCB4 PCB5 PCB2 PCB3 Symbol Name Symbol Name Pickup clutch PCB1 ADF driver PCB Registration clutch PCB2 Document set LED PCB Release solenoid PCB3 Different width sensor PCB Stamp solenoid PCB4 Document width sensor PCB...
  • Page 15 2. Technical Explanation Name Lower delivery reversal roller Lead roller 2 (lower) Lead roller 2 (upper) [10] Platen roller [11] Lead roller [12] Lead roller 1 (lower) [13] Lead roller 1 (upper) ■ Sensor Layout SR9/SR10/SR11/SR12 SR15 SR13/SR14 Symbol Name Detection description Registration sensor Registration arch creation timing...

  • Page 16: Electric Circuit Diagram

    2. Technical Explanation ■ Drive Configuration Symbol Name Role Pickup motor Pickup documents. Read motor Feeds documents when Stream reading or Delivery. Release solenoid Shifts the Lower delivery reversal roller after reversal of a document. Stamp solenoid Stamps on a document. Pickup clutch Transmit the Pickup motor drive to the Pickup roller and the Feed roller.

  • Page 17: Basic Operation

    2. Technical Explanation Basic Operation Outline The ADF has the following operation modes. Operation mode name Outline of operation Associated print mode Forward pickup/Delivery Picks up, reads, and then delivers a document. Single-sided document -> Simplex printing Single-sided document -> Duplex printing Forward feed/Reverse Picks up, reads, reverses, and delivers a document.

  • Page 18: Forward Pickup/Reverse Delivery Operation

    2. Technical Explanation Completion of reading of Completion of reading of first document sheet second document sheet Completion of delivery of Start of reading of the second document sheet/ second document sheet End of job Completion of delivery of first document sheet Forward Pickup/Reverse Delivery Operation Duplex read operation (when two document sheets are placed)
  • Page 19 2. Technical Explanation Document Start of reading of front side of first document sheet Pickup and formation of loop End of reading of of first document sheet first document sheet Position to start of Stop after feeing the first reading of first document sheet document sheet to reversal position To next...
  • Page 20 2. Technical Explanation Stop after feeding the first Removal of registration loop of document sheet to reversal reverse side of the first document position sheet/Re-pickup/ Release of the Lower delivery reversal roller Removal of idle registration Position to start reading of loop at the first document sheet/ reverse side at Re-pickup/Release of...
  • Page 21 2. Technical Explanation Start of separation at End of reading of front side of the seconddocument sheet/ second document sheet Pressurization of the Lower delivery reversal roller Start of reading of top side of Stop after feeding second document sheet the second document sheet to reversal position Delivery of first document sheet...
  • Page 22 2. Technical Explanation Removal of idle registration Start of reading of reverse loop at the second document sheet/ side of second document sheet Re-pickup/Release of the Lower delivery reversal roller End of reading of reverse Delivery of second document sheet/ side of second document sheet Pressurization at the Lower delivery reversal roller...

  • Page 23: Document Pickup/Feed

    2. Technical Explanation Document Pickup/Feed Basic Operation After pressing the start key with a document placed on the Document supply tray, a document is picked up in the following procedure. ■ Pickup Operation The Pickup motor (M1) drives to lower the Pickup roller assembly through the Pickup clutch (CL1) and then the Pickup roller rotates to feed a document.

  • Page 24: Pickup Roller Assembly And Separation Roller

    2. Technical Explanation ■ Stream reading The stream reading starts when the leading edge of a document reaches the reading point and the read start signal is received from the host machine. "Stream reading" is a scan function which a document is scanned while feeding along the Document glass. The Scanner which is fixed under the Document glass reads the image.

  • Page 25: Document Reversing

    2. Technical Explanation Document Reversing Basic Operation There are two types of document reversal operation: one that is performed from the top to the reverse side of the document and the other that is performed from the reverse side to the top of the document. Since the basic operation methods are identical, only the reversal operation performed from the reverse side to the top is discussed below.
  • Page 26 2. Technical Explanation Lower registration roller Upper delivery Read roller 1 reversal roller (Upper) Reading start point...

  • Page 27: Document Delivery

    2. Technical Explanation Document Delivery A document is delivered by the Lead roller 2 (upper) and the Upper delivery reversal roller driven by the Read motor (M2). Upper delivery reversal roller Read roller 2 (Upper)

  • Page 28: Document Detection

    2. Technical Explanation Document Detection Outline This machine detects a document using either of the two methods depending on the print mode. • Normal print mode (other than mixed size print mode and banner paper mode) • Mixed size print mode and banner paper mode Normal print mode Function Description...
  • Page 29 2. Technical Explanation SR14 SR15 SR13 The following table shows the relationship among length detection sensor signals, document widths, and initial document sizes. Document width detection Document length detec- Detected size tion Width (mm) Document Document Document Document Document INCH AB/INCH AB/K width sensor...

  • Page 30: Mixed Width Document Size Detection

    2. Technical Explanation Document width detection Document length detec- Detected size tion More than 11 × 17 11 × 17 263.5 and 11 × 17 11 × 17 288.2 or less 11 × 17 11 × 17 More than 11 × 17 288.2 11 ×...
  • Page 31 2. Technical Explanation Different series of size Maximum size Width (mm) 148.5 297.0 257.0 210.0 182.0 Inch configuration Mixed Different series of size LTRR STMT STMTR Maximum size Width (mm) 215.9 139.7 11 × 17 279.0 215.9 LTRR STMT Item Contents Combination assured Not assured.

  • Page 32: Detecting Jams

    2. Technical Explanation Detecting Jams This machine detects document jams using the sensors shown below. Document jam check timing is controlled by the host machine which determines jam occurrence by document existence on the specific sensors. Jam codes can be checked by outputting a jam error log report in the service mode of the host machine. ACC ID JAM Code JAM Type...
  • Page 33 2. Technical Explanation *2: Limited functions jam is a jam for preventing an original to be left inside the machine when a problem which requires the machine moves to limited functions mode occurs. If an error occurs for some reasons, a jam message is displayed to make the user to perform jam removal.

  • Page 34: Power Supply

    2. Technical Explanation Power Supply The power supply lines are shown below. This machine power is supplied from the host machine. Motor Solenoid Clutch Host machine Sensor ADF driver PCB...

  • Page 35: Original Output Indicator

    2. Technical Explanation Original Output Indicator After completion of reading, the LED at the Document delivery LED PCB (PCB5) lights ON to prevent from leaving a document. The LED keeps lighting for 10 seconds and then turns OFF. PCB5 Related service mode •...

  • Page 36: Upgrading

    2. Technical Explanation Upgrading Outline Since this equipment is not equipped CPU, upgrading is not possible by itself. Upgrade it on the host machine.

  • Page 37: Periodical Service

    Periodical Service Consumable Parts List......32 leaning/Check/Adjustment Locations ............33...

  • Page 38: Consumable Parts List

    3. Periodical Service Consumable Parts List Parts name Parts num- Estimated life Service Mode Alarm code Parts counter Replacement (COUNTER > completion DRBL-2) Pickup Roller FM1-D470 80,000 sheets DF-PU-RL 43-0125 Separation Roller FM1-D471 80,000 sheets DF-SP-RL 43-0092 Left Hinge FE3-5484 150,000 times DF-HNG-L...

  • Page 39: Leaning/Check/Adjustment Locations

    3. Periodical Service leaning/Check/Adjustment Locations Name Timing Work description Pickup roller 40,000 sheets or six months Cleaning (Enforcement timely at the time of visits such as Separation roller Cleaning the parts exchange) Registration roller Cleaning Feed Guide (Dust collecting tape) Cleaning Delivery reverse roller Cleaning...

  • Page 40: Parts Replacement And Cleaning

    Parts Replacement and Cleaning List of Parts......... 35 Removing this Machine from the Host Machine........... 40 External Cover........42 Main Unit..........47 Periodic Replacing Parts, Durable Parts, Cleaning Parts.......50 Sensor..........54 Clutch, Motor, PCB, Other....59...

  • Page 41: List Of Parts

    4. Parts Replacement and Cleaning List of Parts External Cover Name Reference Front Cover “Removing the Front Cover” on page 42 Rear Cover “Removing the Rear Cover” on page 43 Feeder Cover “Removing the Feeder Cover” on page 44 Rear Small Cover “Removing the Rear Cover”...

  • Page 42: Main Unit

    4. Parts Replacement and Cleaning Main Unit Name Reference Feed Assembly “Removing the Feed Assembly” on page 47 Consumable Parts Requiring Periodic Replacement and Cleaning Points Name Reference Pickup roller assembly “Removing the Pickup Roller Assembly” on page Separation roller “Removing the Separation Roller”...

  • Page 43: Sensor

    4. Parts Replacement and Cleaning Name Reference Stamper “Replacing the Stamp” on page 51 Left hinge “Removing the Left Hinge” on page 52 Sensor SR14 SR15 SR11 SR13 SR12 SR10 Name Registration Sensor Read Sensor Delivery Reversal Sensor Document Set Sensor Cover Open/Closed Sensor Document Length Sensor 1 Document Length Sensor 2...

  • Page 44: Clutch, Solenoid, Motor, Pcb

    4. Parts Replacement and Cleaning Clutch, Solenoid, Motor, PCB PCB1 PCB4 PCB5 PCB2 PCB3 Name Pickup Motor Read Motor Release Solenoid Pickup Clutch Registration Clutch PCB1 Adf Driver Pcb PCB2 Original Set Indicator PCB3 Different Width Sensor Pcb PCB4 Document Width Sensor Pcb PCB5 Original Output Indicator...

  • Page 45: Other

    4. Parts Replacement and Cleaning Other Name Reference Right hinge “Removing the Right Hinge” on page 62 Platen roller “Removing the Platen Roller” on page 63...

  • Page 46: Removing This Machine From The Host Machine

    4. Parts Replacement and Cleaning Removing this Machine from the Host Machine Procedure...
  • Page 47 4. Parts Replacement and Cleaning Actions after Replacement:“Adjustment After Replacing the Parts” on page 67...

  • Page 48: External Cover

    4. Parts Replacement and Cleaning External Cover Removing the Front Cover ■ Procedure 1. Open the Feeder Cover [1]. 2. Remove the screw [1]. 3. Open the ADF. 4. Remove the 2 screws [2].

  • Page 49: Removing The Rear Cover

    4. Parts Replacement and Cleaning 5. Close the ADF. 6. Remove the Front Cover [1]. • 3 Hooks [2] Removing the Rear Cover ■ Procedure 1. Open the Feeder Cover [1].

  • Page 50: Removing The Feeder Cover

    4. Parts Replacement and Cleaning 2. Remove the Rear Small Cover [1]. • 1 Screw [2] 3. Remove the Rear Cover [1]. • 2 Screws [2] • 2 Claws [3] Removing the Feeder Cover ■ Preparation 1. Remove the Rear Cover.“Removing the Rear Cover”...

  • Page 51: Removing The Inner Cover

    4. Parts Replacement and Cleaning ■ Procedure 1. Remove the Harness [1]. • 1 Screw [2] • 1 Grounding Wire [3] • 1 Connector [4] • 1 Wire Saddle [5] • 2 Clamps [6] 2. Remove the Feeder Cover [1]. •...
  • Page 52 4. Parts Replacement and Cleaning ■ Procedure 1. Remove the Inner Cover [1]. • 1 Screw [2] • 2 Claws [3]...

  • Page 53: Main Unit

    4. Parts Replacement and Cleaning Main Unit Removing the Feed Assembly ■ Preparation 1. Remove the Front Cover.“Removing the Rear Cover” on page 43 2. Remove the ADF from the host machine.“Removing this Machine from the Host Machine” on page 40 3.
  • Page 54 4. Parts Replacement and Cleaning 3. Remove the 8 Connectors [1] on the ADF driver PCB. 4. Remove the Document supply tray [1]. • 1 Screw [2] • 1 Grounding Wire [3] • 1 Ferrite Core [4] • 1 Harness [5] 5.
  • Page 55 4. Parts Replacement and Cleaning 9. Remove the harness guide [1]. • 1 Screw [2] • 1 Connector [3] 10. Remove the Feed assembly [1]. • 6 Screws [2]...

  • Page 56: Periodic Replacing Parts, Durable Parts, Cleaning Parts

    4. Parts Replacement and Cleaning Periodic Replacing Parts, Durable Parts, Cleaning Parts Removing the Pickup Roller Assembly ■ Procedure 1. Open the Feeder cover [1]. 2. Remove the Pickup roller assembly [1]. 3. When replacing the Pickup roller assembly with a new one, clear the parts counter. COPIER >...

  • Page 57: Removing The Separation Roller

    4. Parts Replacement and Cleaning Removing the Separation Roller ■ Procedure 1. Open the Feeder cover [1]. 2. Remove the Separation roller [1]. 3. When replacing the Separation roller with a new one, clear the parts counter. COPIER > COUNTER > DRBL-2 > DF-SP-RL Replacing the Stamp ■...

  • Page 58: Removing The Left Hinge

    4. Parts Replacement and Cleaning 3. Attach the new Stamper [1]. (Be careful to set the Stamper side to the front.) 4. Close the Feeder cover and Separation guide. CAUTION: If the Stamper is floating, a jam can occur. Be sure to push in the Stamper until it clicks. 5.
  • Page 59 4. Parts Replacement and Cleaning ■ Procedure 1. Remove the Left hinge [1]. • 6 Screws [2] CAUTION: Be careful not to drop the Left hinge. Hold it while removing the screws from it. 2. When replacing the Left hinge with a new one, clear the parts counter. COPIER >...

  • Page 60: Sensor

    4. Parts Replacement and Cleaning Sensor Removing the Different Width Sensor PCB (PCB3) ■ Preparation 1. Remove the Inner cover.“Removing the Inner Cover” on page 45 ■ Procedure 1. Remove the sensor holder [1]. • 3 Screws [2] 2. Remove the Different width sensor PCB [1]. •...
  • Page 61 4. Parts Replacement and Cleaning ■ Procedure 1. Remove the fixing plate [1]. • 3 Screws [2] 2. Turn over the Feed assembly, remove the following parts. • 1 Resin ring [1] • 1 Flange [2] • 1 Pulley [3] •...
  • Page 62 4. Parts Replacement and Cleaning 3. Remove the Platen roller unit [1]. • 2 Claws [2] 4. Remove the Cover [1]. • 2 Screws [2]...
  • Page 63 4. Parts Replacement and Cleaning 5. Remove the Lead roller 2(upper) [1]. • 1 Resin ring [2] • 1 Flange [3] • 1 Pulley [4] • 1 E-ring [5] • 1 Bearing [6] • 1 Gear [7] • 1 Bushing [8] 6.
  • Page 64 4. Parts Replacement and Cleaning 7. Remove the Sensors [1]. • 3 Connectors [2] [1] SR3 [1] SR1 [1] SR2...

  • Page 65: Clutch, Motor, Pcb, Other

    4. Parts Replacement and Cleaning Clutch, Motor, PCB, Other Removing the Pickup Motor (M1) ■ Preparation 1. Remove the Rear Cover.“Removing the Rear Cover” on page 43 2. Remove the Clutch unit.“Removing the Pickup Clutch/Registration Clutch (CL1/CL2)” on page 60 ■...

  • Page 66: Removing The Pickup Clutch/Registration Clutch (Cl1/Cl2)

    4. Parts Replacement and Cleaning ■ Procedure 1. Remove the Read motor [1]. • 1 Connector [2] • 3 Screws [3] • 1 Spring [4] ■ Actions after Replacement 1. Adjusting the Magnification.“ Adjusting the Magnification (Sub Scanning Direction) ” on page 80 Removing the Pickup Clutch/Registration Clutch (CL1/CL2) ■...

  • Page 67: Removing The Adf Driver Pcb (Pcb1)

    4. Parts Replacement and Cleaning 2. Remove the 2 Clutches [1]. • 2 Resin rings [2] • 2 Bushings [3] [1] CL1 [1] CL2 Removing the ADF Driver PCB (PCB1) ■ Preparation 1. Remove the Rear Cover.“Removing the Rear Cover” on page 43 ■...

  • Page 68: Removing The Right Hinge

    4. Parts Replacement and Cleaning ■ Procedure 1. Remove the sensor holder [1]. • 3 Screws [2] 2. Remove the LED PCB [1]. • 1 Screw [2] • 1 Connector [3] Removing the Right Hinge ■ Preparation 1. Remove the ADF from the host machine.“Removing this Machine from the Host Machine”...

  • Page 69: Removing The Platen Roller

    4. Parts Replacement and Cleaning 2. Remove the Right hinge [1]. • 2 Screws [2] Removing the Platen Roller ■ Preparation 1. Remove the Feed assembly.“Removing the Feed Assembly” on page 47 ■ Procedure 1. Remove the fixing plate [1] •...
  • Page 70 4. Parts Replacement and Cleaning 2. Turn over the Feed assembly, remove the following parts. • 1 Resin ring [1] • 1 Flange [2] • 1 Pulley [3] • 1 E-ring [4] • 1 Bearing [5] • 1 Gear [6] •...
  • Page 71 4. Parts Replacement and Cleaning 4. Remove the Platen roller [1]. • 2 Screws [2] • 1 Plate [3] • 1 Platen roller holder (front) [4] • 1 Bushing [5] • 1 Gear [6] • 1 Platen roller holder (rear)[7]...

  • Page 72: Adjustment

    Adjustment Adjustment After Replacing the Parts ............67 Overview of Adjustment...... 68 Preparation or Creation of Test Chart ............69 Adjusting the Height......70 Adjusting the Perpendicularity.... 75 Adjusting the Reading Position... 79 Adjusting the Magnification (Sub Scanning Direction) ......80 Adjusting the Image Position (Main Scanning Direction)......

  • Page 73: Adjustment After Replacing The Parts

    5. Adjustment Adjustment After Replacing the Parts In case of removing the parts as shown below, adjust the following item. Parts to Replace Reference “Adjusting the Height” on page 70 “Adjusting the Perpendicularity” on page 75 “Adjusting the Reading Position” on page 79 “...

  • Page 74: Overview Of Adjustment

    5. Adjustment Overview of Adjustment The ADF has the following adjustment items. The following is the order of adjustment. Adjustment Items Adjusting the Height Adjusting the Perpendicularity Adjusting the Reading Position Adjusting the Magnification (Sub Scanning Direction) Adjusting the Image Position (Main Scanning Direction) Adjusting the Image Position (Sub Scanning Direction) Adjusting the White Level...

  • Page 75: Preparation Or Creation Of Test Chart

    5. Adjustment Preparation or Creation of Test Chart Prepare a test chart. If there is no test chart, create a test chart. Create a test chart that has a 10 mm smaller rectangle from the edge of A4 or LTR paper. NOTE: Be sure to write a character or mark to identify the printed image direction.

  • Page 76: Adjusting The Height

    5. Adjustment Adjusting the Height NOTE: Check following the procedure below and proceed to adjustment if necessary. Check the Left Hinge Height ■ When Visual Check 1. Close the ADF and check whether the front and rear Stream Reading glass spacers are in close contact with the Stream Reading glass.
  • Page 77 5. Adjustment ■ When Check with the Paper 1. Check the rear-left height of the ADF. Cut a sheet of paper to make a paper slip with width of 45mm. Set paper against the protrusion in such a manner that the sheet is nearly hidden, and then close the ADF.

  • Page 78: Check The Right Hinge Height

    5. Adjustment 3. Check the front-left height of the ADF. Set paper against the protrusion in such a manner that the sheet is nearly hidden, and then close the ADF. CAUTION: Set paper so that it does not reach the document reader. Paper 4.

  • Page 79: Order Of Adjustment

    5. Adjustment ■ Order of Adjustment When the front or rear side is floating: 1. Adjust the Left Hinge Height. 2. Adjust the Right Hinge Height. 3. Check the Left Hinge Height. (Check the height of the Left Hinge. If the height is inappropriate, adjust it again.) When both sides are floating: 1.

  • Page 80: Adjusting The Left Hinge Height

    5. Adjustment Adjusting the Left Hinge Height 1. Adjust the height with the left hinge height adjusting screw. CAUTION: Loosen the lock nut before adjustment, and tighten it after adjustment. • If the front spacer is floating, turn the adjusting screw clockwise to bring the front spacer closer to the glass. •...

  • Page 81: Adjusting The Perpendicularity

    5. Adjustment Adjusting the Perpendicularity 1. Copy the test chart with the ADF. 2. Check the perpendicularity at the leading edges of the test chart and copy. Measure dimensions A and B on the test chart and dimensions A' and B' on the copy. If (A-B) is not same as (A'-B'), go step 3 and following steps.
  • Page 82 5. Adjustment 3. Loosen the screw securing the right hinge, and slide the hinge to the front or rear with reference to the marking-off line to adjust the perpendicularity. • For B'>A' Slide the hinge to rear side. • For A'>B' Slide the hinge to front side.
  • Page 83 5. Adjustment 5. Remove the White Plate. 6. Place the White Plate on the Copyboard Glass by aligning it with the Index Sheet. 7. Close the ADF, and then open it again.
  • Page 84 5. Adjustment 8. Press the White Plate upward as shown in the figure below. CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward. 9. With the ADF closed, check that the White Plate is not placed on the Index Sheet as shown in the figures. CAUTION: Be sure that there is no gap between the White Plate and the Index Sheet.

  • Page 85: Adjusting The Reading Position

    5. Adjustment Adjusting the Reading Position 1. Execute the following item in the service mode. COPIER > FUNCTION > INSTALL > STRD-POS 2. Press [OK] or [Yes]. The scanner to start a scan; in several seconds, the ADF will end auto adjustment of the reading position. 3.

  • Page 86: Adjusting The Magnification (Sub Scanning Direction)

    5. Adjustment Adjusting the Magnification (Sub Scanning Direction) 1. Copy the test chart with the ADF. 2. Compare the image length in feed direction between the copy and the test chart. As necessary, make the following adjustment. Adjustment Procedure 1. Select the following item in the service mode. FEEDER >...
  • Page 87 5. Adjustment 2. Change the value as gap A in the figure. • If the printed image is longer: Increase the value. (The image shrinks in the feed direction.) • If the printed image is shorter: Decrease the value. (The image extends in the feed direction.) Setting Value;...

  • Page 88: Adjusting The Image Position (Main Scanning Direction)

    5. Adjustment Adjusting the Image Position (Main Scanning Direction) 1. Copy the test chart with the ADF. 2. Compare the horizontal registration between the copy and the test chart. As necessary, make the following adjustment. Adjustment Procedure 1. Select the following item in the service mode. COPIER >...
  • Page 89 5. Adjustment 2. Change the value as gap A in the figure. • If the image is displaced to the rear: Increase the value. (The image shifts to the front.) • If the image is displaced to the front: Decrease the value. (The image shifts to the rear.) Setting Value;...

  • Page 90: Adjusting The Image Position (Sub Scanning Direction)

    5. Adjustment Adjusting the Image Position (Sub Scanning Direction) 1. Copy the test chart with the ADF. 2. Compare the leading edge registration between the copy and the test chart. As necessary, make the following adjustment. Adjustment Procedure 1. Select the following item in the service mode. FEEDER >...
  • Page 91 5. Adjustment 2. Change the value as gap A in the figure. • If the image is displaced to the trailing edge: Increase the value. (The image shifts to the leading edge.) • If the image is displaced to the leading edge: Decrease the value. (The image shifts to the trailing edge.) Setting Value;...

  • Page 92: Adjusting The White Level

    5. Adjustment Adjusting the White Level CAUTION: This is a item of adjustment in which the white level of images made in stream reading mode are matched with the white level of images made in book mode. If this adjustment is skiped, the following will likely occur: •...
  • Page 93 5. Adjustment 10. Select the following item in the service mode to check the value, and write down the new adjustment value on the service label. COPIER > ADJUST > CCD > DFTAR-R COPIER > ADJUST > CCD > DFTAR-G COPIER >...

  • Page 94: Installing Hinge Covers

    5. Adjustment Installing Hinge Covers...

  • Page 95: Installation

    Installation Pre-checks.......... 90 Checking the Contents......92 Installation Procedure......93 Operation Check ......101...

  • Page 96: Pre-Checks

    6. Installation Pre-checks Essential Items to Be NOTE: Performed Before Installation The weight of the ADF is about 8.2kg. • Turn OFF the main power of the host machine, and disconnect the power plug from the outlet. WARNING: • If performing work without disconnecting the power plug of the host machine, it may cause electrical shock.
  • Page 97 6. Installation CAUTION: Because its balance may be lost when installing this equipment to the host machine, do not remove the tape or cushioning material of the harness, Feeder Cover and Document Pickup Tray when unpacking. Remove in step 12 of "Installing the ADF".

  • Page 98: Checking The Contents

    6. Installation Checking the Contents [3*] [3*] Parts Name ADF main unit 1 unit Hinge Cover 2 pcs. [3*] Face Sticker 2 pcs. Stepped Screw(Black); M5x6 2 pcs. Flat Head Screw; M4x10 2 pcs. TP(Round End); M3×8 1 pc. Glass Cleaning Label 1 pc.

  • Page 99: Installation Procedure

    6. Installation Installation Procedure Installing the ADF Stepped Screw (Black); M5x6 NOTE: Use this parts only when replacing the Platen Cover with the ADF.
  • Page 100 6. Installation NOTE: Installing the ADF From the rear side of the host machine, fit hinges in the order shown in the below figure onto the Stepped Screws and then slide it toward the front direction. CAUTION: • Do not touch the platen roller while installing the ADF.
  • Page 101 6. Installation CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.

  • Page 102: Connecting The Cable

    6. Installation Connecting the Cable ■ For imageRUNNER 2645/2635 Series / imageRUNNER C3125/C3120 CAUTION: • With the ADF closed, check that the White Plate is Series not placed on the Index Sheet as shown in the figures. • Be sure that there is no gap between the White Plate and the Index Sheet.
  • Page 103 6. Installation CAUTION: Fix the Grounding Cable in the correct direction. P Tighteing; M3x8 TP (Round End); M3x8 ■ For imageRUNNER ADVANCE DX 4745/4735/4725 Series /...
  • Page 104 6. Installation imageRUNNER ADVANCE DX C3730/ C3725/C3720 Series CAUTION: Fix the Grounding Cable in the correct direction. TP (Round End); M3x8...

  • Page 105: Affixing The Label

    6. Installation Affixing the Label Cleaning the Stream Reading Glass NOTE: Clean the Stream Reading Glass with a lint-free paper.
  • Page 106 6. Installation...

  • Page 107: Operation Check

    6. Installation Operation Check 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power of the host machine. 3. Check the copy operation of the single-sided and double-sided document with the ADF.

  • Page 108: Appendices

    APPENDICES Service Tools........103 General Circuit Diagram....104...

  • Page 109: Service Tools

    Service Tools Service Tools Special Tools In addition to the standard tools set, the following special tools are required when servicing the machine: Tool name Tool No. Rank* Configuration Use/Remarks Digital multimeter FY9-2002-000 For making electrical- checks. hex wrench (2.5 mm) Hinge Pressure Ad- justment Reference: Category...

  • Page 110: General Circuit Diagram

    General Circuit Diagram General Circuit Diagram DADF-BA1 Pickup Motor Read Motor Pickup Clutch Registration Clutch Release Solenoid Stamp Solenoid J105 J109 MT10 MT12 18 17 16 15 14 13 12 11 10 9 8 2 3 4 3 4 5 6 3 4 5 6 J101...
