The following table outlines the steps for removing and replacing the LCD for the Latitude™ D620.

Removing and Replacing the LCD

1. Before removing the LCD:
Remove the AC power.
Remove the battery.
Remove the hinge cover.
Remove the keyboard.
2. Locate the LCD.
3. Disconnect all cables to the WWAN and WLAN cards if necessary.
4.
Disconnect the video cable from the chassis.
